9CMZ

Crystal Structure of Cdk-related protein kinase 6 (PK6) from Plasmodium falciparum in complex with inhibitor KG2-051

• PDB DOI: https://doi.org/10.2210/pdb9CMZ/pdb

• Classification: TRANSFERASE
• Organism(s): Plasmodium falciparum 3D7
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2024-07-15 Released: 2024-07-24
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Institutes of Health/Office of the Director

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.45 Å
• R-Value Free: 0.255
• R-Value Work: 0.220
• R-Value Observed: 0.221

Starting Model: experimental

Literature

Crystal Structure of Cdk-related protein kinase 6 (PK6) from Plasmodium falciparum in complex with inhibitor KG2-051

Seibold, S., Lovell, S., Mian, M.R.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors.

Macromolecule Content

• Total Structure Weight: 109.48 kDa
• Atom Count: 6,826
• Modelled Residue Count: 833
• Deposited Residue Count: 918
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein kinase 6	A, B, C	306	Plasmodium falciparum 3D7	Mutation(s): 5  Gene Names: PF3D7_1337100 EC: 2.7.11.22
UniProt
Find proteins for Q8IDW1 (Plasmodium falciparum (isolate 3D7)) Explore Q8IDW1  Go to UniProtKB:  Q8IDW1

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
A1AZE (Subject of Investigation/LOI)	H [auth A], K [auth B], M [auth C]	(4-{[5-chloro-4-(5-chlorothiophen-2-yl)pyrimidin-2-yl]amino}phenyl)[4-(pyrrolidin-1-yl)piperidin-1-yl]methanone C24 H25 Cl2 N5 O S SZKUPGRFEZHAPU-UHFFFAOYSA-N
SO4	G [auth A], J [auth B], L [auth C]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
CL	D [auth A], E [auth A], F [auth A], I [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.45 Å
• R-Value Free: 0.255
• R-Value Work: 0.220
• R-Value Observed: 0.221
• Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 77.539	α = 90
b = 99.428	β = 100.78
c = 78.148	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-07-24
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	75N93022C00036
National Institutes of Health/Office of the Director	United States	S10OD030394

Revision History

• Version 1.0: 2024-07-24
  Type: Initial release
