8ZIX | pdb_00008zix

RAT skeletal muscle F-actin

PDB DOI: https://doi.org/10.2210/pdb8ZIX/pdb
EM Map EMD-60132: EMDB EMDataResource

Classification: PROTEIN FIBRIL
Organism(s): Rattus norvegicus
Mutation(s): No

Deposited: 2024-05-14 Released: 2025-01-29
Deposition Author(s): Li, D.N., Zhao, Q.Y., Liu, C.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.54 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report

Validation slider image for 8ZIX

This is version 1.0 of the entry. See complete history.

Literature

RAT skeletal muscle F-actin

Li, D.N., Zhao, Q.Y.

To be published.

Macromolecule Content

Total Structure Weight: 250.81 kDa
Atom Count: 17,556
Modeled Residue Count: 2,226
Deposited Residue Count: 2,226
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Actin, alpha skeletal muscle	A [auth P] B [auth R] C [auth A] D [auth E] E [auth B] A [auth P], B [auth R], C [auth A], D [auth E], E [auth B], F	371	Rattus norvegicus	Mutation(s): 0 EC: 3.6.4
UniProt
Find proteins for P68136 (Rattus norvegicus) Explore P68136 Go to UniProtKB: P68136
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P68136
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ADP (Subject of Investigation/LOI) Query on ADP Download:Ideal Coordinates CCD File SDF format, chain G [auth P] SDF format, chain H [auth R] SDF format, chain I [auth A] SDF format, chain J [auth E] SDF format, chain K [auth B] SDF format, chain L [auth F] MOL2 format, chain G [auth P] MOL2 format, chain H [auth R] MOL2 format, chain I [auth A] MOL2 format, chain J [auth E] MOL2 format, chain K [auth B] MOL2 format, chain L [auth F] mmCIF format, chain G [auth P] mmCIF format, chain H [auth R] mmCIF format, chain I [auth A] mmCIF format, chain J [auth E] mmCIF format, chain K [auth B] mmCIF format, chain L [auth F]	G [auth P] H [auth R] I [auth A] J [auth E] K [auth B] G [auth P], H [auth R], I [auth A], J [auth E], K [auth B], L [auth F]	ADENOSINE-5'-DIPHOSPHATE C₁₀ H₁₅ N₅ O₁₀ P₂ XTWYTFMLZFPYCI-KQYNXXCUSA-N		Interactions Focus chain G [auth P] Focus chain H [auth R] Focus chain I [auth A] Focus chain J [auth E] Focus chain K [auth B] Focus chain L [auth F] Interactions & Density Focus chain G [auth P] Focus chain H [auth R] Focus chain I [auth A] Focus chain J [auth E] Focus chain K [auth B] Focus chain L [auth F]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.54 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.15.2_3472:

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-01-29

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2025-01-29
Type: Initial release
