9HRT | pdb_00009hrt

Structure of human PD-L1 in complex with clinically evaluated inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:
    0.263 (Depositor), 0.267 (DCC)
  • R-Value Work:
    0.207 (Depositor), 0.216 (DCC)
  • R-Value Observed:
    0.209 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9HRT

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Characterization of Clinically Evaluated Small-Molecule Inhibitors of PD-L1 for Immunotherapy.

Slota, A.Golebiowska-Mendroch, K.Kocik-Krol, J.Musielak, B.Stec, M.Weglarczyk, K.Siedlar, M.Skalniak, L.Plewka, J.Magiera-Mularz, K.

(2025) ACS Med Chem Lett 16: 1359-1364

  • DOI: https://doi.org/10.1021/acsmedchemlett.5c00245
  • Primary Citation Related Structures:
    9HRT, 9I0U, 9I0W

  • PubMed Abstract:

    Cancer immunotherapy aims to employ the immune system to target cancer cells. The PD-1/PD-L1 axis is a critical immune checkpoint that tumors exploit to evade immune surveillance. In this study, we characterized three small-molecule PD-L1 inhibitors, Evixapodlin, MAX-10181, and INCB086550, currently undergoing clinical trials for cancers such as non-small cell lung cancer, renal cell carcinoma, urothelial carcinoma, hepatocellular carcinoma, and melanoma. Using the homogeneous time resolved fluorescence assay, we confirmed that each compound potently disrupts human PD-1/PD-L1 binding with IC 50 values in the nanomolar range. PD-L1 oligomerization upon inhibitor binding was demonstrated through NMR analysis and confirmed by X-ray crystallography, which finally elucidated the binding interactions that stabilize these inhibitors at the PD-L1 interface. Cellular assays revealed dose-dependent T-cell activation, demonstrating the immunomodulatory potential of each compound and its cytotoxicity profiles. These findings underscore the promise of small-molecule PD-L1 inhibitors as viable alternatives to antibody-based therapies in cancer immunotherapy.


  • Organizational Affiliation
    • Jagiellonian University, Faculty of Chemistry, Department of Organic Chemistry, Gronostajowa 2, 30-387 Krakow, Poland.

Macromolecule Content

  • Total Structure Weight: 30.44 kDa
  • Atom Count: 2,100
  • Modeled Residue Count: 252
  • Deposited Residue Count: 262
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Programmed cell death 1 ligand 1
A, B
131Homo sapiensMutation(s): 0
Gene Names: CD274B7H1PDCD1L1PDCD1LG1PDL1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NZQ7 (Homo sapiens)
Explore Q9NZQ7
Go to UniProtKB:  Q9NZQ7
PHAROS:  Q9NZQ7
GTEx:  ENSG00000120217
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NZQ7
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1IXH
(Subject of Investigation/LOI)

Query on A1IXH



Download:Ideal Coordinates CCD File
C [auth B](2~{R})-2-[[3-[(~{E})-2-[3-(2,3-dihydro-1,4-benzodioxin-6-yl)-2-methyl-phenyl]ethenyl]-4-(trifluoromethyl)phenyl]methylamino]-2-methyl-3-oxidanyl-propanoic acid
C29 H28 F3 N O5
PTGUEPRQUFAZLN-UWSNOUECSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:  0.263 (Depositor), 0.267 (DCC)
  • R-Value Work:  0.207 (Depositor), 0.216 (DCC)
  • R-Value Observed: 0.209 (Depositor)
Space Group: P 21 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 50.859α = 90
b = 52.03β = 90
c = 111.318γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Polish National Science CentrePoland2021/43/B/NZ7/03170

Revision History  (Full details and data files)

  • Version 1.0: 2025-06-18
    Type: Initial release
  • Version 1.1: 2025-07-30
    Changes: Database references
