8TOW

Structure of a mutated photosystem II complex reveals perturbation of the oxygen-evolving complex

PDB DOI: https://doi.org/10.2210/pdb8TOW/pdb
EM Map EMD-41460: EMDB EMDataResource

Classification: PHOTOSYNTHESIS
Organism(s): Synechocystis sp. PCC 6803
Mutation(s): No

Deposited: 2023-08-04 Released: 2024-06-19
Deposition Author(s): Flesher, D.A., Liu, J., Wang, J., Gisriel, C.J., Yang, K.R., Batista, V.S., Debus, R.J., Brudvig, G.W.
Funding Organization(s): Department of Energy (DOE, United States)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.14 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Mutation-induced shift of the photosystem II active site reveals insight into conserved water channels

Flesher, D.A., Brudvig, G.W.

To be published.

Macromolecule Content

Total Structure Weight: 816.78 kDa
Atom Count: 54,910
Modelled Residue Count: 5,550
Deposited Residue Count: 5,976
Unique protein chains: 21

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II protein D1 2	A, V [auth a]	360	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P16033 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P16033 Go to UniProtKB: P16033
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P16033
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II CP47 reaction center protein	B, W [auth b]	507	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P05429 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P05429 Go to UniProtKB: P05429
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P05429
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II CP43 reaction center protein	C, X [auth c]	460	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P09193 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P09193 Go to UniProtKB: P09193
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P09193
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II D2 protein	D, Y [auth d]	352	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P09192 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P09192 Go to UniProtKB: P09192
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P09192
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome b559 subunit alpha	E, Z [auth e]	81	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P09190 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P09190 Go to UniProtKB: P09190
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P09190
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 6
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome b559 subunit beta	AA [auth f], F	44	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P09191 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P09191 Go to UniProtKB: P09191
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P09191
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 7
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein H	BA [auth h], G [auth H]	64	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P14835 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P14835 Go to UniProtKB: P14835
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P14835
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 8
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein I	CA [auth i], H [auth I]	38	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for Q54697 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore Q54697 Go to UniProtKB: Q54697
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q54697
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 9
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein J	DA [auth j], I [auth J]	39	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P73070 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P73070 Go to UniProtKB: P73070
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P73070
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 10
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein K	EA [auth k], J [auth K]	45	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P15819 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P15819 Go to UniProtKB: P15819
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P15819
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 11
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein L	FA [auth l], K [auth L]	39	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for Q55354 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore Q55354 Go to UniProtKB: Q55354
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q55354
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 12
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein M	GA [auth m], L [auth M]	35	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P72701 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P72701 Go to UniProtKB: P72701
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P72701
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 13
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II manganese-stabilizing polypeptide	HA [auth o], M [auth O]	274	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P10549 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P10549 Go to UniProtKB: P10549
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P10549
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 14
Molecule	Chains	Sequence Length	Organism	Details	Image
Sll1638 protein	IA [auth q], N [auth Q]	149	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P73048 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P73048 Go to UniProtKB: P73048
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P73048
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 15
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II protein Y	JA [auth r], O [auth R]	39	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P73676 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P73676 Go to UniProtKB: P73676
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P73676
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 16
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein T	KA [auth t], P [auth T]	31	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P74787 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P74787 Go to UniProtKB: P74787
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P74787
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 17
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II 12 kDa extrinsic protein	LA [auth u], Q [auth U]	131	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for Q55332 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore Q55332 Go to UniProtKB: Q55332
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q55332
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 18
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome c-550	MA [auth v], R [auth V]	160	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for Q55013 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore Q55013 Go to UniProtKB: Q55013
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q55013
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 19
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center X protein	NA [auth x], S [auth X]	39	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P72575 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P72575 Go to UniProtKB: P72575
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P72575
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 20
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein Ycf12	OA [auth y], T [auth Y]	39	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for Q55438 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore Q55438 Go to UniProtKB: Q55438
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q55438
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 21
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein Z	PA [auth z], U [auth Z]	62	Synechocystis sp. PCC 6803	Mutation(s): 0
UniProt
Find proteins for P73528 (Synechocystis sp. (strain PCC 6803 / Kazusa)) Explore P73528 Go to UniProtKB: P73528
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P73528
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 16 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
DGD Query on DGD Download Ideal Coordinates CCD File SDF format, chain OI [auth h] SDF format, chain AD [auth C] SDF format, chain CE [auth H] SDF format, chain KH [auth c] SDF format, chain LH [auth c] SDF format, chain MH [auth c] SDF format, chain YC [auth C] SDF format, chain ZC [auth C] MOL2 format, chain OI [auth h] MOL2 format, chain AD [auth C] MOL2 format, chain CE [auth H] MOL2 format, chain KH [auth c] MOL2 format, chain LH [auth c] MOL2 format, chain MH [auth c] MOL2 format, chain YC [auth C] MOL2 format, chain ZC [auth C]	AD [auth C] CE [auth H] KH [auth c] LH [auth c] MH [auth c] AD [auth C], CE [auth H], KH [auth c], LH [auth c], MH [auth c], OI [auth h], YC [auth C], ZC [auth C]	DIGALACTOSYL DIACYL GLYCEROL (DGDG) C₅₁ H₉₆ O₁₅ LDQFLSUQYHBXSX-HXXRYREZSA-N		Interactions Focus chain AD [auth C] Focus chain CE [auth H] Focus chain KH [auth c] Focus chain LH [auth c] Focus chain MH [auth c] Focus chain OI [auth h] Focus chain YC [auth C] Focus chain ZC [auth C] Interactions & Density Focus chain AD [auth C] Focus chain CE [auth H] Focus chain KH [auth c] Focus chain LH [auth c] Focus chain MH [auth c] Focus chain OI [auth h] Focus chain YC [auth C] Focus chain ZC [auth C]
CLA Query on CLA Download Ideal Coordinates CCD File SDF format, chain BG [auth b] SDF format, chain DH [auth c] SDF format, chain EH [auth c] SDF format, chain GF [auth a] SDF format, chain GH [auth c] SDF format, chain KB [auth B] SDF format, chain MB [auth B] SDF format, chain OB [auth B] SDF format, chain OC [auth C] SDF format, chain QC [auth C] SDF format, chain RB [auth B] SDF format, chain UA [auth A] SDF format, chain UF [auth b] SDF format, chain VF [auth b] SDF format, chain WG [auth c] SDF format, chain XA [auth A] SDF format, chain XF [auth b] SDF format, chain ZG [auth c] SDF format, chain AG [auth b] SDF format, chain AH [auth c] SDF format, chain BH [auth c] SDF format, chain CG [auth b] SDF format, chain CH [auth c] SDF format, chain DG [auth b] SDF format, chain EG [auth b] SDF format, chain FG [auth b] SDF format, chain FH [auth c] SDF format, chain GD [auth D] SDF format, chain GG [auth b] SDF format, chain HB [auth B] SDF format, chain HF [auth a] SDF format, chain HG [auth b] SDF format, chain HH [auth c] SDF format, chain IB [auth B] SDF format, chain ID [auth D] SDF format, chain IG [auth b] SDF format, chain IH [auth c] SDF format, chain JB [auth B] SDF format, chain JD [auth D] SDF format, chain JF [auth a] SDF format, chain KC [auth C] SDF format, chain LB [auth B] SDF format, chain LC [auth C] SDF format, chain MC [auth C] SDF format, chain NB [auth B] SDF format, chain NC [auth C] SDF format, chain PB [auth B] SDF format, chain PC [auth C] SDF format, chain QB [auth B] SDF format, chain RC [auth C] SDF format, chain SB [auth B] SDF format, chain SC [auth C] SDF format, chain SH [auth d] SDF format, chain TB [auth B] SDF format, chain TC [auth C] SDF format, chain TF [auth b] SDF format, chain UB [auth B] SDF format, chain UC [auth C] SDF format, chain UH [auth d] SDF format, chain VA [auth A] SDF format, chain VB [auth B] SDF format, chain VC [auth C] SDF format, chain VH [auth d] SDF format, chain WB [auth B] SDF format, chain WC [auth C] SDF format, chain WF [auth b] SDF format, chain XG [auth c] SDF format, chain YF [auth b] SDF format, chain YG [auth c] SDF format, chain ZF [auth b] MOL2 format, chain BG [auth b] MOL2 format, chain DH [auth c] MOL2 format, chain EH [auth c] MOL2 format, chain GF [auth a] MOL2 format, chain GH [auth c] MOL2 format, chain KB [auth B] MOL2 format, chain MB [auth B] MOL2 format, chain OB [auth B] MOL2 format, chain OC [auth C] MOL2 format, chain QC [auth C] MOL2 format, chain RB [auth B] MOL2 format, chain UA [auth A] MOL2 format, chain UF [auth b] MOL2 format, chain VF [auth b] MOL2 format, chain WG [auth c] MOL2 format, chain XA [auth A] MOL2 format, chain XF [auth b] MOL2 format, chain ZG [auth c] MOL2 format, chain AG [auth b] MOL2 format, chain AH [auth c] MOL2 format, chain BH [auth c] MOL2 format, chain CG [auth b] MOL2 format, chain CH [auth c] MOL2 format, chain DG [auth b] MOL2 format, chain EG [auth b] MOL2 format, chain FG [auth b] MOL2 format, chain FH [auth c] MOL2 format, chain GD [auth D] MOL2 format, chain GG [auth b] MOL2 format, chain HB [auth B] MOL2 format, chain HF [auth a] MOL2 format, chain HG [auth b] MOL2 format, chain HH [auth c] MOL2 format, chain IB [auth B] MOL2 format, chain ID [auth D] MOL2 format, chain IG [auth b] MOL2 format, chain IH [auth c] MOL2 format, chain JB [auth B] MOL2 format, chain JD [auth D] MOL2 format, chain JF [auth a] MOL2 format, chain KC [auth C] MOL2 format, chain LB [auth B] MOL2 format, chain LC [auth C] MOL2 format, chain MC [auth C] MOL2 format, chain NB [auth B] MOL2 format, chain NC [auth C] MOL2 format, chain PB [auth B] MOL2 format, chain PC [auth C] MOL2 format, chain QB [auth B] MOL2 format, chain RC [auth C] MOL2 format, chain SB [auth B] MOL2 format, chain SC [auth C] MOL2 format, chain SH [auth d] MOL2 format, chain TB [auth B] MOL2 format, chain TC [auth C] MOL2 format, chain TF [auth b] MOL2 format, chain UB [auth B] MOL2 format, chain UC [auth C] MOL2 format, chain UH [auth d] MOL2 format, chain VA [auth A] MOL2 format, chain VB [auth B] MOL2 format, chain VC [auth C] MOL2 format, chain VH [auth d] MOL2 format, chain WB [auth B] MOL2 format, chain WC [auth C] MOL2 format, chain WF [auth b] MOL2 format, chain XG [auth c] MOL2 format, chain YF [auth b] MOL2 format, chain YG [auth c] MOL2 format, chain ZF [auth b]	AG [auth b] AH [auth c] BG [auth b] BH [auth c] CG [auth b] AG [auth b], AH [auth c], BG [auth b], BH [auth c], CG [auth b], CH [auth c], DG [auth b], DH [auth c], EG [auth b], EH [auth c], FG [auth b], FH [auth c], GD [auth D], GF [auth a], GG [auth b], GH [auth c], HB [auth B], HF [auth a], HG [auth b], HH [auth c], IB [auth B], ID [auth D], IG [auth b], IH [auth c], JB [auth B], JD [auth D], JF [auth a], KB [auth B], KC [auth C], LB [auth B], LC [auth C], MB [auth B], MC [auth C], NB [auth B], NC [auth C], OB [auth B], OC [auth C], PB [auth B], PC [auth C], QB [auth B], QC [auth C], RB [auth B], RC [auth C], SB [auth B], SC [auth C], SH [auth d], TB [auth B], TC [auth C], TF [auth b], UA [auth A], UB [auth B], UC [auth C], UF [auth b], UH [auth d], VA [auth A], VB [auth B], VC [auth C], VF [auth b], VH [auth d], WB [auth B], WC [auth C], WF [auth b], WG [auth c], XA [auth A], XF [auth b], XG [auth c], YF [auth b], YG [auth c], ZF [auth b], ZG [auth c]	CHLOROPHYLL A C₅₅ H₇₂ Mg N₄ O₅ ATNHDLDRLWWWCB-AENOIHSZSA-M		Interactions Focus chain AG [auth b] Focus chain AH [auth c] Focus chain BG [auth b] Focus chain BH [auth c] Focus chain CG [auth b] Focus chain CH [auth c] Focus chain DG [auth b] Focus chain DH [auth c] Focus chain EG [auth b] Focus chain EH [auth c] Focus chain FG [auth b] Focus chain FH [auth c] Focus chain GD [auth D] Focus chain GF [auth a] Focus chain GG [auth b] Focus chain GH [auth c] Focus chain HB [auth B] Focus chain HF [auth a] Focus chain HG [auth b] Focus chain HH [auth c] Focus chain IB [auth B] Focus chain ID [auth D] Focus chain IG [auth b] Focus chain IH [auth c] Focus chain JB [auth B] Focus chain JD [auth D] Focus chain JF [auth a] Focus chain KB [auth B] Focus chain KC [auth C] Focus chain LB [auth B] Focus chain LC [auth C] Focus chain MB [auth B] Focus chain MC [auth C] Focus chain NB [auth B] Focus chain NC [auth C] Focus chain OB [auth B] Focus chain OC [auth C] Focus chain PB [auth B] Focus chain PC [auth C] Focus chain QB [auth B] Focus chain QC [auth C] Focus chain RB [auth B] Focus chain RC [auth C] Focus chain SB [auth B] Focus chain SC [auth C] Focus chain SH [auth d] Focus chain TB [auth B] Focus chain TC [auth C] Focus chain TF [auth b] Focus chain UA [auth A] Focus chain UB [auth B] Focus chain UC [auth C] Focus chain UF [auth b] Focus chain UH [auth d] Focus chain VA [auth A] Focus chain VB [auth B] Focus chain VC [auth C] Focus chain VF [auth b] Focus chain VH [auth d] Focus chain WB [auth B] Focus chain WC [auth C] Focus chain WF [auth b] Focus chain WG [auth c] Focus chain XA [auth A] Focus chain XF [auth b] Focus chain XG [auth c] Focus chain YF [auth b] Focus chain YG [auth c] Focus chain ZF [auth b] Focus chain ZG [auth c] Interactions & Density Focus chain AG [auth b] Focus chain AH [auth c] Focus chain BG [auth b] Focus chain BH [auth c] Focus chain CG [auth b] Focus chain CH [auth c] Focus chain DG [auth b] Focus chain DH [auth c] Focus chain EG [auth b] Focus chain EH [auth c] Focus chain FG [auth b] Focus chain FH [auth c] Focus chain GD [auth D] Focus chain GF [auth a] Focus chain GG [auth b] Focus chain GH [auth c] Focus chain HB [auth B] Focus chain HF [auth a] Focus chain HG [auth b] Focus chain HH [auth c] Focus chain IB [auth B] Focus chain ID [auth D] Focus chain IG [auth b] Focus chain IH [auth c] Focus chain JB [auth B] Focus chain JD [auth D] Focus chain JF [auth a] Focus chain KB [auth B] Focus chain KC [auth C] Focus chain LB [auth B] Focus chain LC [auth C] Focus chain MB [auth B] Focus chain MC [auth C] Focus chain NB [auth B] Focus chain NC [auth C] Focus chain OB [auth B] Focus chain OC [auth C] Focus chain PB [auth B] Focus chain PC [auth C] Focus chain QB [auth B] Focus chain QC [auth C] Focus chain RB [auth B] Focus chain RC [auth C] Focus chain SB [auth B] Focus chain SC [auth C] Focus chain SH [auth d] Focus chain TB [auth B] Focus chain TC [auth C] Focus chain TF [auth b] Focus chain UA [auth A] Focus chain UB [auth B] Focus chain UC [auth C] Focus chain UF [auth b] Focus chain UH [auth d] Focus chain VA [auth A] Focus chain VB [auth B] Focus chain VC [auth C] Focus chain VF [auth b] Focus chain VH [auth d] Focus chain WB [auth B] Focus chain WC [auth C] Focus chain WF [auth b] Focus chain WG [auth c] Focus chain XA [auth A] Focus chain XF [auth b] Focus chain XG [auth c] Focus chain YF [auth b] Focus chain YG [auth c] Focus chain ZF [auth b] Focus chain ZG [auth c]
PHO Query on PHO Download Ideal Coordinates CCD File SDF format, chain TH [auth d] SDF format, chain HD [auth D] SDF format, chain IF [auth a] SDF format, chain WA [auth A] MOL2 format, chain TH [auth d] MOL2 format, chain HD [auth D] MOL2 format, chain IF [auth a] MOL2 format, chain WA [auth A]	HD [auth D], IF [auth a], TH [auth d], WA [auth A]	PHEOPHYTIN A C₅₅ H₇₄ N₄ O₅ CQIKWXUXPNUNDV-RCBXBCQGSA-N		Interactions Focus chain HD [auth D] Focus chain IF [auth a] Focus chain TH [auth d] Focus chain WA [auth A] Interactions & Density Focus chain HD [auth D] Focus chain IF [auth a] Focus chain TH [auth d] Focus chain WA [auth A]
SQD Query on SQD Download Ideal Coordinates CCD File SDF format, chain BE [auth H] SDF format, chain XD [auth F] SDF format, chain AC [auth B] SDF format, chain BB [auth A] SDF format, chain CB [auth A] SDF format, chain JC [auth C] SDF format, chain JE [auth K] SDF format, chain JI [auth f] SDF format, chain MG [auth b] SDF format, chain NF [auth a] SDF format, chain NI [auth h] SDF format, chain OF [auth a] SDF format, chain VG [auth c] SDF format, chain VI [auth k] MOL2 format, chain BE [auth H] MOL2 format, chain XD [auth F] MOL2 format, chain AC [auth B] MOL2 format, chain BB [auth A] MOL2 format, chain CB [auth A] MOL2 format, chain JC [auth C] MOL2 format, chain JE [auth K] MOL2 format, chain JI [auth f] MOL2 format, chain MG [auth b] MOL2 format, chain NF [auth a] MOL2 format, chain NI [auth h] MOL2 format, chain OF [auth a] MOL2 format, chain VG [auth c] MOL2 format, chain VI [auth k]	AC [auth B] BB [auth A] BE [auth H] CB [auth A] JC [auth C] AC [auth B], BB [auth A], BE [auth H], CB [auth A], JC [auth C], JE [auth K], JI [auth f], MG [auth b], NF [auth a], NI [auth h], OF [auth a], VG [auth c], VI [auth k], XD [auth F]	1,2-DI-O-ACYL-3-O-[6-DEOXY-6-SULFO-ALPHA-D-GLUCOPYRANOSYL]-SN-GLYCEROL C₄₁ H₇₈ O₁₂ S RVUUQPKXGDTQPG-JUDHQOGESA-N		Interactions Focus chain AC [auth B] Focus chain BB [auth A] Focus chain BE [auth H] Focus chain CB [auth A] Focus chain JC [auth C] Focus chain JE [auth K] Focus chain JI [auth f] Focus chain MG [auth b] Focus chain NF [auth a] Focus chain NI [auth h] Focus chain OF [auth a] Focus chain VG [auth c] Focus chain VI [auth k] Focus chain XD [auth F] Interactions & Density Focus chain AC [auth B] Focus chain BB [auth A] Focus chain BE [auth H] Focus chain CB [auth A] Focus chain JC [auth C] Focus chain JE [auth K] Focus chain JI [auth f] Focus chain MG [auth b] Focus chain NF [auth a] Focus chain NI [auth h] Focus chain OF [auth a] Focus chain VG [auth c] Focus chain VI [auth k] Focus chain XD [auth F]
LMG Query on LMG Download Ideal Coordinates CCD File SDF format, chain DD [auth C] SDF format, chain NG [auth b] SDF format, chain NH [auth c] SDF format, chain PF [auth a] SDF format, chain ZA [auth A] SDF format, chain AI [auth d] SDF format, chain BC [auth B] SDF format, chain BD [auth C] SDF format, chain DB [auth A] SDF format, chain DE [auth H] SDF format, chain LF [auth a] SDF format, chain OD [auth D] SDF format, chain PH [auth c] SDF format, chain PI [auth h] MOL2 format, chain DD [auth C] MOL2 format, chain NG [auth b] MOL2 format, chain NH [auth c] MOL2 format, chain PF [auth a] MOL2 format, chain ZA [auth A] MOL2 format, chain AI [auth d] MOL2 format, chain BC [auth B] MOL2 format, chain BD [auth C] MOL2 format, chain DB [auth A] MOL2 format, chain DE [auth H] MOL2 format, chain LF [auth a] MOL2 format, chain OD [auth D] MOL2 format, chain PH [auth c] MOL2 format, chain PI [auth h]	AI [auth d] BC [auth B] BD [auth C] DB [auth A] DD [auth C] AI [auth d], BC [auth B], BD [auth C], DB [auth A], DD [auth C], DE [auth H], LF [auth a], NG [auth b], NH [auth c], OD [auth D], PF [auth a], PH [auth c], PI [auth h], ZA [auth A]	1,2-DISTEAROYL-MONOGALACTOSYL-DIGLYCERIDE C₄₅ H₈₆ O₁₀ DCLTVZLYPPIIID-CVELTQQQSA-N		Interactions Focus chain AI [auth d] Focus chain BC [auth B] Focus chain BD [auth C] Focus chain DB [auth A] Focus chain DD [auth C] Focus chain DE [auth H] Focus chain LF [auth a] Focus chain NG [auth b] Focus chain NH [auth c] Focus chain OD [auth D] Focus chain PF [auth a] Focus chain PH [auth c] Focus chain PI [auth h] Focus chain ZA [auth A] Interactions & Density Focus chain AI [auth d] Focus chain BC [auth B] Focus chain BD [auth C] Focus chain DB [auth A] Focus chain DD [auth C] Focus chain DE [auth H] Focus chain LF [auth a] Focus chain NG [auth b] Focus chain NH [auth c] Focus chain OD [auth D] Focus chain PF [auth a] Focus chain PH [auth c] Focus chain PI [auth h] Focus chain ZA [auth A]
PL9 Query on PL9 Download Ideal Coordinates CCD File SDF format, chain WH [auth d] SDF format, chain AB [auth A] SDF format, chain KD [auth D] SDF format, chain MF [auth a] MOL2 format, chain WH [auth d] MOL2 format, chain AB [auth A] MOL2 format, chain KD [auth D] MOL2 format, chain MF [auth a]	AB [auth A], KD [auth D], MF [auth a], WH [auth d]	2,3-DIMETHYL-5-(3,7,11,15,19,23,27,31,35-NONAMETHYL-2,6,10,14,18,22,26,30,34-HEXATRIACONTANONAENYL-2,5-CYCLOHEXADIENE-1,4-DIONE-2,3-DIMETHYL-5-SOLANESYL-1,4-BENZOQUINONE C₅₃ H₈₀ O₂ FKUYMLZIRPABFK-UHFFFAOYSA-N		Interactions Focus chain AB [auth A] Focus chain KD [auth D] Focus chain MF [auth a] Focus chain WH [auth d] Interactions & Density Focus chain AB [auth A] Focus chain KD [auth D] Focus chain MF [auth a] Focus chain WH [auth d]
LHG Query on LHG Download Ideal Coordinates CCD File SDF format, chain FI [auth e] SDF format, chain YH [auth d] SDF format, chain ZH [auth d] SDF format, chain BF [auth Z] SDF format, chain GC [auth B] SDF format, chain HC [auth B] SDF format, chain LD [auth D] SDF format, chain MD [auth D] SDF format, chain ND [auth D] SDF format, chain NJ [auth z] SDF format, chain SG [auth b] SDF format, chain TD [auth E] SDF format, chain TG [auth b] SDF format, chain XH [auth d] MOL2 format, chain FI [auth e] MOL2 format, chain YH [auth d] MOL2 format, chain ZH [auth d] MOL2 format, chain BF [auth Z] MOL2 format, chain GC [auth B] MOL2 format, chain HC [auth B] MOL2 format, chain LD [auth D] MOL2 format, chain MD [auth D] MOL2 format, chain ND [auth D] MOL2 format, chain NJ [auth z] MOL2 format, chain SG [auth b] MOL2 format, chain TD [auth E] MOL2 format, chain TG [auth b] MOL2 format, chain XH [auth d]	BF [auth Z] FI [auth e] GC [auth B] HC [auth B] LD [auth D] BF [auth Z], FI [auth e], GC [auth B], HC [auth B], LD [auth D], MD [auth D], ND [auth D], NJ [auth z], SG [auth b], TD [auth E], TG [auth b], XH [auth d], YH [auth d], ZH [auth d]	1,2-DIPALMITOYL-PHOSPHATIDYL-GLYCEROLE C₃₈ H₇₅ O₁₀ P BIABMEZBCHDPBV-MPQUPPDSSA-N		Interactions Focus chain BF [auth Z] Focus chain FI [auth e] Focus chain GC [auth B] Focus chain HC [auth B] Focus chain LD [auth D] Focus chain MD [auth D] Focus chain ND [auth D] Focus chain NJ [auth z] Focus chain SG [auth b] Focus chain TD [auth E] Focus chain TG [auth b] Focus chain XH [auth d] Focus chain YH [auth d] Focus chain ZH [auth d] Interactions & Density Focus chain BF [auth Z] Focus chain FI [auth e] Focus chain GC [auth B] Focus chain HC [auth B] Focus chain LD [auth D] Focus chain MD [auth D] Focus chain ND [auth D] Focus chain NJ [auth z] Focus chain SG [auth b] Focus chain TD [auth E] Focus chain TG [auth b] Focus chain XH [auth d] Focus chain YH [auth d] Focus chain ZH [auth d]
HEM Query on HEM Download Ideal Coordinates CCD File SDF format, chain VD [auth E] SDF format, chain EJ [auth v] SDF format, chain HI [auth e] SDF format, chain SE [auth V] MOL2 format, chain VD [auth E] MOL2 format, chain EJ [auth v] MOL2 format, chain HI [auth e] MOL2 format, chain SE [auth V]	EJ [auth v], HI [auth e], SE [auth V], VD [auth E]	PROTOPORPHYRIN IX CONTAINING FE C₃₄ H₃₂ Fe N₄ O₄ KABFMIBPWCXCRK-RGGAHWMASA-L		Interactions Focus chain EJ [auth v] Focus chain HI [auth e] Focus chain SE [auth V] Focus chain VD [auth E] Interactions & Density Focus chain EJ [auth v] Focus chain HI [auth e] Focus chain SE [auth V] Focus chain VD [auth E]
RRX Query on RRX Download Ideal Coordinates CCD File SDF format, chain LI [auth h] SDF format, chain ZD [auth H] MOL2 format, chain LI [auth h] MOL2 format, chain ZD [auth H]	LI [auth h], ZD [auth H]	(3R)-beta,beta-caroten-3-ol C₄₀ H₅₆ O DMASLKHVQRHNES-FKKUPVFPSA-N		Interactions Focus chain LI [auth h] Focus chain ZD [auth H] Interactions & Density Focus chain LI [auth h] Focus chain ZD [auth H]
BCR Query on BCR Download Ideal Coordinates CCD File SDF format, chain AF [auth Z] SDF format, chain JG [auth b] SDF format, chain KF [auth a] SDF format, chain KG [auth b] SDF format, chain II [auth f] SDF format, chain JH [auth c] SDF format, chain KE [auth K] SDF format, chain LE [auth K] SDF format, chain LG [auth b] SDF format, chain MJ [auth z] SDF format, chain WD [auth F] SDF format, chain WI [auth k] SDF format, chain XB [auth B] SDF format, chain XC [auth C] SDF format, chain XI [auth k] SDF format, chain YA [auth A] SDF format, chain YB [auth B] SDF format, chain ZB [auth B] MOL2 format, chain AF [auth Z] MOL2 format, chain JG [auth b] MOL2 format, chain KF [auth a] MOL2 format, chain KG [auth b] MOL2 format, chain II [auth f] MOL2 format, chain JH [auth c] MOL2 format, chain KE [auth K] MOL2 format, chain LE [auth K] MOL2 format, chain LG [auth b] MOL2 format, chain MJ [auth z] MOL2 format, chain WD [auth F] MOL2 format, chain WI [auth k] MOL2 format, chain XB [auth B] MOL2 format, chain XC [auth C] MOL2 format, chain XI [auth k] MOL2 format, chain YA [auth A] MOL2 format, chain YB [auth B] MOL2 format, chain ZB [auth B]	AF [auth Z] II [auth f] JG [auth b] JH [auth c] KE [auth K] AF [auth Z], II [auth f], JG [auth b], JH [auth c], KE [auth K], KF [auth a], KG [auth b], LE [auth K], LG [auth b], MJ [auth z], WD [auth F], WI [auth k], XB [auth B], XC [auth C], XI [auth k], YA [auth A], YB [auth B], ZB [auth B]	BETA-CAROTENE C₄₀ H₅₆ OENHQHLEOONYIE-JLTXGRSLSA-N		Interactions Focus chain AF [auth Z] Focus chain II [auth f] Focus chain JG [auth b] Focus chain JH [auth c] Focus chain KE [auth K] Focus chain KF [auth a] Focus chain KG [auth b] Focus chain LE [auth K] Focus chain LG [auth b] Focus chain MJ [auth z] Focus chain WD [auth F] Focus chain WI [auth k] Focus chain XB [auth B] Focus chain XC [auth C] Focus chain XI [auth k] Focus chain YA [auth A] Focus chain YB [auth B] Focus chain ZB [auth B] Interactions & Density Focus chain AF [auth Z] Focus chain II [auth f] Focus chain JG [auth b] Focus chain JH [auth c] Focus chain KE [auth K] Focus chain KF [auth a] Focus chain KG [auth b] Focus chain LE [auth K] Focus chain LG [auth b] Focus chain MJ [auth z] Focus chain WD [auth F] Focus chain WI [auth k] Focus chain XB [auth B] Focus chain XC [auth C] Focus chain XI [auth k] Focus chain YA [auth A] Focus chain YB [auth B] Focus chain ZB [auth B]
LMT Query on LMT Download Ideal Coordinates CCD File SDF format, chain EC [auth B] SDF format, chain GE [auth I] SDF format, chain IC [auth B] SDF format, chain KJ [auth x] SDF format, chain MI [auth h] SDF format, chain OE [auth M] SDF format, chain QG [auth b] SDF format, chain RG [auth b] SDF format, chain SD [auth E] SDF format, chain UG [auth b] SDF format, chain UI [auth j] SDF format, chain ZE [auth Y] SDF format, chain AE [auth H] SDF format, chain AJ [auth m] SDF format, chain BI [auth d] SDF format, chain BJ [auth m] SDF format, chain CC [auth B] SDF format, chain CD [auth C] SDF format, chain CI [auth d] SDF format, chain CJ [auth t] SDF format, chain DC [auth B] SDF format, chain DI [auth d] SDF format, chain EB [auth A] SDF format, chain ED [auth C] SDF format, chain EE [auth I] SDF format, chain EI [auth e] SDF format, chain FB [auth A] SDF format, chain FC [auth B] SDF format, chain FD [auth C] SDF format, chain FE [auth I] SDF format, chain GI [auth e] SDF format, chain GJ [auth x] SDF format, chain HE [auth I] SDF format, chain HJ [auth x] SDF format, chain IE [auth J] SDF format, chain IJ [auth x] SDF format, chain JJ [auth x] SDF format, chain KI [auth f] SDF format, chain LJ [auth y] SDF format, chain NE [auth K] SDF format, chain OG [auth b] SDF format, chain OH [auth c] SDF format, chain PD [auth D] SDF format, chain PE [auth M] SDF format, chain PG [auth b] SDF format, chain QD [auth D] SDF format, chain QE [auth T] SDF format, chain QF [auth a] SDF format, chain QH [auth c] SDF format, chain QI [auth i] SDF format, chain RD [auth D] SDF format, chain RF [auth a] SDF format, chain RH [auth c] SDF format, chain RI [auth i] SDF format, chain SI [auth i] SDF format, chain TI [auth i] SDF format, chain UD [auth E] SDF format, chain UE [auth X] SDF format, chain VE [auth X] SDF format, chain WE [auth X] SDF format, chain XE [auth X] SDF format, chain YD [auth F] SDF format, chain YE [auth X] SDF format, chain ZI [auth k] MOL2 format, chain EC [auth B] MOL2 format, chain GE [auth I] MOL2 format, chain IC [auth B] MOL2 format, chain KJ [auth x] MOL2 format, chain MI [auth h] MOL2 format, chain OE [auth M] MOL2 format, chain QG [auth b] MOL2 format, chain RG [auth b] MOL2 format, chain SD [auth E] MOL2 format, chain UG [auth b] MOL2 format, chain UI [auth j] MOL2 format, chain ZE [auth Y] MOL2 format, chain AE [auth H] MOL2 format, chain AJ [auth m] MOL2 format, chain BI [auth d] MOL2 format, chain BJ [auth m] MOL2 format, chain CC [auth B] MOL2 format, chain CD [auth C] MOL2 format, chain CI [auth d] MOL2 format, chain CJ [auth t] MOL2 format, chain DC [auth B] MOL2 format, chain DI [auth d] MOL2 format, chain EB [auth A] MOL2 format, chain ED [auth C] MOL2 format, chain EE [auth I] MOL2 format, chain EI [auth e] MOL2 format, chain FB [auth A] MOL2 format, chain FC [auth B] MOL2 format, chain FD [auth C] MOL2 format, chain FE [auth I] MOL2 format, chain GI [auth e] MOL2 format, chain GJ [auth x] MOL2 format, chain HE [auth I] MOL2 format, chain HJ [auth x] MOL2 format, chain IE [auth J] MOL2 format, chain IJ [auth x] MOL2 format, chain JJ [auth x] MOL2 format, chain KI [auth f] MOL2 format, chain LJ [auth y] MOL2 format, chain NE [auth K] MOL2 format, chain OG [auth b] MOL2 format, chain OH [auth c] MOL2 format, chain PD [auth D] MOL2 format, chain PE [auth M] MOL2 format, chain PG [auth b] MOL2 format, chain QD [auth D] MOL2 format, chain QE [auth T] MOL2 format, chain QF [auth a] MOL2 format, chain QH [auth c] MOL2 format, chain QI [auth i] MOL2 format, chain RD [auth D] MOL2 format, chain RF [auth a] MOL2 format, chain RH [auth c] MOL2 format, chain RI [auth i] MOL2 format, chain SI [auth i] MOL2 format, chain TI [auth i] MOL2 format, chain UD [auth E] MOL2 format, chain UE [auth X] MOL2 format, chain VE [auth X] MOL2 format, chain WE [auth X] MOL2 format, chain XE [auth X] MOL2 format, chain YD [auth F] MOL2 format, chain YE [auth X] MOL2 format, chain ZI [auth k]	AE [auth H] AJ [auth m] BI [auth d] BJ [auth m] CC [auth B] AE [auth H], AJ [auth m], BI [auth d], BJ [auth m], CC [auth B], CD [auth C], CI [auth d], CJ [auth t], DC [auth B], DI [auth d], EB [auth A], EC [auth B], ED [auth C], EE [auth I], EI [auth e], FB [auth A], FC [auth B], FD [auth C], FE [auth I], GE [auth I], GI [auth e], GJ [auth x], HE [auth I], HJ [auth x], IC [auth B], IE [auth J], IJ [auth x], JJ [auth x], KI [auth f], KJ [auth x], LJ [auth y], MI [auth h], NE [auth K], OE [auth M], OG [auth b], OH [auth c], PD [auth D], PE [auth M], PG [auth b], QD [auth D], QE [auth T], QF [auth a], QG [auth b], QH [auth c], QI [auth i], RD [auth D], RF [auth a], RG [auth b], RH [auth c], RI [auth i], SD [auth E], SI [auth i], TI [auth i], UD [auth E], UE [auth X], UG [auth b], UI [auth j], VE [auth X], WE [auth X], XE [auth X], YD [auth F], YE [auth X], ZE [auth Y], ZI [auth k]	DODECYL-BETA-D-MALTOSIDE C₂₄ H₄₆ O₁₁ NLEBIOOXCVAHBD-QKMCSOCLSA-N		Interactions Focus chain AE [auth H] Focus chain AJ [auth m] Focus chain BI [auth d] Focus chain BJ [auth m] Focus chain CC [auth B] Focus chain CD [auth C] Focus chain CI [auth d] Focus chain CJ [auth t] Focus chain DC [auth B] Focus chain DI [auth d] Focus chain EB [auth A] Focus chain EC [auth B] Focus chain ED [auth C] Focus chain EE [auth I] Focus chain EI [auth e] Focus chain FB [auth A] Focus chain FC [auth B] Focus chain FD [auth C] Focus chain FE [auth I] Focus chain GE [auth I] Focus chain GI [auth e] Focus chain GJ [auth x] Focus chain HE [auth I] Focus chain HJ [auth x] Focus chain IC [auth B] Focus chain IE [auth J] Focus chain IJ [auth x] Focus chain JJ [auth x] Focus chain KI [auth f] Focus chain KJ [auth x] Focus chain LJ [auth y] Focus chain MI [auth h] Focus chain NE [auth K] Focus chain OE [auth M] Focus chain OG [auth b] Focus chain OH [auth c] Focus chain PD [auth D] Focus chain PE [auth M] Focus chain PG [auth b] Focus chain QD [auth D] Focus chain QE [auth T] Focus chain QF [auth a] Focus chain QG [auth b] Focus chain QH [auth c] Focus chain QI [auth i] Focus chain RD [auth D] Focus chain RF [auth a] Focus chain RG [auth b] Focus chain RH [auth c] Focus chain RI [auth i] Focus chain SD [auth E] Focus chain SI [auth i] Focus chain TI [auth i] Focus chain UD [auth E] Focus chain UE [auth X] Focus chain UG [auth b] Focus chain UI [auth j] Focus chain VE [auth X] Focus chain WE [auth X] Focus chain XE [auth X] Focus chain YD [auth F] Focus chain YE [auth X] Focus chain ZE [auth Y] Focus chain ZI [auth k] Interactions & Density Focus chain AE [auth H] Focus chain AJ [auth m] Focus chain BI [auth d] Focus chain BJ [auth m] Focus chain CC [auth B] Focus chain CD [auth C] Focus chain CI [auth d] Focus chain CJ [auth t] Focus chain DC [auth B] Focus chain DI [auth d] Focus chain EB [auth A] Focus chain EC [auth B] Focus chain ED [auth C] Focus chain EE [auth I] Focus chain EI [auth e] Focus chain FB [auth A] Focus chain FC [auth B] Focus chain FD [auth C] Focus chain FE [auth I] Focus chain GE [auth I] Focus chain GI [auth e] Focus chain GJ [auth x] Focus chain HE [auth I] Focus chain HJ [auth x] Focus chain IC [auth B] Focus chain IE [auth J] Focus chain IJ [auth x] Focus chain JJ [auth x] Focus chain KI [auth f] Focus chain KJ [auth x] Focus chain LJ [auth y] Focus chain MI [auth h] Focus chain NE [auth K] Focus chain OE [auth M] Focus chain OG [auth b] Focus chain OH [auth c] Focus chain PD [auth D] Focus chain PE [auth M] Focus chain PG [auth b] Focus chain QD [auth D] Focus chain QE [auth T] Focus chain QF [auth a] Focus chain QG [auth b] Focus chain QH [auth c] Focus chain QI [auth i] Focus chain RD [auth D] Focus chain RF [auth a] Focus chain RG [auth b] Focus chain RH [auth c] Focus chain RI [auth i] Focus chain SD [auth E] Focus chain SI [auth i] Focus chain TI [auth i] Focus chain UD [auth E] Focus chain UE [auth X] Focus chain UG [auth b] Focus chain UI [auth j] Focus chain VE [auth X] Focus chain WE [auth X] Focus chain XE [auth X] Focus chain YD [auth F] Focus chain YE [auth X] Focus chain ZE [auth Y] Focus chain ZI [auth k]
OEX (Subject of Investigation/LOI) Query on OEX Download Ideal Coordinates CCD File SDF format, chain CF [auth a] SDF format, chain QA [auth A] MOL2 format, chain CF [auth a] MOL2 format, chain QA [auth A]	CF [auth a], QA [auth A]	CA-MN4-O5 CLUSTER Ca Mn₄ O₅ SEXWDHMBWJEXOJ-UHFFFAOYSA-N		Interactions Focus chain CF [auth a] Focus chain QA [auth A] Interactions & Density Focus chain CF [auth a] Focus chain QA [auth A]
BCT Query on BCT Download Ideal Coordinates CCD File SDF format, chain SF [auth a] SDF format, chain GB [auth A] MOL2 format, chain SF [auth a] MOL2 format, chain GB [auth A]	GB [auth A], SF [auth a]	BICARBONATE ION C H O₃ BVKZGUZCCUSVTD-UHFFFAOYSA-M		Interactions Focus chain GB [auth A] Focus chain SF [auth a] Interactions & Density Focus chain GB [auth A] Focus chain SF [auth a]
FE2 Query on FE2 Download Ideal Coordinates CCD File SDF format, chain DF [auth a] SDF format, chain RA [auth A] MOL2 format, chain DF [auth a] MOL2 format, chain RA [auth A]	DF [auth a], RA [auth A]	FE (II) ION Fe CWYNVVGOOAEACU-UHFFFAOYSA-N		Interactions Focus chain DF [auth a] Focus chain RA [auth A] Interactions & Density Focus chain DF [auth a] Focus chain RA [auth A]
CA Query on CA Download Ideal Coordinates CCD File SDF format, chain ME [auth K] SDF format, chain TE [auth V] SDF format, chain DJ [auth u] SDF format, chain FJ [auth v] SDF format, chain RE [auth U] SDF format, chain YI [auth k] MOL2 format, chain ME [auth K] MOL2 format, chain TE [auth V] MOL2 format, chain DJ [auth u] MOL2 format, chain FJ [auth v] MOL2 format, chain RE [auth U] MOL2 format, chain YI [auth k]	DJ [auth u] FJ [auth v] ME [auth K] RE [auth U] TE [auth V] DJ [auth u], FJ [auth v], ME [auth K], RE [auth U], TE [auth V], YI [auth k]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain DJ [auth u] Focus chain FJ [auth v] Focus chain ME [auth K] Focus chain RE [auth U] Focus chain TE [auth V] Focus chain YI [auth k] Interactions & Density Focus chain DJ [auth u] Focus chain FJ [auth v] Focus chain ME [auth K] Focus chain RE [auth U] Focus chain TE [auth V] Focus chain YI [auth k]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain EF [auth a] SDF format, chain TA [auth A] SDF format, chain FF [auth a] SDF format, chain SA [auth A] MOL2 format, chain EF [auth a] MOL2 format, chain TA [auth A] MOL2 format, chain FF [auth a] MOL2 format, chain SA [auth A]	EF [auth a], FF [auth a], SA [auth A], TA [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain EF [auth a] Focus chain FF [auth a] Focus chain SA [auth A] Focus chain TA [auth A] Interactions & Density Focus chain EF [auth a] Focus chain FF [auth a] Focus chain SA [auth A] Focus chain TA [auth A]
