8Z0A | pdb_00008z0a

Human GYS1-GYG2 complex (apo)

PDB DOI: https://doi.org/10.2210/pdb8Z0A/pdb
EM Map EMD-39700: EMDB EMDataResource

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): No

Deposited: 2024-04-09 Released: 2025-04-09
Deposition Author(s): Chen, P.P., Hsia, K.C.
Funding Organization(s): Academia Sinica (Taiwan)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.84 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8Z0A

This is version 1.1 of the entry. See complete history.

Literature

Human GYS1-GYG2 complex (apo)

Chen, P.P., Hsia, K.C.

To be published.

Macromolecule Content

Total Structure Weight: 568.78 kDa
Atom Count: 20,668
Modeled Residue Count: 2,544
Deposited Residue Count: 5,052
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glycogen [starch] synthase, muscle	A, B, C, D	762	Homo sapiens	Mutation(s): 0 Gene Names: GYS1, GYS EC: 2.4.1.11
UniProt & NIH Common Fund Data Resources
Find proteins for P13807 (Homo sapiens) Explore P13807 Go to UniProtKB: P13807
PHAROS: P13807 GTEx: ENSG00000104812
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P13807
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Glycogenin-2	E, F, G, H	501	Homo sapiens	Mutation(s): 0 Gene Names: GYG2 EC: 2.4.1.186
UniProt & NIH Common Fund Data Resources
Find proteins for O15488 (Homo sapiens) Explore O15488 Go to UniProtKB: O15488
PHAROS: O15488 GTEx: ENSG00000056998
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O15488
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.84 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-04-09

Deposition Author(s):

Funding Organization	Location	Grant Number
Academia Sinica (Taiwan)	Taiwan	--

Revision History (Full details and data files)

Version 1.0: 2025-04-09
Type: Initial release
Version 1.1: 2025-07-02
Changes: Data collection
