9RG2 | pdb_00009rg2

Unspecific peroxygenase from Psathyrella aberdarensis, Grogu variant, in complex with alpha-damascone

PDB DOI: https://doi.org/10.2210/pdb9RG2/pdb

Classification: OXIDOREDUCTASE
Organism(s): Candolleomyces aberdarensis
Expression System: Komagataella phaffii CBS 7435
Mutation(s): Yes

Deposited: 2025-06-05 Released: 2026-04-01
Deposition Author(s): Fernandez-Garcia, A., Sanz-Aparicio, J.
Funding Organization(s): Spanish Ministry of Science, Innovation, and Universities

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.185 (Depositor), 0.194 (DCC)
R-Value Work:
0.155 (Depositor), 0.164 (DCC)
R-Value Observed:
0.156 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Structural features and reaction profile of an evolved unspecific peroxygenase from Candolleomyces aberdarensis

Fernandez-Garcia, A., Sanz-Aparicio, J.

(2026) Adv Synth Catal

DOI: https://doi.org/10.1002/adsc.70432

Macromolecule Content

Total Structure Weight: 79.99 kDa
Atom Count: 6,476
Modeled Residue Count: 668
Deposited Residue Count: 668
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Heme-thiolate peroxidase	A, B	334	Candolleomyces aberdarensis	Mutation(s): 3 Gene Names: EST38_g7491 EC: 1.11.2.1
UniProt
Find proteins for A0A4Q2DF39 (Candolleomyces aberdarensis) Explore A0A4Q2DF39 Go to UniProtKB: A0A4Q2DF39
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A4Q2DF39
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C, D	2		N/A	Interactions Focus chain C Focus chain D Interactions & Density Focus chain C Focus chain D
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 11 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
HEM (Subject of Investigation/LOI) Query on HEM Download:Ideal Coordinates CCD File SDF format, chain BA [auth B] SDF format, chain G [auth A] MOL2 format, chain BA [auth B] MOL2 format, chain G [auth A] mmCIF format, chain BA [auth B] mmCIF format, chain G [auth A]	BA [auth B], G [auth A]	PROTOPORPHYRIN IX CONTAINING FE C₃₄ H₃₂ Fe N₄ O₄ KABFMIBPWCXCRK-RGGAHWMASA-L		Interactions Focus chain BA [auth B] Focus chain G [auth A] Interactions & Density Focus chain BA [auth B] Focus chain G [auth A]
NDG Query on NDG Download:Ideal Coordinates CCD File SDF format, chain K [auth A] MOL2 format, chain K [auth A] mmCIF format, chain K [auth A]	K [auth A]	2-acetamido-2-deoxy-alpha-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-PVFLNQBWSA-N		Interactions Focus chain K [auth A] Interactions & Density Focus chain K [auth A]
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain CA [auth B] SDF format, chain DA [auth B] SDF format, chain EA [auth B] SDF format, chain FA [auth B] SDF format, chain H [auth A] SDF format, chain J [auth A] SDF format, chain Y [auth B] MOL2 format, chain AA [auth B] MOL2 format, chain CA [auth B] MOL2 format, chain DA [auth B] MOL2 format, chain EA [auth B] MOL2 format, chain FA [auth B] MOL2 format, chain H [auth A] MOL2 format, chain J [auth A] MOL2 format, chain Y [auth B] mmCIF format, chain AA [auth B] mmCIF format, chain CA [auth B] mmCIF format, chain DA [auth B] mmCIF format, chain EA [auth B] mmCIF format, chain FA [auth B] mmCIF format, chain H [auth A] mmCIF format, chain J [auth A] mmCIF format, chain Y [auth B]	AA [auth B] CA [auth B] DA [auth B] EA [auth B] FA [auth B] AA [auth B], CA [auth B], DA [auth B], EA [auth B], FA [auth B], H [auth A], J [auth A], Y [auth B]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain AA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain H [auth A] Focus chain J [auth A] Focus chain Y [auth B] Interactions & Density Focus chain AA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain H [auth A] Focus chain J [auth A] Focus chain Y [auth B]
MES Query on MES Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain Z [auth B] MOL2 format, chain E [auth A] MOL2 format, chain Z [auth B] mmCIF format, chain E [auth A] mmCIF format, chain Z [auth B]	E [auth A], Z [auth B]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C₆ H₁₃ N O₄ S SXGZJKUKBWWHRA-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain Z [auth B] Interactions & Density Focus chain E [auth A] Focus chain Z [auth B]
A1IUA (Subject of Investigation/LOI) Query on A1IUA Download:Ideal Coordinates CCD File SDF format, chain GA [auth B] SDF format, chain I [auth A] MOL2 format, chain GA [auth B] MOL2 format, chain I [auth A] mmCIF format, chain GA [auth B] mmCIF format, chain I [auth A]	GA [auth B], I [auth A]	alpha-damascone C₁₃ H₂₀ O CRIGTVCBMUKRSL-PZBABLGHSA-N		Interactions Focus chain GA [auth B] Focus chain I [auth A] Interactions & Density Focus chain GA [auth B] Focus chain I [auth A]
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain IA [auth B] SDF format, chain KA [auth B] MOL2 format, chain IA [auth B] MOL2 format, chain KA [auth B] mmCIF format, chain IA [auth B] mmCIF format, chain KA [auth B]	IA [auth B], KA [auth B]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain IA [auth B] Focus chain KA [auth B] Interactions & Density Focus chain IA [auth B] Focus chain KA [auth B]
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain TA [auth B] SDF format, chain UA [auth B] SDF format, chain X [auth A] MOL2 format, chain TA [auth B] MOL2 format, chain UA [auth B] MOL2 format, chain X [auth A] mmCIF format, chain TA [auth B] mmCIF format, chain UA [auth B] mmCIF format, chain X [auth A]	TA [auth B], UA [auth B], X [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain TA [auth B] Focus chain UA [auth B] Focus chain X [auth A] Interactions & Density Focus chain TA [auth B] Focus chain UA [auth B] Focus chain X [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain HA [auth B] SDF format, chain LA [auth B] SDF format, chain MA [auth B] MOL2 format, chain F [auth A] MOL2 format, chain HA [auth B] MOL2 format, chain LA [auth B] MOL2 format, chain MA [auth B] mmCIF format, chain F [auth A] mmCIF format, chain HA [auth B] mmCIF format, chain LA [auth B] mmCIF format, chain MA [auth B]	F [auth A], HA [auth B], LA [auth B], MA [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain HA [auth B] Focus chain LA [auth B] Focus chain MA [auth B] Interactions & Density Focus chain F [auth A] Focus chain HA [auth B] Focus chain LA [auth B] Focus chain MA [auth B]
ZN (Subject of Investigation/LOI) Query on ZN Download:Ideal Coordinates CCD File SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain NA [auth B] SDF format, chain O [auth A] SDF format, chain OA [auth B] SDF format, chain P [auth A] SDF format, chain PA [auth B] SDF format, chain Q [auth A] SDF format, chain QA [auth B] SDF format, chain R [auth A] SDF format, chain RA [auth B] SDF format, chain S [auth A] SDF format, chain T [auth A] SDF format, chain U [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain NA [auth B] MOL2 format, chain O [auth A] MOL2 format, chain OA [auth B] MOL2 format, chain P [auth A] MOL2 format, chain PA [auth B] MOL2 format, chain Q [auth A] MOL2 format, chain QA [auth B] MOL2 format, chain R [auth A] MOL2 format, chain RA [auth B] MOL2 format, chain S [auth A] MOL2 format, chain T [auth A] MOL2 format, chain U [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain NA [auth B] mmCIF format, chain O [auth A] mmCIF format, chain OA [auth B] mmCIF format, chain P [auth A] mmCIF format, chain PA [auth B] mmCIF format, chain Q [auth A] mmCIF format, chain QA [auth B] mmCIF format, chain R [auth A] mmCIF format, chain RA [auth B] mmCIF format, chain S [auth A] mmCIF format, chain T [auth A] mmCIF format, chain U [auth A]	L [auth A] M [auth A] N [auth A] NA [auth B] O [auth A] L [auth A], M [auth A], N [auth A], NA [auth B], O [auth A], OA [auth B], P [auth A], PA [auth B], Q [auth A], QA [auth B], R [auth A], RA [auth B], S [auth A], T [auth A], U [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain NA [auth B] Focus chain O [auth A] Focus chain OA [auth B] Focus chain P [auth A] Focus chain PA [auth B] Focus chain Q [auth A] Focus chain QA [auth B] Focus chain R [auth A] Focus chain RA [auth B] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Interactions & Density Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain NA [auth B] Focus chain O [auth A] Focus chain OA [auth B] Focus chain P [auth A] Focus chain PA [auth B] Focus chain Q [auth A] Focus chain QA [auth B] Focus chain R [auth A] Focus chain RA [auth B] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A]
EOH Query on EOH Download:Ideal Coordinates CCD File SDF format, chain JA [auth B] SDF format, chain W [auth A] MOL2 format, chain JA [auth B] MOL2 format, chain W [auth A] mmCIF format, chain JA [auth B] mmCIF format, chain W [auth A]	JA [auth B], W [auth A]	ETHANOL C₂ H₆ O LFQSCWFLJHTTHZ-UHFFFAOYSA-N		Interactions Focus chain JA [auth B] Focus chain W [auth A] Interactions & Density Focus chain JA [auth B] Focus chain W [auth A]
MG (Subject of Investigation/LOI) Query on MG Download:Ideal Coordinates CCD File SDF format, chain SA [auth B] SDF format, chain V [auth A] MOL2 format, chain SA [auth B] MOL2 format, chain V [auth A] mmCIF format, chain SA [auth B] mmCIF format, chain V [auth A]	SA [auth B], V [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain SA [auth B] Focus chain V [auth A] Interactions & Density Focus chain SA [auth B] Focus chain V [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.185 (Depositor), 0.194 (DCC)
R-Value Work: 0.155 (Depositor), 0.164 (DCC)
R-Value Observed: 0.156 (Depositor)

Space Group: P 6₅

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 76.33	α = 90
b = 76.33	β = 90
c = 272.231	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
XDS	data scaling
REFMAC	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-04-01

Deposition Author(s):

Fernandez-Garcia, A.

Sanz-Aparicio, J.

Funding Organization	Location	Grant Number
Spanish Ministry of Science, Innovation, and Universities	Spain	Y2018/BIO-4738-EVOQUIMERA-CM
Spanish Ministry of Science, Innovation, and Universities	Spain	PID2019-105838RB-C33
