8WJX

ADP-bound purinergic receptor 1 in complex with miniGs/q

• PDB DOI: https://doi.org/10.2210/pdb8WJX/pdb
• EM Map EMD-37591: EMDB EMDataResource

• Classification: MEMBRANE PROTEIN
• Organism(s): Homo sapiens, Escherichia coli
• Expression System: Escherichia coli, Spodoptera frugiperda
• Mutation(s): No
• Membrane Protein: Yes  PDBTM


• Deposited: 2023-09-26 Released: 2024-10-02
• Deposition Author(s): Gu, Q.C., Tang, W.Q.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.20 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

ADP-bound purinergic receptor 1 in complex with miniGs/q

Gu, Q.C., Tang, W.Q.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 5-mer - A1B1C1D1E1

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 174.22 kDa
• Atom Count: 7,535
• Modelled Residue Count: 1,034
• Deposited Residue Count: 1,550
• Unique protein chains: 5

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
GNAS complex locus	A	265	Homo sapiens	Mutation(s): 0  Gene Names: GNAS EC: 3.6.5 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P63092 (Homo sapiens) Explore P63092  Go to UniProtKB:  P63092
PHAROS:  P63092 GTEx:  ENSG00000087460

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1	B	377	Homo sapiens	Mutation(s): 0  Gene Names: GNB1
UniProt & NIH Common Fund Data Resources
Find proteins for P62873 (Homo sapiens) Explore P62873  Go to UniProtKB:  P62873
PHAROS:  P62873 GTEx:  ENSG00000078369

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2	C [auth G]	71	Homo sapiens	Mutation(s): 0  Gene Names: GNG2 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P59768 (Homo sapiens) Explore P59768  Go to UniProtKB:  P59768
PHAROS:  P59768 GTEx:  ENSG00000186469

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Nanobody 35	D [auth N]	157	Homo sapiens	Mutation(s): 0

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
Soluble cytochrome b562,P2Y purinoceptor 1,Soluble cytochrome b562,P2Y purinoceptor 1	E [auth R]	680	Escherichia coli, Homo sapiens	Mutation(s): 0  Gene Names: cybC, P2RY1 EC: 1.13.12.13 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P0ABE7 (Escherichia coli) Explore P0ABE7  Go to UniProtKB:  P0ABE7
Find proteins for Q9GV45 (Oplophorus gracilirostris) Explore Q9GV45  Go to UniProtKB:  Q9GV45
Find proteins for P47900 (Homo sapiens) Explore P47900  Go to UniProtKB:  P47900
PHAROS:  P47900 GTEx:  ENSG00000169860
UniProt Groups	P0ABE7Q9GV45P47900

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ADP (Subject of Investigation/LOI)	F [auth R]	ADENOSINE-5'-DIPHOSPHATE C10 H15 N5 O10 P2 XTWYTFMLZFPYCI-KQYNXXCUSA-N
CLR (Subject of Investigation/LOI)	G [auth R]	CHOLESTEROL C27 H46 O HVYWMOMLDIMFJA-DPAQBDIFSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.20 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-10-02
Deposition Author(s): Gu, Q.C., Tang, W.Q.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History

• Version 1.0: 2024-10-02
  Type: Initial release

• Version 1.1: 2024-10-23
  Changes: Data collection, Structure summary
