9K8Y | pdb_00009k8y

Structure of PfENT1(T144C,K375C,N60R,Q266R) with inosine- outward-facing state

PDB DOI: https://doi.org/10.2210/pdb9K8Y/pdb
EM Map EMD-62182: EMDB EMDataResource

Classification: TRANSPORT PROTEIN
Organism(s): Plasmodium falciparum 3D7
Expression System: Spodoptera frugiperda
Mutation(s): Yes

Deposited: 2024-10-25 Released: 2026-04-29
Deposition Author(s): Chen, X.Y., Li, J.L., Wang, X., Deng, D.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.76 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9K8Y

This is version 1.0 of the entry. See complete history.

Literature

Structure of PfENT1(T144C,K375C,N60R,Q266R) with inosine- outward-facing state

Chen, X.Y., Li, J.L., Wang, X., Deng, D.

To be published.

Macromolecule Content

Total Structure Weight: 42.94 kDa
Atom Count: 2,888
Modeled Residue Count: 361
Deposited Residue Count: 376
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Nucleoside transporter 1	A	376	Plasmodium falciparum 3D7	Mutation(s): 4 Gene Names: NT1, PF3D7_1347200
UniProt
Find proteins for Q8IDM6 (Plasmodium falciparum (isolate 3D7)) Explore Q8IDM6 Go to UniProtKB: Q8IDM6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8IDM6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NOS (Subject of Investigation/LOI) Query on NOS Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	INOSINE C₁₀ H₁₂ N₄ O₅ UGQMRVRMYYASKQ-KQYNXXCUSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.76 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-04-29

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	3217110258

Revision History (Full details and data files)

Version 1.0: 2026-04-29
Type: Initial release
