9GQP | pdb_00009gqp

Structural characterization of a N-acetyl-beta-neuraminic acid-binding site in human RNase2

PDB DOI: https://doi.org/10.2210/pdb9GQP/pdb

Classification: PROTEIN BINDING
Organism(s): Homo sapiens
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): No

Deposited: 2024-09-09 Released: 2026-03-18
Deposition Author(s): Xincheng, K., Jiarui, L., Prats-Ejarque, G., Boix, E.
Funding Organization(s): Agencia Estatal de Investigacion (AEI)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.01 Å
R-Value Free:
0.151 (Depositor), 0.151 (DCC)
R-Value Work:
0.135 (Depositor), 0.135 (DCC)
R-Value Observed:
0.135 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Structural basis for saccharide binding by human RNase 2/EDN, a protein combining enzymatic and lectin properties

Kang, X., Prats-Ejarque, G., Boix, E., Li, J.

(2026) bioRxiv

DOI: https://doi.org/10.64898/2026.03.20.713198

Macromolecule Content

Total Structure Weight: 17.19 kDa
Atom Count: 1,496
Modeled Residue Count: 135
Deposited Residue Count: 135
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Non-secretory ribonuclease	A	135	Homo sapiens	Mutation(s): 0 Gene Names: RNASE2, EDN, RNS2 EC: 4.6.1.18
UniProt & NIH Common Fund Data Resources
Find proteins for P10153 (Homo sapiens) Explore P10153 Go to UniProtKB: P10153
PHAROS: P10153 GTEx: ENSG00000169385
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P10153
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SLB (Subject of Investigation/LOI) Query on SLB Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain G [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain G [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A], D [auth A], G [auth A]	N-acetyl-beta-neuraminic acid C₁₁ H₁₉ N O₉ SQVRNKJHWKZAKO-PFQGKNLYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain G [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain G [auth A]
B3P Query on B3P Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	2-[3-(2-HYDROXY-1,1-DIHYDROXYMETHYL-ETHYLAMINO)-PROPYLAMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C₁₁ H₂₆ N₂ O₆ HHKZCCWKTZRCCL-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]
