9RR9 | pdb_00009rr9

Galectin-3 with a bound inhibitor

PDB DOI: https://doi.org/10.2210/pdb9RR9/pdb

Classification: SUGAR BINDING PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-06-27 Released: 2026-07-08
Deposition Author(s): Mac Sweeney, A.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.207 (Depositor), 0.199 (DCC)
R-Value Work:
0.193 (Depositor), 0.183 (DCC)
R-Value Observed:
0.194 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Galectin-3 with a bound inhibitor

Mac Sweeney, A.

To be published.

Macromolecule Content

Total Structure Weight: 32.91 kDa
Atom Count: 2,530
Modeled Residue Count: 276
Deposited Residue Count: 276
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Galectin-3	A, B	138	Homo sapiens	Mutation(s): 0 Gene Names: LGALS3, MAC2
UniProt & NIH Common Fund Data Resources
Find proteins for P17931 (Homo sapiens) Explore P17931 Go to UniProtKB: P17931
PHAROS: P17931 GTEx: ENSG00000131981
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P17931
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1JIU (Subject of Investigation/LOI) Query on A1JIU Download:Ideal Coordinates CCD File SDF format, chain G [auth B] SDF format, chain C [auth A] MOL2 format, chain G [auth B] MOL2 format, chain C [auth A] mmCIF format, chain G [auth B] mmCIF format, chain C [auth A]	C [auth A], G [auth B]	(2~{R},3~{R},4~{S},5~{R},6~{S})-2-(hydroxymethyl)-6-[(~{R})-(2-methylphenyl)-(1-oxidanylcyclohexyl)methyl]sulfanyl-4-[4-[3,4,5-tris(fluoranyl)phenyl]-1,2,3-triazol-1-yl]oxane-3,5-diol C₂₈ H₃₂ F₃ N₃ O₅ S URNHDQNEVNGJOB-CCUOSZMHSA-N		Interactions Focus chain C [auth A] Focus chain G [auth B] Interactions & Density Focus chain C [auth A] Focus chain G [auth B]
SCN Query on SCN Download:Ideal Coordinates CCD File SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain H [auth B] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain H [auth B] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain H [auth B] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A] E [auth A] F [auth A] H [auth B] I [auth B] D [auth A], E [auth A], F [auth A], H [auth B], I [auth B], J [auth B]	THIOCYANATE ION C N S ZMZDMBWJUHKJPS-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B]
