8QEK

Neck and tail of phage 812 after tail contraction (composite)

• PDB DOI: https://doi.org/10.2210/pdb8QEK/pdb
• EM Map EMD-18369: EMDB EMDataResource
• NAKB: 8QEK

• Classification: VIRUS
• Organism(s): Staphylococcus phage 812
• Mutation(s): No


• Deposited: 2023-08-31 Released: 2024-09-11
• Deposition Author(s): Cienikova, Z., Siborova, M., Fuzik, T., Plevka, P.
• Funding Organization(s): Ministry of Education, Youth and Sports of the Czech Republic

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.60 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Starting Models: experimental

Literature

Genome anchoring, retention, and release by neck proteins of Herelleviridae phage 812

Cienikova, Z., Novacek, J., Siborova, M., Popelarova, B., Fuzik, T., Benesik, M., Bardy, P., Plevka, P.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C6  (Explore in 3D)
Global Stoichiometry: Hetero 66-mer - A12B12C12D12E6F6G6

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 562.04 kDa
• Atom Count: 32,480
• Modelled Residue Count: 3,705
• Deposited Residue Count: 4,585
• Unique protein chains: 6
• Unique nucleic acid chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Portal protein	A [auth p], B [auth D]	563	Staphylococcus phage 812	Mutation(s): 0
UniProt
Find proteins for A0A0U1WIV9 (Staphylococcus phage 812) Explore A0A0U1WIV9  Go to UniProtKB:  A0A0U1WIV9

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Capsid protein	E [auth A], G	142	Staphylococcus phage 812	Mutation(s): 0
UniProt
Find proteins for A1YTP2 (Staphylococcus phage 812) Explore A1YTP2  Go to UniProtKB:  A1YTP2

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
Baseplate hub assembly protein	F [auth M]	278	Staphylococcus phage 812	Mutation(s): 0
UniProt
Find proteins for A1YTN9 (Staphylococcus phage 812) Explore A1YTN9  Go to UniProtKB:  A1YTN9

Entity ID: 6
Molecule	Chains	Sequence Length	Organism	Details	Image
Capsid protein	H [auth S]	292	Staphylococcus phage 812	Mutation(s): 0
UniProt
Find proteins for A1YTN7 (Staphylococcus phage 812) Explore A1YTN7  Go to UniProtKB:  A1YTN7

Entity ID: 7
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative neck protein	I [auth b], J [auth c]	302	Staphylococcus phage 812	Mutation(s): 0
UniProt
Find proteins for A1YTN6 (Staphylococcus phage 812) Explore A1YTN6  Go to UniProtKB:  A1YTN6

Entity ID: 8
Molecule	Chains	Sequence Length	Organism	Details	Image
Major tail sheath protein	K [auth B], L [auth I], M [auth O]	587	Staphylococcus phage 812	Mutation(s): 0
UniProt
Find proteins for A0A0U1WZ79 (Staphylococcus phage 812) Explore A0A0U1WZ79  Go to UniProtKB:  A0A0U1WZ79

Entity ID: 2
Molecule	Chains	Length	Organism	Image
Anchor DNA forward strand (120-MER)	C [auth Y]	120	Staphylococcus phage 812

Entity ID: 3
Molecule	Chains	Length	Organism	Image
Anchor DNA reverse strand (120-MER)	D [auth Z]	120	Staphylococcus phage 812

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN	N [auth S], O [auth b], P [auth c]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.60 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	RELION	3.1
RECONSTRUCTION	UCSF Chimera	1.16

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-09-11
Deposition Author(s): Cienikova, Z., Siborova, M., Fuzik, T., Plevka, P.

---

Funding Organization	Location	Grant Number
Ministry of Education, Youth and Sports of the Czech Republic	Czech Republic	--

Revision History

• Version 1.0: 2024-09-11
  Type: Initial release
