9L44 | pdb_00009l44

Neuraminidase of A/dairy cow/Minnesota/24_016288-003/2024 H5N1

PDB DOI: https://doi.org/10.2210/pdb9L44/pdb
EM Map EMD-62805: EMDB EMDataResource

Classification: VIRAL PROTEIN
Organism(s): Influenza A virus
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2024-12-19 Released: 2025-07-02
Deposition Author(s): Wang, X., Ge, J., Li, X.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.02 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9L44

This is version 1.0 of the entry. See complete history.

Literature

Neuraminidase of A/dairy cow/Minnesota/24_016288-003/2024 H5N1

Wang, X., Ge, J., Li, X.

To be published.

Macromolecule Content

Total Structure Weight: 173.27 kDa
Atom Count: 12,124
Modeled Residue Count: 1,548
Deposited Residue Count: 1,548
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Neuraminidase	A, B, C, D	387	Influenza A virus	Mutation(s): 0 Gene Names: NA EC: 3.2.1.18
UniProt
Find proteins for A0A8K1VZ50 (Influenza A virus) Explore A0A8K1VZ50 Go to UniProtKB: A0A8K1VZ50
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A8K1VZ50
Glycosylation
Glycosylation Sites: 3	Glycosylation Focus chain A Focus chain B Focus chain C Focus chain D
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG (Subject of Investigation/LOI) Query on NAG Download:Ideal Coordinates CCD File SDF format, chain V [auth D] SDF format, chain U [auth D] SDF format, chain T [auth D] SDF format, chain Q [auth C] SDF format, chain P [auth C] SDF format, chain O [auth C] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain V [auth D] MOL2 format, chain U [auth D] MOL2 format, chain T [auth D] MOL2 format, chain Q [auth C] MOL2 format, chain P [auth C] MOL2 format, chain O [auth C] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain V [auth D] mmCIF format, chain U [auth D] mmCIF format, chain T [auth D] mmCIF format, chain Q [auth C] mmCIF format, chain P [auth C] mmCIF format, chain O [auth C] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A] F [auth A] G [auth A] J [auth B] K [auth B] E [auth A], F [auth A], G [auth A], J [auth B], K [auth B], L [auth B], O [auth C], P [auth C], Q [auth C], T [auth D], U [auth D], V [auth D]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth C] Focus chain T [auth D] Focus chain U [auth D] Focus chain V [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth C] Focus chain T [auth D] Focus chain U [auth D] Focus chain V [auth D]
CA (Subject of Investigation/LOI) Query on CA Download:Ideal Coordinates CCD File SDF format, chain X [auth D] SDF format, chain W [auth D] SDF format, chain S [auth C] SDF format, chain R [auth C] SDF format, chain N [auth B] SDF format, chain M [auth B] SDF format, chain I [auth A] SDF format, chain H [auth A] MOL2 format, chain X [auth D] MOL2 format, chain W [auth D] MOL2 format, chain S [auth C] MOL2 format, chain R [auth C] MOL2 format, chain N [auth B] MOL2 format, chain M [auth B] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] mmCIF format, chain X [auth D] mmCIF format, chain W [auth D] mmCIF format, chain S [auth C] mmCIF format, chain R [auth C] mmCIF format, chain N [auth B] mmCIF format, chain M [auth B] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A]	H [auth A] I [auth A] M [auth B] N [auth B] R [auth C] H [auth A], I [auth A], M [auth B], N [auth B], R [auth C], S [auth C], W [auth D], X [auth D]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain R [auth C] Focus chain S [auth C] Focus chain W [auth D] Focus chain X [auth D] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain R [auth C] Focus chain S [auth C] Focus chain W [auth D] Focus chain X [auth D]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.02 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-07-02

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2025-07-02
Type: Initial release
