9BWU | pdb_00009bwu

Glutarate L-2-hydroxylase (CsiD/GlaH) from Escherichia coli at 2.20 Angstroms Resolution

PDB DOI: https://doi.org/10.2210/pdb9BWU/pdb

Classification: METAL BINDING PROTEIN
Organism(s): Escherichia coli
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-05-21 Released: 2025-05-28
Deposition Author(s): Han, Z.
Funding Organization(s): National Science Foundation (NSF, United States)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free:
0.226 (Depositor), 0.226 (DCC)
R-Value Work:
0.190 (Depositor), 0.190 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9BWU

This is version 1.1 of the entry. See complete history.

Literature

Diffraction-quality, ultraflexible protein single crystals engineered with DNA

Han, Z., Mirkin, C.A.

(2026) Sci Adv

DOI: https://doi.org/10.1126/sciadv.aeh2948

Macromolecule Content

Total Structure Weight: 37.37 kDa
Atom Count: 2,614
Modeled Residue Count: 290
Deposited Residue Count: 324
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glutarate 2-hydroxylase	A	324	Escherichia coli	Mutation(s): 0 Gene Names: glaH, EcolC_1047 EC: 1.14.11.64
UniProt
Find proteins for P76621 (Escherichia coli (strain K12)) Explore P76621 Go to UniProtKB: P76621
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P76621
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FE2 (Subject of Investigation/LOI) Query on FE2 Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	FE (II) ION Fe CWYNVVGOOAEACU-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free: 0.226 (Depositor), 0.226 (DCC)
R-Value Work: 0.190 (Depositor), 0.190 (DCC)

Space Group: I 4 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 123.83	α = 90
b = 123.83	β = 90
c = 139.03	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
DIALS	data reduction
PHASER	phasing
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-05-28

Deposition Author(s):

Funding Organization	Location	Grant Number
National Science Foundation (NSF, United States)	United States	DMR-2104353

Revision History (Full details and data files)

Version 1.0: 2025-05-28
Type: Initial release
Version 1.1: 2026-07-29
Changes: Database references
