9KU5 | pdb_00009ku5

Crystal structure of substrate bound GH5_22 exo-beta-xylosidase from the seaweed-derived thermophile Geobacillus thermodenitrificans OS27


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.52 Å
  • R-Value Free:
    0.194 (Depositor), 0.191 (DCC)
  • R-Value Work:
    0.161 (Depositor), 0.158 (DCC)
  • R-Value Observed:
    0.163 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9KU5

This is version 1.1 of the entry. See complete history

Literature

Structural and biochemical characterization of a GH5_22 enzyme from the seaweed-derived thermophile Geobacillus thermodenitrificans OS27.

Lee, W.Hino, T.Fujii, K.Tanimoto, S.Naka, R.Hara, K.Okamoto, T.Okazaki, F.Nagano, S.Ohshiro, T.Suzuki, H.

(2026) Arch Biochem Biophys 778: 110736-110736

  • DOI: https://doi.org/10.1016/j.abb.2026.110736
  • Primary Citation Related Structures:
    9KU5, 9KUA

  • PubMed Abstract:

    Geobacillus thermodenitrificans OS27 is a seaweed-derived thermophile that harbors a GH5_22 gene (bxlA) that encodes for a glycoside hydrolase fused with the cyclin box domain. In this study, we characterized the catalytic activity, enzymatic properties, three-dimensional structure, and physiological role of the gene product, GtBxlA. The enzyme was produced as a thermostable dimer, acting on p-nitrophenyl-β-d-xylopyranoside among 23 substrates. β-1,4-Linked xylooligosaccharides were also hydrolyzed from the nonreducing end. The activity indicated that GtBxlA functions as an exo-β-1,4-xylosidase. We determined the crystal structure of the Glu188Ala variant complexed with β-1,4-xylotriose at 1.52 Å resolution. GtBxlA exhibited an atypical (β/α) 8 -barrel architecture. The cyclin box constituted a single α-helix within the core barrel and a lid-like domain that contributes to dimer formation. Structural analysis revealed that Glu188 and Glu318 are positioned to serve as the acid/base and nucleophile catalysts, respectively. Alanine mutagenesis confirmed the essential role of Glu188 and Glu318 in catalysis. We also determined the ligand-free structure of the Glu188Ala variant. Both structures were almost identical; however, a loop at the substrate entry site was fixed in the ligand-free structure, suggesting a conformational change upon substrate binding. Although bxlA deletion did not affect β-1,4-xylan utilization, its expression was induced by β-1,4-xylan. These observations suggest that G. thermodenitrificans OS27 employed GtBxlA in utilizing β-1,4-xylan. Notably, GtBxlA could hydrolyze β-1,3-linked xylooligosaccharides. This highlights the possibility that GtBxlA also assists the host in utilizing β-1,3-xylan, which is abundant in certain seaweeds.


  • Organizational Affiliation
    • Department of Engineering, Graduate School of Sustainability Science, Tottori University, 4-101 Koyama-Minami, Tottori 680-8552, Japan.

Macromolecule Content

  • Total Structure Weight: 119.56 kDa
  • Atom Count: 8,841
  • Modeled Residue Count: 957
  • Deposited Residue Count: 1,026
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Glycoside hydrolase
A, B
513Geobacillus thermodenitrificansMutation(s): 1
Gene Names: GEPA3_1816

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
beta-D-xylopyranose-(1-4)-beta-D-xylopyranose
C, D
2N/A
Glycosylation Resources
GlyTouCan: G87728WL
GlyCosmos: G87728WL

Biologically Interesting Molecules (External Reference)

1 Unique

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.52 Å
  • R-Value Free:  0.194 (Depositor), 0.191 (DCC)
  • R-Value Work:  0.161 (Depositor), 0.158 (DCC)
  • R-Value Observed: 0.163 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 89.479α = 90
b = 92.01β = 90
c = 106.326γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Cootmodel building
Aimlessdata scaling
MoRDaphasing
XDSdata reduction

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of Science (JSPS)JapanKAKENHI (25450105)

Revision History  (Full details and data files)

  • Version 1.0: 2026-02-04
    Type: Initial release
  • Version 1.1: 2026-02-18
    Changes: Database references
