9PMY | pdb_00009pmy

Crystal Structure of an ATP-Binding Cassette (ABC) Transporter Associated, Xyloglucan-Binding Protein from the Extremely Thermophilic, Lignocellulose Degrading Bacterium Anaerocellum (f. Caldicellulosiruptor) bescii


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.43 Å
  • R-Value Free:
    0.218 (Depositor), 0.219 (DCC)
  • R-Value Work:
    0.164 (Depositor), 0.167 (DCC)
  • R-Value Observed:
    0.167 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9PMY

This is version 1.1 of the entry. See complete history

Literature

Structural insights into xyloglucan recognition by an ABC transporter from a Gram-positive, thermophilic bacterium.

Tjo, H.Jiang, V.Jeffrey, P.D.Zhu, A.Link, A.J.Joseph, J.A.Conway, J.M.

(2026) FEBS J

  • DOI: https://doi.org/10.1111/febs.70667
  • Primary Citation Related Structures:
    9PMY

  • PubMed Abstract:

    Xyloglucan (an α-1,6-xylosyl-substituted β-1,4-glucan) is a major hemicellulose of the primary cell wall of many plants and an important growth substrate for biomass-degrading bacteria in diverse ecological niches, including the gut microbiome and hot springs. In Gram-positive bacteria, xyloglucan is deconstructed into soluble oligosaccharides in the extracytoplasmic space before import by ATP-Binding Cassette (ABC) transporters, but the structural basis for this process remains poorly understood. Here, we identified an ABC transporter for xyloglucan uptake (Athe_2052-2054) in the Gram-positive, plant biomass-degrading thermophile Anaerocellum bescii, which is conserved across the Anaerocellum genus. We solved the apo crystal structure of its extracellular substrate-binding protein (SBP), Athe_2052, revealing a unique tertiary fold found only in a small subset of SBPs that bind complex oligosaccharides. To our knowledge, Athe_2052 is the first structurally characterized ABC SBP known to recognize xyloglucan oligosaccharides. Biophysical analysis showed that while Athe_2052 binds unsubstituted β-glucan chains, recognition of xyloglucan side chains in the binding pocket markedly increases affinity (K d  = 14 nm) for xyloglucan heptasaccharide (XXXG), the principal oligosaccharide released during xyloglucan deconstruction. Molecular modeling revealed that xyloglucan heptasaccharide, owing to its branched substitutions, is bound in a distinct conformation compared to unsubstituted β-glucans. This represents a unique mode of xyloglucan recognition driven by α-linked side chain interactions rather than β-glucan backbone recognition alone. Together, these findings provide the first structural basis for xyloglucan oligosaccharide recognition by an ABC transporter in Gram-positive bacteria.


  • Organizational Affiliation
    • Department of Chemical and Biological Engineering, Princeton University, NJ, USA.

Macromolecule Content

  • Total Structure Weight: 126.28 kDa
  • Atom Count: 8,989
  • Modeled Residue Count: 1,066
  • Deposited Residue Count: 1,100
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Extracellular solute-binding protein family 1
A, B
550Caldicellulosiruptor besciiMutation(s): 0
Gene Names: Athe_2052
UniProt
Find proteins for B9MLD9 (Caldicellulosiruptor bescii (strain ATCC BAA-1888 / DSM 6725 / KCTC 15123 / Z-1320))
Explore B9MLD9
Go to UniProtKB:  B9MLD9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB9MLD9
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.43 Å
  • R-Value Free:  0.218 (Depositor), 0.219 (DCC)
  • R-Value Work:  0.164 (Depositor), 0.167 (DCC)
  • R-Value Observed: 0.167 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 43.291α = 90
b = 129.997β = 93.611
c = 111.249γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2026-07-29
    Type: Initial release
  • Version 1.1: 2026-08-26
    Changes: Database references
