8VG9 | pdb_00008vg9

Crystallographic structure of Ruminococcus champanellensis xylanase (RcXyn30A)

PDB DOI: https://doi.org/10.2210/pdb8VG9/pdb

Classification: HYDROLASE
Organism(s): Ruminococcus champanellensis 18P13 = JCM 17042
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2023-12-24 Released: 2024-12-25
Deposition Author(s): Vacilotto, M.M., Araujo, E.A., Polikarpov, I.
Funding Organization(s): Sao Paulo Research Foundation (FAPESP), Brazilian National Council for Scientific and Technological Development (CNPq)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.37 Å
R-Value Free:
0.164 (Depositor), 0.164 (DCC)
R-Value Work:
0.140 (Depositor), 0.140 (DCC)
R-Value Observed:
0.141 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystallographic structure of Ruminococcus champanellensis xylanase (RcXyn30A)

Vacilotto, M.M., Araujo, E.A., Polikarpov, I.

To be published.

Macromolecule Content

Total Structure Weight: 47.07 kDa
Atom Count: 3,702
Modeled Residue Count: 398
Deposited Residue Count: 420
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
O-Glycosyl hydrolase	A	420	Ruminococcus champanellensis 18P13 = JCM 17042	Mutation(s): 0 Gene Names: RUM_18530
UniProt
Find proteins for D4LE58 (Ruminococcus champanellensis (strain DSM 18848 / JCM 17042 / KCTC 15320 / 18P13)) Explore D4LE58 Go to UniProtKB: D4LE58
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	D4LE58
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PEG (Subject of Investigation/LOI) Query on PEG Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
PO4 (Subject of Investigation/LOI) Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain N [auth A] MOL2 format, chain N [auth A] mmCIF format, chain N [auth A]	N [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain N [auth A] Interactions & Density Focus chain N [auth A]
EDO (Subject of Investigation/LOI) Query on EDO Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
NA (Subject of Investigation/LOI) Query on NA Download:Ideal Coordinates CCD File SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A] E [auth A] F [auth A] G [auth A] H [auth A] D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A]
F (Subject of Investigation/LOI) Query on F Download:Ideal Coordinates CCD File SDF format, chain L [auth A] SDF format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A]	L [auth A], M [auth A]	FLUORIDE ION F KRHYYFGTRYWZRS-UHFFFAOYSA-M		Interactions Focus chain L [auth A] Focus chain M [auth A] Interactions & Density Focus chain L [auth A] Focus chain M [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.37 Å
R-Value Free: 0.164 (Depositor), 0.164 (DCC)
R-Value Work: 0.140 (Depositor), 0.140 (DCC)
R-Value Observed: 0.141 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.62	α = 90
b = 55.019	β = 95.16
c = 63.329	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-12-25

Deposition Author(s):

Vacilotto, M.M.

Araujo, E.A.

Polikarpov, I.

Funding Organization	Location	Grant Number
Sao Paulo Research Foundation (FAPESP)	Brazil	2021/08780-1
Brazilian National Council for Scientific and Technological Development (CNPq)	Brazil	306852/2021-7
Brazilian National Council for Scientific and Technological Development (CNPq)	Brazil	440180/2022-8
