8WTL | pdb_00008wtl

Crystal structure of Cas3-DExD+MG+ATP

PDB DOI: https://doi.org/10.2210/pdb8WTL/pdb

Classification: METAL BINDING PROTEIN
Organism(s): Pyrococcus horikoshii
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2023-10-18 Released: 2024-10-30
Deposition Author(s): Mo, X.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.94 Å
R-Value Free:
0.246 (Depositor), 0.247 (DCC)
R-Value Work:
0.206 (Depositor), 0.210 (DCC)
R-Value Observed:
0.208 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8WTL

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Structural insight into dynamic characteristic of the polymerized forms of kinetoplastid membrane protein-11

Mo, X.

To be published.

Macromolecule Content

Total Structure Weight: 60.88 kDa
Atom Count: 4,065
Modeled Residue Count: 496
Deposited Residue Count: 519
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
CRISPR-associated helicase Cas3	A	519	Pyrococcus horikoshii	Mutation(s): 0 Gene Names: cas3
UniProt
Find proteins for O58616 (Pyrococcus horikoshii (strain ATCC 700860 / DSM 12428 / JCM 9974 / NBRC 100139 / OT-3)) Explore O58616 Go to UniProtKB: O58616
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O58616
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ATP (Subject of Investigation/LOI) Query on ATP Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	ADENOSINE-5'-TRIPHOSPHATE C₁₀ H₁₆ N₅ O₁₃ P₃ ZKHQWZAMYRWXGA-KQYNXXCUSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
MG (Subject of Investigation/LOI) Query on MG Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.94 Å
R-Value Free: 0.246 (Depositor), 0.247 (DCC)
R-Value Work: 0.206 (Depositor), 0.210 (DCC)
R-Value Observed: 0.208 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 115.246	α = 90
b = 115.246	β = 90
c = 119.229	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-10-30

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	32071476

Revision History (Full details and data files)

Version 1.0: 2024-10-30
Type: Initial release
