9RIE | pdb_00009rie

Integrin alpha(2) I-domain mutant

PDB DOI: https://doi.org/10.2210/pdb9RIE/pdb

Classification: CELL ADHESION
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-06-11 Released: 2026-06-24
Deposition Author(s): Airenne, T.T., Bligt-Linden, E., Parkash, V., Kapyla, J., Heino, J., Salminen, T.A.
Funding Organization(s): Sigrid Juselius Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free:
0.189 (Depositor), 0.182 (DCC)
R-Value Work:
0.147 (Depositor), 0.142 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9RIE

This is version 1.0 of the entry. See complete history.

Literature

Integrin alpha(2) I-domain mutant

Airenne, T.T., Bligt-Linden, E., Parkash, V., Kapyla, J., Heino, J., Salminen, T.A.

To be published.

Macromolecule Content

Total Structure Weight: 21.93 kDa
Atom Count: 1,759
Modeled Residue Count: 191
Deposited Residue Count: 199
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Integrin alpha-2	A	199	Homo sapiens	Mutation(s): 0 Gene Names: ITGA2, CD49B
UniProt & NIH Common Fund Data Resources
Find proteins for P17301 (Homo sapiens) Explore P17301 Go to UniProtKB: P17301
PHAROS: P17301 GTEx: ENSG00000164171
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P17301
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
LMR Query on LMR Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	(2S)-2-hydroxybutanedioic acid C₄ H₆ O₅ BJEPYKJPYRNKOW-REOHCLBHSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
MG (Subject of Investigation/LOI) Query on MG Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free: 0.189 (Depositor), 0.182 (DCC)
R-Value Work: 0.147 (Depositor), 0.142 (DCC)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 36.26	α = 90
b = 53.42	β = 96.093
c = 49.02	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
Aimless	data scaling
PHASER	phasing
REFMAC	refinement

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-06-24

Deposition Author(s):

Bligt-Linden, E.

Funding Organization	Location	Grant Number
Sigrid Juselius Foundation	Finland	--

Revision History (Full details and data files)

Version 1.0: 2026-06-24
Type: Initial release
