8AAC

African cichlid nackednavirus capsid at pH 7.5


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structural conservation of HBV-like capsid proteins over hundreds of millions of years despite the shift from non-enveloped to enveloped life-style.

Pfister, S.Rabl, J.Wiegand, T.Mattei, S.Malar, A.A.Lecoq, L.Seitz, S.Bartenschlager, R.Bockmann, A.Nassal, M.Boehringer, D.Meier, B.H.

(2023) Nat Commun 14: 1574-1574

  • DOI: https://doi.org/10.1038/s41467-023-37068-w
  • Primary Citation of Related Structures:
    8AAC, 8C0O

  • PubMed Abstract:

    The discovery of nackednaviruses provided new insight into the evolutionary history of the hepatitis B virus (HBV): The common ancestor of HBV and nackednaviruses was non-enveloped and while HBV acquired an envelope during evolution, nackednaviruses remained non-enveloped. We report the capsid structure of the African cichlid nackednavirus (ACNDV), determined by cryo-EM at 3.7 Å resolution. This enables direct comparison with the known capsid structures of HBV and duck HBV, prototypic representatives of the mammalian and avian lineages of the enveloped Hepadnaviridae, respectively. The sequence identity with HBV is 24% and both the ACNDV capsid protein fold and the capsid architecture are very similar to those of the Hepadnaviridae and HBV in particular. Acquisition of the hepadnaviral envelope was thus not accompanied by a major change in capsid structure. Dynamic residues at the spike tip are tentatively assigned by solid-state NMR, while the C-terminal domain is invisible due to dynamics. Solid-state NMR characterization of the capsid structure reveals few conformational differences between the quasi-equivalent subunits of the ACNDV capsid and an overall higher capsid structural disorder compared to HBV. Despite these differences, the capsids of ACNDV and HBV are structurally highly similar despite the 400 million years since their separation.


  • Organizational Affiliation

    Physical Chemistry, ETH Zurich, 8093, Zurich, Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
C protein
A [auth 1A],
AA [auth JA],
AB [auth RB],
AC [auth ZC],
AD [auth iA],
AE [auth qB],
AF [auth yC],
B [auth AC],
BA [auth 1B],
BB [auth RC],
BC [auth aA],
BD [auth iB],
BE [auth qC],
BF [auth zA],
C [auth BA],
CA [auth JB],
CB [auth 1C],
CC [auth aB],
CD [auth iC],
CE [auth rA],
CF [auth zB],
D [auth BB],
DA [auth JC],
DB [auth SA],
DC [auth 2A],
DD [auth jA],
DE [auth rB],
DF [auth zC],
E [auth BC],
EA [auth KA],
EB [auth SB],
EC [auth aC],
ED [auth 2B],
EE [auth rC],
EF [auth 3A],
F [auth CA],
FA [auth KB],
FB [auth SC],
FC [auth bA],
FD [auth jB],
FE [auth 2C],
FF [auth 3B],
G [auth CB],
GA [auth KC],
GB [auth TA],
GC [auth bB],
GD [auth jC],
GE [auth sA],
GF [auth 3C],
H [auth CC],
HA [auth LA],
HB [auth TB],
HC [auth bC],
HD [auth kA],
HE [auth sB],
HF [auth 4A],
I [auth DA],
IA [auth LB],
IB [auth TC],
IC [auth cA],
ID [auth kB],
IE [auth sC],
IF [auth 4B],
J [auth DB],
JA [auth LC],
JB [auth UA],
JC [auth cB],
JD [auth kC],
JE [auth tA],
JF [auth 4C],
K [auth DC],
KA [auth MA],
KB [auth UB],
KC [auth cC],
KD [auth lA],
KE [auth tB],
KF [auth 5A],
L [auth EA],
LA [auth MB],
LB [auth UC],
LC [auth dA],
LD [auth lB],
LE [auth tC],
LF [auth 5B],
M [auth EB],
MA [auth MC],
MB [auth VA],
MC [auth dB],
MD [auth lC],
ME [auth uA],
MF [auth 5C],
N [auth EC],
NA,
NB [auth VB],
NC [auth dC],
ND [auth mA],
NE [auth uB],
NF [auth 6A],
O [auth FA],
OA [auth NB],
OB [auth VC],
OC [auth eA],
OD [auth mB],
OE [auth uC],
OF [auth 6B],
P [auth FB],
PA [auth NC],
PB [auth WA],
PC [auth eB],
PD [auth mC],
PE [auth vA],
PF [auth 6C],
Q [auth FC],
QA [auth OA],
QB [auth WB],
QC [auth eC],
QD [auth nA],
QE [auth vB],
QF [auth 7A],
R [auth GA],
RA [auth OB],
RB [auth WC],
RC [auth fA],
RD [auth nB],
RE [auth vC],
RF [auth 7B],
S [auth GB],
SA [auth OC],
SB [auth XA],
SC [auth fB],
SD [auth nC],
SE [auth wA],
SF [auth 7C],
T [auth GC],
TA [auth PA],
TB [auth XB],
TC [auth fC],
TD [auth oA],
TE [auth wB],
TF [auth 8A],
U [auth HA],
UA [auth PB],
UB [auth XC],
UC [auth gA],
UD [auth oB],
UE [auth wC],
UF [auth 8B],
V [auth HB],
VA [auth PC],
VB [auth YA],
VC [auth gB],
VD [auth oC],
VE [auth xA],
VF [auth 8C],
W [auth HC],
WA [auth QA],
WB [auth YB],
WC [auth gC],
WD [auth pA],
WE [auth xB],
WF [auth AA],
X [auth IA],
XA [auth QB],
XB [auth YC],
XC [auth hA],
XD [auth pB],
XE [auth xC],
XF [auth AB],
Y [auth IB],
YA [auth QC],
YB [auth ZA],
YC [auth hB],
YD [auth pC],
YE [auth yA],
Z [auth IC],
ZA [auth RA],
ZB,
ZC [auth hC],
ZD [auth qA],
ZE [auth yB]
175African cichlid nackednavirusMutation(s): 0
UniProt
Find proteins for A0A3S9H6T3 (African cichlid nackednavirus)
Explore A0A3S9H6T3
Go to UniProtKB:  A0A3S9H6T3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A3S9H6T3
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.1
MODEL REFINEMENTPHENIX1.17.1-3660
MODEL REFINEMENTISOLDE1.0b4.dev0

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
European Research Council (ERC)European Union741863
Swiss National Science FoundationSwitzerland200020_159707
Swiss National Science FoundationSwitzerland200020_188711

Revision History  (Full details and data files)

  • Version 1.0: 2023-04-05
    Type: Initial release
