8X0A | pdb_00008x0a

Crystal Structure of MftR from mycobacterium tuberculosis

PDB DOI: https://doi.org/10.2210/pdb8X0A/pdb

Classification: DNA BINDING PROTEIN
Organism(s): Mycobacterium tuberculosis
Expression System: Escherichia coli K-12
Mutation(s): No

Deposited: 2023-11-04 Released: 2024-11-06
Deposition Author(s): Peng, F., Ke, Z.H., Li, Y.
Funding Organization(s): Ministry of Science and Technology (MoST, China)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free:
0.278 (Depositor), 0.279 (DCC)
R-Value Work:
0.229 (Depositor), 0.230 (DCC)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8X0A

This is version 1.0 of the entry. See complete history.

Literature

Crystal Structure of MftR from mycobacterium tuberculosis

Peng, F., Ke, Z.H., Li, Y.

To be published.

Macromolecule Content

Total Structure Weight: 104.2 kDa
Atom Count: 7,285
Modeled Residue Count: 918
Deposited Residue Count: 930
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative mycofactocin biosynthesis transcriptional regulator MftR	A, B [auth E], C [auth B], D [auth C], E [auth D]	186	Mycobacterium tuberculosis	Mutation(s): 0 Gene Names: mftR
UniProt
Find proteins for P9WMB7 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)) Explore P9WMB7 Go to UniProtKB: P9WMB7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P9WMB7
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.70 Å
R-Value Free: 0.278 (Depositor), 0.279 (DCC)
R-Value Work: 0.229 (Depositor), 0.230 (DCC)

Space Group: I 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 109.75	α = 90
b = 81.43	β = 107.356
c = 120.457	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
PHASES	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-11-06

Deposition Author(s):

Funding Organization	Location	Grant Number
Ministry of Science and Technology (MoST, China)	China	2021YFC2600200

Revision History (Full details and data files)

Version 1.0: 2024-11-06
Type: Initial release
