9LZR | pdb_00009lzr

Crystal structure of MERS main protease in complex with Pomotrelvir

PDB DOI: https://doi.org/10.2210/pdb9LZR/pdb

Classification: VIRAL PROTEIN
Organism(s): Betacoronavirus England 1
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2025-02-22 Released: 2026-08-26
Deposition Author(s): Zhou, X.L., Zhang, J., Li, J.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.14 Å
R-Value Free:
0.262 (Depositor), 0.263 (DCC)
R-Value Work:
0.224 (Depositor), 0.226 (DCC)
R-Value Observed:
0.226 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9LZR

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of MERS main protease in complex with Pomotrelvir

Zhou, X.L., Zhang, J., Li, J.

To be published.

Macromolecule Content

Total Structure Weight: 66.59 kDa
Atom Count: 4,816
Modeled Residue Count: 601
Deposited Residue Count: 602
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
3C-like proteinase nsp5	A, B	301	Betacoronavirus England 1	Mutation(s): 0 Gene Names: rep, 1a-1b EC: 3.4.22
UniProt
Find proteins for K9N7C7 (Middle East respiratory syndrome-related coronavirus (isolate United Kingdom/H123990006/2012)) Explore K9N7C7 Go to UniProtKB: K9N7C7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	K9N7C7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZQB (Subject of Investigation/LOI) Query on ZQB Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	Pomotrelvir bound form C₂₃ H₂₈ Cl N₅ O₃ IOEBZYOQTDUOBG-UZWGZPNFSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.14 Å
R-Value Free: 0.262 (Depositor), 0.263 (DCC)
R-Value Work: 0.224 (Depositor), 0.226 (DCC)
R-Value Observed: 0.226 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 81.01	α = 90
b = 93.57	β = 90
c = 103.822	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PHENIX	refinement
XDS	data reduction
XDS	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-08-26

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2026-08-26
Type: Initial release
