9MNS | pdb_00009mns

Structure of Hepatitis C virus envelope glycoprotein E2 core from genotype 6a bound to broadly neutralizing antibody RM1-36


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.89 Å
  • R-Value Free:
    0.250 (Depositor), 0.247 (DCC)
  • R-Value Work:
    0.232 (Depositor), 0.228 (DCC)
  • R-Value Observed:
    0.233 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9MNS

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Structural and genetic signatures of two classes of HCV E2 neutralizing face antibodies from non-human primates immunized with a recombinant E1E2.

Nguyen, Y.T.K.Chen, F.Giang, E.Saha, S.Ueno, L.A.Chen, C.Watson, C.T.Tzarum, N.Wilson, I.A.Law, M.Stanfield, R.L.

(2026) NPJ Vaccines

  • DOI: https://doi.org/10.1038/s41541-026-01449-1
  • Primary Citation Related Structures:
    9MNQ, 9MNS, 9MNT, 9MNU, 9MRZ, 9MS9, 9MSC

  • PubMed Abstract:

    Hepatitis C continues to be a significant public health problem despite advancements in antiviral therapeutics. To eliminate this disease, an effective vaccine against new infections and re-infections is needed. However, to date only one Hepatitis C virus (HCV) envelope protein (E1E2) immunogen, developed by Chiron Inc., has been tested in a Phase I clinical trial (ClinicalTrials.gov identifier NCT00500747). To establish a benchmark for elicitation of broadly neutralizing antibodies (bnAbs) by E1E2, we previously immunized non-human primates (NHPs) with this immunogen and isolated monoclonal nAbs that exhibit neutralization potency comparable to human nAbs. Here we show that NHP nAbs, encoded by germline genes IGHV1-138*01 and IGHV4-NL_5*01 (homologs of human IGHV1-69*10 and IGHV4-59*12, respectively), recognize a relatively conserved E2 region (neutralizing face) proximal to antigenic region 3 (AR3). These NHP AR3-targeting nAbs share highly similar binding modes to human AR3-targeting nAbs, suggesting a similarity in human and NHP immune responses to the same HCV immunogen.


  • Organizational Affiliation
    • Department of Integrative Structural and Computational Biology, The Scripps Research Institute, La Jolla, CA, USA.

Macromolecule Content

  • Total Structure Weight: 146.4 kDa
  • Atom Count: 9,140
  • Modeled Residue Count: 1,185
  • Deposited Residue Count: 1,328
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
RM1-36 Fab heavy chainA [auth H],
D [auth h]
222Macaca mulattaMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
RM1-36 Fab light chainB [auth L],
C [auth l]
211Macaca mulattaMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Envelope glycoprotein E2E,
F [auth B]
231Recombinant Hepatitis C virus HK6a/JFH-1Mutation(s): 0
UniProt
Find proteins for B9V0E2 (Recombinant Hepatitis C virus HK6a/JFH-1)
Explore B9V0E2
Go to UniProtKB:  B9V0E2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB9V0E2
Glycosylation
Glycosylation Sites: 3
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.89 Å
  • R-Value Free:  0.250 (Depositor), 0.247 (DCC)
  • R-Value Work:  0.232 (Depositor), 0.228 (DCC)
  • R-Value Observed: 0.233 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 59.751α = 90
b = 223.545β = 93.58
c = 73.296γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAI106005
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAI123861

Revision History  (Full details and data files)

  • Version 1.0: 2026-01-14
    Type: Initial release
  • Version 1.1: 2026-08-05
