9RQK | pdb_00009rqk

COXSACKIE B3 2C PROTEIN IN COMPLEX WITH COMPOUND 53

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.72 Å
  • R-Value Free:
    0.223 (Depositor), 0.215 (DCC)
  • R-Value Work:
    0.196 (Depositor), 0.192 (DCC)
  • R-Value Observed:
    0.198 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9RQK

Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history.

Literature

New fluoxetine analogues as anti-enterovirus agents targeting 2C protein.

Khemiri, S., Faucher, M.O., Bourg, S., Attoumani-Madi, S., Yaacoub, C., Touret, F., Farag, M., Vitorino, M.F., Bonnet, P., Vanelle, P., Aci-Seche, S., Coutard, B., Barral, K.

(2026) Eur J Med Chem 306: 118621-118621

  • DOI: https://doi.org/10.1016/j.ejmech.2026.118621
  • Primary Citation Related Structures:
    9RQK

  • PubMed Abstract:

    There are currently no antiviral drugs available to treat or prevent life-threatening human non-poliovirus enterovirus infections, such as those caused by CV-B3, EV-A71 or EV-D68. Our aim is to develop novel inhibitors that target the non-structural ATPase/Helicase 2C protein, which is involved in the RNA replication process that is essential for enterovirus replication, among other functions. In this study, we describe the optimization of (S)-fluoxetine, a promising hit identified through drug repurposing that binds to an allosteric site on the CV-B3 2C ATPase domain. Our optimization process was guided by rational design, X-ray crystallographic structures, computational docking, and validation by enzyme and cell-based assays, leading to several new inhibitors, among which compound 53 (CV-B3 EC 50  = 0.5 μM and EV-D68 EC 50  = 0.4 μM), a novel anti-enterovirus with higher selectivity indexes than (S)-fluoxetine.

    • Organizational Affiliation:
    • Aix Marseille Univ, CNRS, ICR, Marseille, France.

Macromolecule Content

  • Total Structure Weight: 24.2 kDa
  • Atom Count: 1,860
  • Modeled Residue Count: 207
  • Deposited Residue Count: 215
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:
|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
2C protein215Coxsackievirus B3Mutation(s): 0
EC: 3.4.22.29 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.4.22.28 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
UniProt
Find proteins for Q9E7C2 (Coxsackievirus B3)
Explore Q9E7C2
Go to UniProtKB:  Q9E7C2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9E7C2
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.72 Å
  • R-Value Free:  0.223 (Depositor), 0.215 (DCC)
  • R-Value Work:  0.196 (Depositor), 0.192 (DCC)
  • R-Value Observed: 0.198 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 49.665α = 90
b = 55.724β = 90
c = 80γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Agence Nationale de la Recherche (ANR)FranceANR-23-CE18-0023-01

Revision History  (Full details and data files)

  • Version 1.0: 2026-02-18
    Type: Initial release
