9QAW | pdb_00009qaw

CryoEM structure of the human LRP2 receptor ectodomain in complex with LRPAP1

PDB DOI: https://doi.org/10.2210/pdb9QAW/pdb
EM Map EMD-52977: EMDB EMDataResource

Classification: ENDOCYTOSIS
Organism(s): Homo sapiens
Expression System: Escherichia coli, Homo sapiens
Mutation(s): No

Deposited: 2025-02-28 Released: 2026-03-11
Deposition Author(s): Ramanadane, K., Coscia, F.
Funding Organization(s): European Research Council (ERC), Swiss National Science Foundation, Human Frontier Science Program (HFSP)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.34 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9QAW

This is version 1.0 of the entry. See complete history.

Literature

CryoEM structure of the human LRP2 receptor ectodomain in complex with LRPAP1

Ramanadane, K., Coscia, F.

To be published.

Macromolecule Content

Total Structure Weight: 1,106.85 kDa
Atom Count: 63,458
Modeled Residue Count: 7,952
Deposited Residue Count: 9,708
Unique protein chains: 7

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Alpha-2-macroglobulin receptor-associated protein	A [auth L], L [auth K]	344	Homo sapiens	Mutation(s): 0 Gene Names: LRPAP1, A2MRAP
UniProt & NIH Common Fund Data Resources
Find proteins for P30533 (Homo sapiens) Explore P30533 Go to UniProtKB: P30533
PHAROS: P30533 GTEx: ENSG00000163956
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P30533
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Low-density lipoprotein receptor-related protein 2	B [auth A], C [auth B]	4,473	Homo sapiens	Mutation(s): 0 Gene Names: LRP2
UniProt & NIH Common Fund Data Resources
Find proteins for P98164 (Homo sapiens) Explore P98164 Go to UniProtKB: P98164
PHAROS: P98164 GTEx: ENSG00000081479
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P98164
Glycosylation
Glycosylation Sites: 13	Glycosylation Focus chain B [auth A] Focus chain C [auth B]	Go to GlyGen: P98164-1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Unidentified peptide 1	D, G [auth E]	10	Homo sapiens	Mutation(s): 0

Find similar proteins by: Sequence | 3D Structure

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Unidentified peptide 2	E [auth C], F, K [auth J]	7	Homo sapiens	Mutation(s): 0

Find similar proteins by: Sequence | 3D Structure

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
Unidentified peptide 3	H	12	Homo sapiens	Mutation(s): 0

Find similar proteins by: Sequence | 3D Structure

Entity ID: 6
Molecule	Chains	Sequence Length	Organism	Details	Image
Unidentified peptide 4	I	8	Homo sapiens	Mutation(s): 0

Find similar proteins by: Sequence | 3D Structure

Entity ID: 7
Molecule	Chains	Sequence Length	Organism	Details	Image
Unidentified peptide 5	J [auth G]	13	Homo sapiens	Mutation(s): 0

Oligosaccharides

Entity ID: 8
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	AA [auth a], BA [auth b], M, N, T, AA [auth a], BA [auth b], M, N, T, X, Y	3		N-Glycosylation	Interactions Focus chain AA [auth a] Focus chain BA [auth b] Focus chain M Focus chain N Focus chain T Focus chain X Focus chain Y Interactions & Density Focus chain AA [auth a] Focus chain BA [auth b] Focus chain M Focus chain N Focus chain T Focus chain X Focus chain Y
Glycosylation Resources
GlyTouCan: G15407YE GlyCosmos: G15407YE GlyGen: G15407YE

Entity ID: 9
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	O, P, Q, R, S O, P, Q, R, S, U, V, W, Z	2		N-Glycosylation	Interactions Focus chain O Focus chain P Focus chain Q Focus chain R Focus chain S Focus chain U Focus chain V Focus chain W Focus chain Z Interactions & Density Focus chain O Focus chain P Focus chain Q Focus chain R Focus chain S Focus chain U Focus chain V Focus chain W Focus chain Z
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NGA Query on NGA Download:Ideal Coordinates CCD File SDF format, chain MA [auth A] SDF format, chain MB [auth B] SDF format, chain NA [auth A] SDF format, chain NB [auth B] SDF format, chain OA [auth A] SDF format, chain OB [auth B] SDF format, chain PA [auth A] MOL2 format, chain MA [auth A] MOL2 format, chain MB [auth B] MOL2 format, chain NA [auth A] MOL2 format, chain NB [auth B] MOL2 format, chain OA [auth A] MOL2 format, chain OB [auth B] MOL2 format, chain PA [auth A] mmCIF format, chain MA [auth A] mmCIF format, chain MB [auth B] mmCIF format, chain NA [auth A] mmCIF format, chain NB [auth B] mmCIF format, chain OA [auth A] mmCIF format, chain OB [auth B] mmCIF format, chain PA [auth A]	MA [auth A] MB [auth B] NA [auth A] NB [auth B] OA [auth A] MA [auth A], MB [auth B], NA [auth A], NB [auth B], OA [auth A], OB [auth B], PA [auth A]	2-acetamido-2-deoxy-beta-D-galactopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-JAJWTYFOSA-N		Interactions Focus chain MA [auth A] Focus chain MB [auth B] Focus chain NA [auth A] Focus chain NB [auth B] Focus chain OA [auth A] Focus chain OB [auth B] Focus chain PA [auth A] Interactions & Density Focus chain MA [auth A] Focus chain MB [auth B] Focus chain NA [auth A] Focus chain NB [auth B] Focus chain OA [auth A] Focus chain OB [auth B] Focus chain PA [auth A]
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain CA [auth A] SDF format, chain DA [auth A] SDF format, chain EA [auth A] SDF format, chain FB [auth B] SDF format, chain GB [auth B] SDF format, chain HA [auth A] SDF format, chain HB [auth B] SDF format, chain IA [auth A] SDF format, chain IB [auth B] SDF format, chain JA [auth A] SDF format, chain JB [auth B] SDF format, chain KA [auth A] SDF format, chain KB [auth B] SDF format, chain LA [auth A] SDF format, chain LB [auth B] SDF format, chain PB [auth B] SDF format, chain QA [auth A] SDF format, chain QB [auth B] SDF format, chain RA [auth A] MOL2 format, chain CA [auth A] MOL2 format, chain DA [auth A] MOL2 format, chain EA [auth A] MOL2 format, chain FB [auth B] MOL2 format, chain GB [auth B] MOL2 format, chain HA [auth A] MOL2 format, chain HB [auth B] MOL2 format, chain IA [auth A] MOL2 format, chain IB [auth B] MOL2 format, chain JA [auth A] MOL2 format, chain JB [auth B] MOL2 format, chain KA [auth A] MOL2 format, chain KB [auth B] MOL2 format, chain LA [auth A] MOL2 format, chain LB [auth B] MOL2 format, chain PB [auth B] MOL2 format, chain QA [auth A] MOL2 format, chain QB [auth B] MOL2 format, chain RA [auth A] mmCIF format, chain CA [auth A] mmCIF format, chain DA [auth A] mmCIF format, chain EA [auth A] mmCIF format, chain FB [auth B] mmCIF format, chain GB [auth B] mmCIF format, chain HA [auth A] mmCIF format, chain HB [auth B] mmCIF format, chain IA [auth A] mmCIF format, chain IB [auth B] mmCIF format, chain JA [auth A] mmCIF format, chain JB [auth B] mmCIF format, chain KA [auth A] mmCIF format, chain KB [auth B] mmCIF format, chain LA [auth A] mmCIF format, chain LB [auth B] mmCIF format, chain PB [auth B] mmCIF format, chain QA [auth A] mmCIF format, chain QB [auth B] mmCIF format, chain RA [auth A]	CA [auth A] DA [auth A] EA [auth A] FB [auth B] GB [auth B] CA [auth A], DA [auth A], EA [auth A], FB [auth B], GB [auth B], HA [auth A], HB [auth B], IA [auth A], IB [auth B], JA [auth A], JB [auth B], KA [auth A], KB [auth B], LA [auth A], LB [auth B], PB [auth B], QA [auth A], QB [auth B], RA [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain CA [auth A] Focus chain DA [auth A] Focus chain EA [auth A] Focus chain FB [auth B] Focus chain GB [auth B] Focus chain HA [auth A] Focus chain HB [auth B] Focus chain IA [auth A] Focus chain IB [auth B] Focus chain JA [auth A] Focus chain JB [auth B] Focus chain KA [auth A] Focus chain KB [auth B] Focus chain LA [auth A] Focus chain LB [auth B] Focus chain PB [auth B] Focus chain QA [auth A] Focus chain QB [auth B] Focus chain RA [auth A] Interactions & Density Focus chain CA [auth A] Focus chain DA [auth A] Focus chain EA [auth A] Focus chain FB [auth B] Focus chain GB [auth B] Focus chain HA [auth A] Focus chain HB [auth B] Focus chain IA [auth A] Focus chain IB [auth B] Focus chain JA [auth A] Focus chain JB [auth B] Focus chain KA [auth A] Focus chain KB [auth B] Focus chain LA [auth A] Focus chain LB [auth B] Focus chain PB [auth B] Focus chain QA [auth A] Focus chain QB [auth B] Focus chain RA [auth A]
BMA Query on BMA Download:Ideal Coordinates CCD File SDF format, chain FA [auth A] SDF format, chain GA [auth A] MOL2 format, chain FA [auth A] MOL2 format, chain GA [auth A] mmCIF format, chain FA [auth A] mmCIF format, chain GA [auth A]	FA [auth A], GA [auth A]	beta-D-mannopyranose C₆ H₁₂ O₆ WQZGKKKJIJFFOK-RWOPYEJCSA-N		Interactions Focus chain FA [auth A] Focus chain GA [auth A] Interactions & Density Focus chain FA [auth A] Focus chain GA [auth A]
NI Query on NI Download:Ideal Coordinates CCD File SDF format, chain YB [auth B] SDF format, chain ZA [auth A] MOL2 format, chain YB [auth B] MOL2 format, chain ZA [auth A] mmCIF format, chain YB [auth B] mmCIF format, chain ZA [auth A]	YB [auth B], ZA [auth A]	NICKEL (II) ION Ni VEQPNABPJHWNSG-UHFFFAOYSA-N		Interactions Focus chain YB [auth B] Focus chain ZA [auth A] Interactions & Density Focus chain YB [auth B] Focus chain ZA [auth A]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain AB [auth A] SDF format, chain AC [auth B] SDF format, chain BB [auth A] SDF format, chain BC [auth B] SDF format, chain CB [auth A] SDF format, chain CC [auth B] SDF format, chain DB [auth A] SDF format, chain DC [auth B] SDF format, chain EB [auth A] SDF format, chain EC [auth B] SDF format, chain RB [auth B] SDF format, chain SA [auth A] SDF format, chain SB [auth B] SDF format, chain TA [auth A] SDF format, chain TB [auth B] SDF format, chain UA [auth A] SDF format, chain UB [auth B] SDF format, chain VA [auth A] SDF format, chain VB [auth B] SDF format, chain WA [auth A] SDF format, chain WB [auth B] SDF format, chain XA [auth A] SDF format, chain XB [auth B] SDF format, chain YA [auth A] SDF format, chain ZB [auth B] MOL2 format, chain AB [auth A] MOL2 format, chain AC [auth B] MOL2 format, chain BB [auth A] MOL2 format, chain BC [auth B] MOL2 format, chain CB [auth A] MOL2 format, chain CC [auth B] MOL2 format, chain DB [auth A] MOL2 format, chain DC [auth B] MOL2 format, chain EB [auth A] MOL2 format, chain EC [auth B] MOL2 format, chain RB [auth B] MOL2 format, chain SA [auth A] MOL2 format, chain SB [auth B] MOL2 format, chain TA [auth A] MOL2 format, chain TB [auth B] MOL2 format, chain UA [auth A] MOL2 format, chain UB [auth B] MOL2 format, chain VA [auth A] MOL2 format, chain VB [auth B] MOL2 format, chain WA [auth A] MOL2 format, chain WB [auth B] MOL2 format, chain XA [auth A] MOL2 format, chain XB [auth B] MOL2 format, chain YA [auth A] MOL2 format, chain ZB [auth B] mmCIF format, chain AB [auth A] mmCIF format, chain AC [auth B] mmCIF format, chain BB [auth A] mmCIF format, chain BC [auth B] mmCIF format, chain CB [auth A] mmCIF format, chain CC [auth B] mmCIF format, chain DB [auth A] mmCIF format, chain DC [auth B] mmCIF format, chain EB [auth A] mmCIF format, chain EC [auth B] mmCIF format, chain RB [auth B] mmCIF format, chain SA [auth A] mmCIF format, chain SB [auth B] mmCIF format, chain TA [auth A] mmCIF format, chain TB [auth B] mmCIF format, chain UA [auth A] mmCIF format, chain UB [auth B] mmCIF format, chain VA [auth A] mmCIF format, chain VB [auth B] mmCIF format, chain WA [auth A] mmCIF format, chain WB [auth B] mmCIF format, chain XA [auth A] mmCIF format, chain XB [auth B] mmCIF format, chain YA [auth A] mmCIF format, chain ZB [auth B]	AB [auth A] AC [auth B] BB [auth A] BC [auth B] CB [auth A] AB [auth A], AC [auth B], BB [auth A], BC [auth B], CB [auth A], CC [auth B], DB [auth A], DC [auth B], EB [auth A], EC [auth B], RB [auth B], SA [auth A], SB [auth B], TA [auth A], TB [auth B], UA [auth A], UB [auth B], VA [auth A], VB [auth B], WA [auth A], WB [auth B], XA [auth A], XB [auth B], YA [auth A], ZB [auth B]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain AB [auth A] Focus chain AC [auth B] Focus chain BB [auth A] Focus chain BC [auth B] Focus chain CB [auth A] Focus chain CC [auth B] Focus chain DB [auth A] Focus chain DC [auth B] Focus chain EB [auth A] Focus chain EC [auth B] Focus chain RB [auth B] Focus chain SA [auth A] Focus chain SB [auth B] Focus chain TA [auth A] Focus chain TB [auth B] Focus chain UA [auth A] Focus chain UB [auth B] Focus chain VA [auth A] Focus chain VB [auth B] Focus chain WA [auth A] Focus chain WB [auth B] Focus chain XA [auth A] Focus chain XB [auth B] Focus chain YA [auth A] Focus chain ZB [auth B] Interactions & Density Focus chain AB [auth A] Focus chain AC [auth B] Focus chain BB [auth A] Focus chain BC [auth B] Focus chain CB [auth A] Focus chain CC [auth B] Focus chain DB [auth A] Focus chain DC [auth B] Focus chain EB [auth A] Focus chain EC [auth B] Focus chain RB [auth B] Focus chain SA [auth A] Focus chain SB [auth B] Focus chain TA [auth A] Focus chain TB [auth B] Focus chain UA [auth A] Focus chain UB [auth B] Focus chain VA [auth A] Focus chain VB [auth B] Focus chain WA [auth A] Focus chain WB [auth B] Focus chain XA [auth A] Focus chain XB [auth B] Focus chain YA [auth A] Focus chain ZB [auth B]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.34 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.21.2_5419

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-03-11

Deposition Author(s):

Funding Organization	Location	Grant Number
European Research Council (ERC)	European Union	101041298
Swiss National Science Foundation	Switzerland	P500PB_217862
Human Frontier Science Program (HFSP)	France	LT0024/2024-L

Revision History (Full details and data files)

Version 1.0: 2026-03-11
Type: Initial release
