9N5J | pdb_00009n5j

Cryo-EM structure of the magnesium transporter MgtA in the E2 conformation with bound beryllium fluoride (BeF3-) and Mg2+ at 2.65 A resolution.

PDB DOI: https://doi.org/10.2210/pdb9N5J/pdb
EM Map EMD-48923: EMDB EMDataResource

Classification: TRANSPORT PROTEIN
Organism(s): Lactococcus lactis subsp. lactis
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-02-04 Released: 2026-02-18
Deposition Author(s): Khan, M.B., Primeau, J.O., Basu, P.C., Morth, J.P., Lemieux, M.J., Young, H.S.
Funding Organization(s): Canadian Institutes of Health Research (CIHR)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.59 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9N5J

This is version 1.1 of the entry. See complete history.

Literature

Cryo-EM structure of a membrane transport protein

Khan, M.B., Primeau, J.O., Basu, P.C., Morth, J.P., Lemieux, M.J., Young, H.S.

To be published.

Macromolecule Content

Total Structure Weight: 203.24 kDa
Atom Count: 13,686
Modeled Residue Count: 1,778
Deposited Residue Count: 1,842
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Magnesium-transporting ATPase, P-type 1	A, B [auth C]	921	Lactococcus lactis subsp. lactis	Mutation(s): 0 Gene Names: LL275_1350 EC: 7.2.2.14
UniProt
Find proteins for A0A1V0NGB6 (Lactococcus lactis subsp. lactis) Explore A0A1V0NGB6 Go to UniProtKB: A0A1V0NGB6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A1V0NGB6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
BEF (Subject of Investigation/LOI) Query on BEF Download:Ideal Coordinates CCD File SDF format, chain H [auth C] SDF format, chain E [auth A] MOL2 format, chain H [auth C] MOL2 format, chain E [auth A] mmCIF format, chain H [auth C] mmCIF format, chain E [auth A]	E [auth A], H [auth C]	BERYLLIUM TRIFLUORIDE ION Be F₃ OGIAHMCCNXDTIE-UHFFFAOYSA-K		Interactions Focus chain E [auth A] Focus chain H [auth C] Interactions & Density Focus chain E [auth A] Focus chain H [auth C]
MG (Subject of Investigation/LOI) Query on MG Download:Ideal Coordinates CCD File SDF format, chain G [auth C] SDF format, chain F [auth C] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain G [auth C] MOL2 format, chain F [auth C] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain G [auth C] mmCIF format, chain F [auth C] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A], D [auth A], F [auth C], G [auth C]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain F [auth C] Focus chain G [auth C] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain F [auth C] Focus chain G [auth C]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.59 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.21.2_5419

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-02-18

Deposition Author(s):

Funding Organization	Location	Grant Number
Canadian Institutes of Health Research (CIHR)	Canada	--

Revision History (Full details and data files)

Version 1.0: 2026-02-18
Type: Initial release
Version 1.1: 2026-03-04
Changes: Data collection, Structure summary
