9HAG | pdb_00009hag

De novo designed beta barrel fold BBF-14

PDB DOI: https://doi.org/10.2210/pdb9HAG/pdb

Classification: DE NOVO PROTEIN
Organism(s): synthetic construct
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-11-03 Released: 2024-12-18
Deposition Author(s): Pacesa, M., Correia, B.E.
Funding Organization(s): Swiss National Science Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.86 Å
R-Value Free:
0.229 (Depositor), 0.229 (DCC)
R-Value Work:
0.215 (Depositor), 0.215 (DCC)
R-Value Observed:
0.215 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9HAG

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Structural characterization of a designed beta barrel protein with a hydrophobic pore

Pacesa, M., Goverde, C.A., Schellhaas, C., Georgeon, S., Correia, B.E.

To be published.

Macromolecule Content

Total Structure Weight: 13.76 kDa
Atom Count: 948
Modeled Residue Count: 112
Deposited Residue Count: 122
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
BBF-14	A	122	synthetic construct	Mutation(s): 0

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
P6G (Subject of Investigation/LOI) Query on P6G Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	HEXAETHYLENE GLYCOL C₁₂ H₂₆ O₇ IIRDTKBZINWQAW-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
K Query on K Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	POTASSIUM ION K NPYPAHLBTDXSSS-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.86 Å
R-Value Free: 0.229 (Depositor), 0.229 (DCC)
R-Value Work: 0.215 (Depositor), 0.215 (DCC)
R-Value Observed: 0.215 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 35.14	α = 90
b = 51.28	β = 90
c = 70.72	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-12-18

Deposition Author(s):

Funding Organization	Location	Grant Number
Swiss National Science Foundation		--

Revision History (Full details and data files)

Version 1.0: 2024-12-18
Type: Initial release
