RCSB PDB - 9HA3: Pooled 50S subunit C_(L22)-~H61 precursor states supplemented with Api137

 9HA3

Pooled 50S subunit C_(L22)-~H61 precursor states supplemented with Api137


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.62 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

The proline-rich antimicrobial peptide Api137 disrupts large ribosomal subunit assembly and induces misfolding.

Lauer, S.M.Gasse, J.Krizsan, A.Reepmeyer, M.Sprink, T.Nikolay, R.Spahn, C.M.T.Hoffmann, R.

(2025) Nat Commun 16: 567-567

  • DOI: https://doi.org/10.1038/s41467-025-55836-8
  • Primary Citation of Related Structures:
    9H3K, 9H3L, 9H3M, 9H3N, 9H3O, 9H3P, 9H3Q, 9H3R, 9H3S, 9H3T, 9H3U, 9H3V, 9H3W, 9H3Y, 9H3Z, 9HA1, 9HA2, 9HA3, 9HA5, 9HA6, 9HA7, 9HAI, 9HAL, 9HAM

  • PubMed Abstract:

    The proline-rich antimicrobial designer peptide Api137 inhibits protein expression in bacteria by binding simultaneously to the ribosomal polypeptide exit tunnel and the release factor (RF), depleting the cellular RF pool and leading to ribosomal arrest at stop codons. This study investigates the additional effect of Api137 on the assembly of ribosomes using an Escherichia coli reporter strain expressing one ribosomal protein per 30S and 50S subunit tagged with mCherry and EGFP, respectively. Separation of cellular extracts derived from cells exposed to Api137 in a sucrose gradient reveals elevated levels of partially assembled and not fully matured precursors of the 50S subunit (pre-50S). High-resolution structures obtained by cryogenic electron microscopy demonstrate that a large proportion of pre-50S states are missing up to five proteins (uL22, bL32, uL29, bL23, and uL16) and have misfolded helices in 23S rRNA domain IV. These data suggest a second mechanism for Api137, wherein it disrupts 50S subunit assembly by inducing the formation of misfolded precursor particles potentially incapable of evolving into active ribosomes, suggesting a bactericidal mechanism.


  • Organizational Affiliation

    Institut für Medizinische Physik und Biophysik, Charité - Universitätsmedizin Berlin, corporate member of Freie Universität Berlin and Humboldt Universität zu Berlin, Berlin, Germany.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein bL34A [auth 2]46Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7P5 (Escherichia coli (strain K12))
Explore P0A7P5
Go to UniProtKB:  P0A7P5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7P5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL13B [auth J]142Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AA10 (Escherichia coli (strain K12))
Explore P0AA10
Go to UniProtKB:  P0AA10
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AA10
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein bL20C [auth Q]117Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7L3 (Escherichia coli (strain K12))
Explore P0A7L3
Go to UniProtKB:  P0A7L3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7L3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein bL21D [auth R]103Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AG48 (Escherichia coli (strain K12))
Explore P0AG48
Go to UniProtKB:  P0AG48
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG48
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL23E [auth T]93Escherichia coliMutation(s): 0
UniProt
Find proteins for P0ADZ0 (Escherichia coli (strain K12))
Explore P0ADZ0
Go to UniProtKB:  P0ADZ0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ADZ0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL24F [auth U]102Escherichia coliMutation(s): 0
UniProt
Find proteins for P60624 (Escherichia coli (strain K12))
Explore P60624
Go to UniProtKB:  P60624
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60624
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL29G [auth Y]63Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7M6 (Escherichia coli (strain K12))
Explore P0A7M6
Go to UniProtKB:  P0A7M6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7M6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL30H [auth Z]58Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AG51 (Escherichia coli (strain K12))
Explore P0AG51
Go to UniProtKB:  P0AG51
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG51
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L3J [auth D]209Escherichia coliMutation(s): 0
UniProt
Find proteins for P60438 (Escherichia coli (strain K12))
Explore P60438
Go to UniProtKB:  P60438
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60438
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL4K [auth E]201Escherichia coliMutation(s): 0
UniProt
Find proteins for P60723 (Escherichia coli (strain K12))
Explore P60723
Go to UniProtKB:  P60723
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60723
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL15143Escherichia coliMutation(s): 0
UniProt
Find proteins for P02413 (Escherichia coli (strain K12))
Explore P02413
Go to UniProtKB:  P02413
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02413
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein bL17M [auth N]120Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AG44 (Escherichia coli (strain K12))
Explore P0AG44
Go to UniProtKB:  P0AG44
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG44
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
Apidaecins type 22N [auth y]17Apis melliferaMutation(s): 0
UniProt
Find proteins for P35581 (Apis mellifera)
Explore P35581
Go to UniProtKB:  P35581
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP35581
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.62 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Federal Ministry for Education and ResearchGermany16GW0300
German Federal Ministry for Education and ResearchGermany16GW0299K
German Research Foundation (DFG)GermanyEXC2008/1-390540038
German Research Foundation (DFG)GermanyINST 335/588-1 FUGG

Revision History  (Full details and data files)

  • Version 1.0: 2025-01-22
    Type: Initial release
