9ATX | pdb_00009atx

AcpB protein from Bacillus anthracis, N-terminal part

PDB DOI: https://doi.org/10.2210/pdb9ATX/pdb

Classification: TRANSCRIPTION
Organism(s): Bacillus anthracis str. Ames
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-02-27 Released: 2024-03-06
Deposition Author(s): Osipiuk, J., Koehler, T.M., Joachimiak, A., Center for Structural Biology of Infectious Diseases (CSBID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.11 Å
R-Value Free:
0.246 (Depositor), 0.248 (DCC)
R-Value Work:
0.201 (Depositor), 0.207 (DCC)
R-Value Observed:
0.203 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 9ATX

This is version 1.1 of the entry. See complete history.

Literature

AcpB protein from Bacillus anthracis, N-terminal part

Osipiuk, J., Koehler, T.M., Joachimiak, A., Center for Structural Biology of Infectious Diseases (CSBID)

To be published.

Macromolecule Content

Total Structure Weight: 33 kDa
Atom Count: 2,344
Modeled Residue Count: 268
Deposited Residue Count: 275
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Capsule synthesis positive regulator AcpB	A	275	Bacillus anthracis str. Ames	Mutation(s): 0 Gene Names: acpB, pXO2-53, BXB0060, GBAA_pXO2_0060
UniProt
Find proteins for Q9RMX9 (Bacillus anthracis) Explore Q9RMX9 Go to UniProtKB: Q9RMX9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9RMX9
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.11 Å
R-Value Free: 0.246 (Depositor), 0.248 (DCC)
R-Value Work: 0.201 (Depositor), 0.207 (DCC)
R-Value Observed: 0.203 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 46.546	α = 90
b = 63.52	β = 90
c = 119.426	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-3000	data scaling
HKL-3000	data reduction
HKL-3000	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-03-06

Deposition Author(s):

Center for Structural Biology of Infectious Diseases (CSBID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	75N93022C00035
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	R01 AI033537

Revision History (Full details and data files)

Version 1.0: 2024-03-06
Type: Initial release
Version 1.1: 2024-11-20
Changes: Structure summary
