9L8E | pdb_00009l8e

Structure of Gh-TDH with Additional N-Terminus in Complex with Double-Stranded DNA Containing a 2-Nucleotide 5' Overhang

• PDB DOI: https://doi.org/10.2210/pdb9L8E/pdb
• NAKB: 9L8E

• Classification: TOXIN
• Organism(s): Grimontia hollisae, synthetic construct
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2024-12-27 Released: 2025-12-31
• Deposition Author(s): Hsiao, P.Y., Wu, T.K., Chang, C.Y.
• Funding Organization(s): National Science Council (NSC, Taiwan)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.37 Å
• R-Value Free:
  0.199 (Depositor), 0.199 (DCC)
• R-Value Work:
  0.186 (Depositor), 0.186 (DCC)
• R-Value Observed:
  0.187 (Depositor)

Starting Model: experimental

Literature

Structure of Gh-TDH in complex with a duplex DNA with 2 nucleotide 5'-overhang at 1.37 angstrom resolution

Hsiao, P.Y., Wu, T.K., Chang, C.Y.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: native gel electrophoresis

Macromolecule Content

• Total Structure Weight: 22.31 kDa
• Atom Count: 1,755
• Modeled Residue Count: 171
• Deposited Residue Count: 177
• Unique protein chains: 1
• Unique nucleic acid chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hemolysin, heat labile	A	165	Grimontia hollisae	Mutation(s): 0
UniProt
Find proteins for P14711 (Grimontia hollisae) Explore P14711  Go to UniProtKB:  P14711

Entity ID: 2
Molecule	Chains	Length	Organism	Image
DNA (5'-D(*CP*TP*CP*AP*CP*TP*AP*TP*AP*GP*GP*G)-3')	B	12	synthetic construct

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.37 Å
• R-Value Free:  0.199 (Depositor), 0.199 (DCC)
• R-Value Work:  0.186 (Depositor), 0.186 (DCC)
• R-Value Observed: 0.187 (Depositor)

Space Group: P 4 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 79.706	α = 90
b = 79.706	β = 90
c = 74.849	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data collection
HKL-2000	data scaling
MOLREP	phasing
HKL-2000	data reduction

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2025-12-31
Deposition Author(s): Hsiao, P.Y., Wu, T.K., Chang, C.Y.

---

Funding Organization	Location	Grant Number
National Science Council (NSC, Taiwan)	Taiwan	--

Revision History

• Version 1.0: 2025-12-31
  Type: Initial release
