9N87 | pdb_00009n87

Cryo-EM structure of human importin beta: xIBB complex


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.40 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9N87

This is version 1.1 of the entry. See complete history

Literature

Ran modulates allosteric crosstalk between importin beta surfaces.

Ko, Y.H.Li, F.Suinn, S.S.Li, J.Hou, C.D.Lokareddy, R.K.Cingolani, G.

(2025) Nat Commun 16: 11425-11425

  • DOI: https://doi.org/10.1038/s41467-025-66255-0
  • Primary Citation Related Structures:
    9BFC, 9N85, 9N86, 9N87, 9YB5

  • PubMed Abstract:

    A cellular gradient of the GTPase Ran orchestrates the movement of import and export complexes through the Nuclear Pore Complex (NPC). Ran-GTP modulates two essential activities of importin β during nuclear import. On the one hand, it reduces the avidity of importin β for phenylalanine-glycine-rich nucleoporins (FG-nups), thereby facilitating the passage of import complexes through the permeability barrier. On the other hand, it disassembles import complexes, releasing the import cargo into the nucleus. The precise mechanisms by which Ran-GTP modulates importin β activities have remained hypothetical. Leveraging cryogenic electron microscopy (cryo-EM) single-particle analysis, in this paper, we describe five distinct conformational states of importin β in complex with various effectors encountered during an import reaction, specifically IBB-cargos, FG-repeats, Ran-GTP, Ran-GTP:RanBP1, and Ran-GDP:RanBP1. Comparing these states allows us to decipher the conformational landscape of importin β without interference from crystallization agents and lattice forces. By correlating structural data with biochemical activities, we find that Ran-GTP, but not Ran-GDP, constrains the solenoid structure of importin β, closing high-affinity FG-binding pockets and displacing import cargos through allosteric crosstalk between the concave and convex surfaces. We propose that this allosteric mechanism is relevant to other β-karyopherins involved in nuclear import.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Genetics, The University of Alabama at Birmingham, Birmingham, AL, USA.

Macromolecule Content

  • Total Structure Weight: 102.85 kDa
  • Atom Count: 7,195
  • Modeled Residue Count: 921
  • Deposited Residue Count: 921
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Importin subunit beta-1876Homo sapiensMutation(s): 0
Gene Names: KPNB1NTF97
UniProt & NIH Common Fund Data Resources
Find proteins for Q14974 (Homo sapiens)
Explore Q14974
Go to UniProtKB:  Q14974
PHAROS:  Q14974
GTEx:  ENSG00000108424
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ14974
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
XRIP1a45Xenopus laevisMutation(s): 0

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.40 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX
RECONSTRUCTIONcryoSPARC

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2025-12-10
    Type: Initial release
  • Version 1.1: 2026-06-24
    Changes: Data collection, Database references
