9K9S | pdb_00009k9s

MPXV DNA polymerase in complex with primer/4U template DNA

• PDB DOI: https://doi.org/10.2210/pdb9K9S/pdb
• EM Map EMD-62197: EMDB EMDataResource
• NAKB: 9K9S

• Classification: REPLICATION/DNA
• Organism(s): Monkeypox virus
• Expression System: Spodoptera
• Mutation(s): Yes


• Deposited: 2024-10-27 Released: 2025-03-05
• Deposition Author(s): Xie, Y.F., Kuai, L., Peng, Q., Wang, Q., Wang, H., Li, X.M., Qi, J.X., Ding, Q., Shi, Y., Gao, F.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 2.39 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

MPXV DNA polymerase in complex with primer/4U template DNA

Xie, Y.F., Kuai, L., Peng, Q., Wang, Q., Wang, H., Li, X.M., Qi, J.X., Ding, Q., Shi, Y., Gao, F.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 213.92 kDa
• Atom Count: 14,241
• Modelled Residue Count: 1,682
• Deposited Residue Count: 1,738
• Unique protein chains: 3
• Unique nucleic acid chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA polymerase	A	1,031	Monkeypox virus	Mutation(s): 2  Gene Names: OPG071, POL, MPXVgp056 EC: 2.7.7.7
UniProt
Find proteins for A0A7H0DN44 (Monkeypox virus) Explore A0A7H0DN44  Go to UniProtKB:  A0A7H0DN44

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
E4R	B	218	Monkeypox virus	Mutation(s): 0  Gene Names:  E4R, UNG, MPXV-CAM1990_02-093, MPXV-Congo_8-094, MPXV-COP-095, MPXV-GAB1988_001-094, MPXV-Ikubi-093, MPXV-M2940_FCT-099, MPXV-M2957_Lagos-099, MPXV-M3021_Delta-099, MPXV-M5320_M15_Bayelsa-092, MPXV-Nig_SEV71_2_82-094, MPXV-PCH-096, MPXV-Singapore-099, MPXV-SL-095, MPXV-UK_P1-099, MPXV-UK_P2-099, MPXV-UK_P3-099, MPXV-USA2003_099_GR-099, MPXV-USA2003_206_DM-099, MPXV-USA2003_223_RS-099, MPXV-UTC-090, MPXV-W_Nigeria-094, MPXV-WRAIR095, MPXV297957_090, MPXV298464_081, MPXV_DRC_Yandongi_102, MPXV_LIB1970_184_106, MPXV_RCG2003_358_106, MPXV_SUD2005_01_102, MPXV_USA2003_039_106, MPXV_USA2003_044_106, MPXV_ZAI1979_005_106, MPXVgp101, PDLMKLCO_00104 EC: 3.2.2.27
UniProt
Find proteins for M1LL92 (Monkeypox virus) Explore M1LL92  Go to UniProtKB:  M1LL92

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA polymerase processivity factor component A20	C	426	Monkeypox virus	Mutation(s): 0  Gene Names:  A22R, MPXV-COP-126, MPXV-M2940_FCT-131, MPXV-M2957_Lagos-131, MPXV-M3021_Delta-131, MPXV-M5320_M15_Bayelsa-124, MPXV-Nig_SEV71_2_82-126, MPXV-PCH-128, MPXV-Singapore-131, MPXV-SL-126, MPXV-UK_P1-131, MPXV-UK_P2-131, MPXV-UK_P3-131, MPXV-USA2003_099_GR-131, MPXV-USA2003_206_DM-131, MPXV-USA2003_223_RS-131, MPXV-UTC-122, MPXV-W_Nigeria-126, MPXV-WRAIR126, MPXV297957_122, MPXV298464_113, MPXV_LIB1970_184_138, MPXV_USA2003_039_138, MPXV_USA2003_044_138, PDLMKLCO_00135
UniProt
Find proteins for A0A7H0DNC0 (Monkeypox virus) Explore A0A7H0DNC0  Go to UniProtKB:  A0A7H0DNC0

Entity ID: 4
Molecule	Chains	Length	Organism	Image
DNA (25-MER)	D [auth P]	25	Monkeypox virus

Entity ID: 5
Molecule	Chains	Length	Organism	Image
DNA (4U 38-MER)	E [auth T]	38	Monkeypox virus

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
TTP (Subject of Investigation/LOI)	G [auth A]	THYMIDINE-5'-TRIPHOSPHATE C10 H17 N2 O14 P3 NHVNXKFIZYSCEB-XLPZGREQSA-N
MG (Subject of Investigation/LOI)	F [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 2.39 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-03-05
Deposition Author(s): Xie, Y.F., Kuai, L., Peng, Q., Wang, Q., Wang, H., Li, X.M., Qi, J.X., Ding, Q., Shi, Y., Gao, F.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History

• Version 1.0: 2025-03-05
  Type: Initial release
