9FXV | pdb_00009fxv

Influenza polymerase A C-terminal domain of PA subunit with peptide inhibitor containing two norleucines

PDB DOI: https://doi.org/10.2210/pdb9FXV/pdb

Classification: VIRAL PROTEIN
Organism(s): Influenza A virus (A/California/07/2009(H1N1)), synthetic construct
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-07-02 Released: 2025-07-16
Deposition Author(s): Radilova, K., Brynda, J.
Funding Organization(s): European Union (EU)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.279 (Depositor), 0.241 (DCC)
R-Value Work:
0.242 (Depositor)
R-Value Observed:
0.243 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9FXV

This is version 1.0 of the entry. See complete history.

Literature

Influenza polymerase A C-terminal domain of PA subunit

Radilova, K., Zima, V., Brynda, J., Konvalinka, J., Machara, A., Kozisek, M.

To be published.

Macromolecule Content

Total Structure Weight: 54.5 kDa
Atom Count: 3,564
Modeled Residue Count: 430
Deposited Residue Count: 471
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Polymerase acidic protein	A	461	Influenza A virus (A/California/07/2009(H1N1))	Mutation(s): 0 Gene Names: PA EC: 3.1
UniProt
Find proteins for D4HI62 (Influenza A virus) Explore D4HI62 Go to UniProtKB: D4HI62
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	D4HI62
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Peptide inhibitor	B	10	synthetic construct	Mutation(s): 0

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PG4 Query on PG4 Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	TETRAETHYLENE GLYCOL C₈ H₁₈ O₅ UWHCKJMYHZGTIT-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
NLE Query on NLE	B	L-PEPTIDE LINKING	C₆ H₁₃ N O₂		LEU

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free: 0.279 (Depositor), 0.241 (DCC)
R-Value Work: 0.242 (Depositor)
R-Value Observed: 0.243 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 37.857	α = 90
b = 119.561	β = 90
c = 123.281	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XSCALE	data scaling
XDS	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-07-16

Deposition Author(s):

Funding Organization	Location	Grant Number
European Union (EU)	European Union	LX22NPO5103

Revision History (Full details and data files)

Version 1.0: 2025-07-16
Type: Initial release
