9FYJ | pdb_00009fyj

N-terminal domain of human galectin-8 in complex with an alpha-galactoside ligand


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.08 Å
  • R-Value Free:
    0.150 (Depositor), 0.161 (DCC)
  • R-Value Work:
    0.132 (Depositor), 0.149 (DCC)
  • R-Value Observed:
    0.133 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9FYJ

Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history

Literature

Nanomolar inhibitor of the galectin-8 N-terminal domain binds via a non-canonical cation-pi interaction.

Puric, E.Hassan, M.Sjovall, F.Tomasic, T.Pevec, M.Lah, J.Forteza, J.A.Sundin, A.Leffler, H.Nilsson, U.J.Logan, D.T.Anderluh, M.

(2025) Commun Chem 8: 59-59

  • DOI: https://doi.org/10.1038/s42004-025-01458-6
  • Primary Citation Related Structures:
    9FYJ

  • PubMed Abstract:

    Galectin-8 is a tandem-repeat galectin consisting of two distinct carbohydrate recognition domains and is a potential drug target. We have developed a library of galectin-8N inhibitors that exhibit high nanomolar K d values as determined by a competitive fluorescence polarization assay. A detailed thermodynamic analysis of the binding of D-galactosides to galectin-8N by isothermal titration calorimetry reveals important differences in enthalpic and/or entropic contributions to binding. Contrary to expectations, the binding of 2-O-propargyl-D-galactoside was found to strongly increase the binding enthalpy, whereas the binding of 2-O-carboxymethylene-D-galactoside was surprisingly less enthalpy-driven. The results of our work suggest that the ethynyl group can successfully replace the carboxylate group when targeting the water-exposed guanidine moiety of a critical arginine residue. This results in only a minor loss of affinity and an adjusted enthalpic contribution to the overall binding due to non-canonical cation-π interactions, as evidenced by the obtained crystal structure of 2-O-propargyl-D-galactoside in complex with the N-terminal domain of galectin-8. Such an interaction has neither been identified nor discussed to date in a small-molecule ligand-protein complex.


  • Organizational Affiliation
    • Department of Pharmaceutical Chemistry, Faculty of Pharmacy, University of Ljubljana, Ljubljana, Slovenia.

Macromolecule Content

  • Total Structure Weight: 35.73 kDa
  • Atom Count: 2,894
  • Modeled Residue Count: 298
  • Deposited Residue Count: 306
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Isoform 1 of Galectin-8
A, B
153Homo sapiensMutation(s): 0
Gene Names: LGALS8
UniProt & NIH Common Fund Data Resources
Find proteins for O00214 (Homo sapiens)
Explore O00214
Go to UniProtKB:  O00214
PHAROS:  O00214
GTEx:  ENSG00000116977
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO00214
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1IHE
(Subject of Investigation/LOI)

Query on A1IHE



Download:Ideal Coordinates CCD File
C [auth A],
E [auth B]
2-[[(2~{R},3~{R},4~{S},5~{S},6~{R})-2-(3,4-dichlorophenyl)sulfanyl-6-(hydroxymethyl)-5-oxidanyl-3-prop-2-ynoxy-oxan-4-yl]oxymethyl]-3-methyl-benzimidazole-5-carboxylic acid
C25 H24 Cl2 N2 O7 S
QFRHUULPFZESGE-BQYMIBSYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
D [auth A]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.08 Å
  • R-Value Free:  0.150 (Depositor), 0.161 (DCC)
  • R-Value Work:  0.132 (Depositor), 0.149 (DCC)
  • R-Value Observed: 0.133 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 53.689α = 90
b = 62.28β = 90
c = 84.791γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
EDNAdata collection
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
H2020 Marie Curie Actions of the European CommissionEuropean Union765581
European Union (EU)European UnionEUTOPIA PhD Co-tutelle grant
Swedish Research CouncilSweden2020-03317
Swedish Research CouncilSweden2016-04855
Slovenian Research AgencySloveniaP1-0208
Slovenian Research AgencySloveniaJ1-50026
European Cooperation in Science and Technology (COST) actionEuropean UnionCA18103
European Cooperation in Science and Technology (COST) actionEuropean UnionCA18132
European Regional Development FundEuropean UnionOP20.05187 RI-SI-EATRIS

Revision History  (Full details and data files)

  • Version 1.0: 2025-03-12
    Type: Initial release
