8ZWL

Heparin bound Tau fibril polymorph 3

• PDB DOI: https://doi.org/10.2210/pdb8ZWL/pdb
• EM Map EMD-60532: EMDB EMDataResource

• Classification: PROTEIN FIBRIL
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2024-06-13 Released: 2024-07-03
• Deposition Author(s): Tao, Y.Q., Liu, C., Li, D.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.40 Å
• Aggregation State: FILAMENT
• Reconstruction Method: HELICAL

Literature

Heparin bound Tau fibril polymorph 3

Tao, Y.Q., Liu, C., Li, D.

To be published.

Biological Assembly 1

Global Symmetry: Helical - H  (Explore in 3D)
Global Stoichiometry: Homo 6-mer - A6

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 275.52 kDa
• Atom Count: 3,468
• Modelled Residue Count: 456
• Deposited Residue Count: 2,646
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Isoform Tau-F of Microtubule-associated protein tau	A [auth C], B [auth D], C [auth E], D [auth F], E [auth A], F [auth B]	441	Homo sapiens	Mutation(s): 0  Gene Names: MAPT, MAPTL, MTBT1, TAU
UniProt & NIH Common Fund Data Resources
Find proteins for P10636 (Homo sapiens) Explore P10636  Go to UniProtKB:  P10636
PHAROS:  P10636 GTEx:  ENSG00000186868

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.40 Å
• Aggregation State: FILAMENT
• Reconstruction Method: HELICAL

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-07-03
Deposition Author(s): Tao, Y.Q., Liu, C., Li, D.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2024-07-03
  Type: Initial release
