8XFR | pdb_00008xfr

Structure of the alginate epimerase/lyase complexed with tetra-mannuronic acid

PDB DOI: https://doi.org/10.2210/pdb8XFR/pdb

Classification: ISOMERASE
Organism(s): Azotobacter chroococcum NCIMB 8003
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2023-12-14 Released: 2024-05-15
Deposition Author(s): Fujiwara, T.
Funding Organization(s): Japan Society for the Promotion of Science (JSPS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.186 (Depositor), 0.186 (DCC)
R-Value Work:
0.162 (Depositor), 0.162 (DCC)
R-Value Observed:
0.164 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Structural basis for the minimal bifunctional alginate epimerase AlgE3 from Azotobacter chroococcum.

Fujiwara, T., Mano, E., Nango, E.

(2024) FEBS Lett 598: 1422-1437

PubMed: 38649293 Search on PubMed
DOI: https://doi.org/10.1002/1873-3468.14886
Primary Citation Related Structures:
8JA4, 8JA6, 8JAZ, 8XFQ, 8XFR

PubMed Abstract:
Among the epimerases specific to alginate, some of them in Azotobacter genera convert β-d-mannuronic acid to α-l-guluronic acid but also have lyase activity to degrade alginate. The remarkable characteristics of these epimerases make it a promising enzyme for tailoring alginates to meet specific demands. Here, we determined the structure of the bifunctional mannuronan C-5 epimerase AlgE3 from Azotobacter chroococcum (AcAlgE3) in complex with several mannuronic acid oligomers as well as in apo form, which allowed us to elucidate the binding manner of each mannuronic acid oligomer, and the structural plasticity, which is dependent on calcium ions. Moreover, a comprehensive analysis of the lyase activity profiles of AcAlgE3 combined with structural characteristics explained the preference for different chain length oligomers.

Organizational Affiliation

Institute of Multidisciplinary Research for Advanced Materials, Tohoku University, Sendai, Japan.

Macromolecule Content

Total Structure Weight: 53.32 kDa
Atom Count: 3,855
Modeled Residue Count: 480
Deposited Residue Count: 485
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
mannuronan 5-epimerase	A	485	Azotobacter chroococcum NCIMB 8003	Mutation(s): 0 Gene Names: algE7, Achr_39570 EC: 5.1.3.37
UniProt
Find proteins for A0A0C4WKK2 (Azotobacter chroococcum NCIMB 8003) Explore A0A0C4WKK2 Go to UniProtKB: A0A0C4WKK2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0C4WKK2
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
beta-D-mannopyranuronic acid-(1-4)-beta-D-mannopyranuronic acid-(1-4)-beta-D-mannopyranuronic acid-(1-4)-beta-D-mannopyranuronic acid	B	4		N/A	Interactions Focus chain B Interactions & Density Focus chain B
Glycosylation Resources
GlyTouCan: G72539QT GlyCosmos: G72539QT

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PG4 Query on PG4 Download:Ideal Coordinates CCD File SDF format, chain N [auth A] MOL2 format, chain N [auth A] mmCIF format, chain N [auth A]	N [auth A]	TETRAETHYLENE GLYCOL C₈ H₁₈ O₅ UWHCKJMYHZGTIT-UHFFFAOYSA-N		Interactions Focus chain N [auth A] Interactions & Density Focus chain N [auth A]
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain L [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A]	J [auth A], K [auth A], L [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Interactions & Density Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain M [auth A] MOL2 format, chain M [auth A] mmCIF format, chain M [auth A]	M [auth A]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain M [auth A] Interactions & Density Focus chain M [auth A]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A]
