8TUF | pdb_00008tuf

Crystal structure of human norovirus RNA-dependent RNA-polymerase

PDB DOI: https://doi.org/10.2210/pdb8TUF/pdb

Classification: VIRAL PROTEIN
Organism(s): Norovirus Hu/GII.4/Sydney/NSW0514/2012/AU
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2023-08-16 Released: 2024-12-18
Deposition Author(s): Prasad, B.V.V., Kaundal, S., Sankaran, B.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.03 Å
R-Value Free:
0.242 (Depositor), 0.242 (DCC)
R-Value Work:
0.207 (Depositor), 0.211 (DCC)
R-Value Observed:
0.209 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8TUF

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of human norovirus RNA-dependent RNA-polymerase

Prasad, B.V.V., Kaundal, S., Sankaran, B.

To be published.

Macromolecule Content

Total Structure Weight: 57.39 kDa
Atom Count: 3,991
Modeled Residue Count: 491
Deposited Residue Count: 509
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
RNA-dependent RNA-polymerase	A	509	Norovirus Hu/GII.4/Sydney/NSW0514/2012/AU	Mutation(s): 0
UniProt
Find proteins for K4L8Z7 (Norovirus Hu/GII.4/Sydney/NSW0514/2012/AU) Explore K4L8Z7 Go to UniProtKB: K4L8Z7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	K4L8Z7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A]
MG (Subject of Investigation/LOI) Query on MG Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.03 Å
R-Value Free: 0.242 (Depositor), 0.242 (DCC)
R-Value Work: 0.207 (Depositor), 0.211 (DCC)
R-Value Observed: 0.209 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 83.07	α = 90
b = 83.7	β = 90
c = 90.72	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
iMOSFLM	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-12-18

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	P01 AI057788

Revision History (Full details and data files)

Version 1.0: 2024-12-18
Type: Initial release
