8YB4

Pfr conformer of Arabidopsis thaliana phytochrome B in complex with phytochrome-interacting factor 6


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Models: in silico
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Light-induced remodeling of phytochrome B enables signal transduction by phytochrome-interacting factor.

Wang, Z.Wang, W.Zhao, D.Song, Y.Lin, X.Shen, M.Chi, C.Xu, B.Zhao, J.Deng, X.W.Wang, J.

(2024) Cell 187: 6235-6250.e19

  • DOI: https://doi.org/10.1016/j.cell.2024.09.005
  • Primary Citation of Related Structures:
    8YB4, 9IUZ

  • PubMed Abstract:

    Phytochrome B (phyB) and phytochrome-interacting factors (PIFs) constitute a well-established signaling module critical for plants adapting to ambient light. However, mechanisms underlying phyB photoactivation and PIF binding for signal transduction remain elusive. Here, we report the cryo-electron microscopy (cryo-EM) structures of the photoactivated phyB or the constitutively active phyB Y276H mutant in complex with PIF6, revealing a similar trimer. The light-induced configuration switch of the chromophore drives a conformational transition of the nearby tongue signature within the phytochrome-specific (PHY) domain of phyB. The resulting α-helical PHY tongue further disrupts the head-to-tail dimer of phyB in the dark-adapted state. These structural remodelings of phyB facilitate the induced-fit recognition of PIF6, consequently stabilizing the N-terminal extension domain and a head-to-head dimer of activated phyB. Interestingly, the phyB dimer exhibits slight asymmetry, resulting in the binding of only one PIF6 molecule. Overall, our findings solve a key question with respect to how light-induced remodeling of phyB enables PIF signaling in phytochrome research.


  • Organizational Affiliation

    National Key Laboratory of Wheat Improvement, Peking University Institute of Advanced Agricultural Sciences, Shandong Laboratory of Advanced Agriculture Sciences at Weifang, Weifang, Shandong, China; State Key Laboratory of Protein and Plant Gene Research, School of Advanced Agricultural Sciences, Peking University, Beijing, China; Peking-Tsinghua Joint Center for Life Sciences, Peking University, Beijing, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
phytochrome BA [auth B],
B [auth A]
1,177Arabidopsis thalianaMutation(s): 0
Gene Names: PHYBHY3OOP1At2g18790MSF3.17
UniProt
Find proteins for P14713 (Arabidopsis thaliana)
Explore P14713
Go to UniProtKB:  P14713
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP14713
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
phytochrome-interacting factor 6105Arabidopsis thalianaMutation(s): 0
Gene Names: PIF6BHLH132EN111PIL2At3g62090T17J13.50
UniProt
Find proteins for Q8L5W7 (Arabidopsis thaliana)
Explore Q8L5W7
Go to UniProtKB:  Q8L5W7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8L5W7
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
O6E (Subject of Investigation/LOI)
Query on O6E

Download Ideal Coordinates CCD File
D [auth B],
E [auth A]
3-[5-[[(3~{R},4~{R})-3-ethyl-4-methyl-5-oxidanylidene-3,4-dihydropyrrol-2-yl]methyl]-2-[[5-[(4-ethyl-3-methyl-5-oxidanylidene-pyrrol-2-yl)methyl]-3-(3-hydroxy-3-oxopropyl)-4-methyl-1~{H}-pyrrol-2-yl]methyl]-4-methyl-1~{H}-pyrrol-3-yl]propanoic acid
C33 H38 N4 O6
SRFSSETUPHUBBC-GMXXPEQVSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC4.1.2
MODEL REFINEMENTPHENIX1.20

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China32271253

Revision History  (Full details and data files)

  • Version 1.0: 2024-10-02
    Type: Initial release
  • Version 1.1: 2024-10-09
    Changes: Data collection, Database references, Structure summary
  • Version 1.2: 2024-11-13
    Changes: Data collection, Database references
