8T9P | pdb_00008t9p

Crystal Structure of YR, a heterohexamer of the 4-oxalocrotonate tautomerase (4-OT) family

  • Classification: ISOMERASE
  • Organism(s): Herbaspirillum
  • Expression System: Escherichia coli
  • Mutation(s): No

  • Deposited: 2023-06-24 Released: 2023-12-06
  • Deposition Author(s): Moreno, R.Y., Zhang, Y.J.
  • Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.04 Å
  • R-Value Free:
    0.230 (Depositor), 0.231 (DCC)
  • R-Value Work:
    0.192 (Depositor), 0.194 (DCC)
  • R-Value Observed:
    0.195 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8T9P

This is version 1.0 of the entry. See complete history

Literature

Introduction of Asymmetry in the Fused 4-Oxalocrotonate Tautomerases.

Erwin, K.Moreno, R.Y.Baas, B.J.Zhang, Y.J.Whitman, C.P.

(2023) Biochemistry 62: 2461-2471

  • DOI: https://doi.org/10.1021/acs.biochem.3c00180
  • Primary Citation Related Structures:
    8T9O, 8T9P, 8T9Q

  • PubMed Abstract:

    Members of the 4-oxalocrotonate tautomerase (4-OT) subgroup in the tautomerase superfamily (TSF) are constructed from a single β-α-β unit and form homo- or heterohexamers, whereas those of the other four subgroups are composed of two consecutively joined β-α-β units and form trimers. A subset of sequences, double the length of the short 4-OTs, is found in the 4-OT subgroup. These "fused" 4-OTs form a separate subgroup that connects to the short 4-OTs in a sequence similarity network (SSN). The fused gene can be a template for the other four subgroups, resulting in the diversification of activity. Analysis of the SSN shows that multiple nodes in the fused 4-OTs connect to five linker nodes, which in turn connect to the short 4-OTs. Some fused 4-OTs are symmetric trimers and others are asymmetric trimers. The origin of this asymmetry was investigated by subjecting the sequences in three linker nodes and a closely associated fourth node to kinetic, mutagenic, and structural analyses. The results show that each sequence corresponds to the α- or β-subunit of a heterohexamer that functions as a 4-OT. Mutagenesis indicates that the key residues in both are αPro1 and βArg-11, like that of a typical 4-OT. Crystallographic analysis shows that both heterohexamers are asymmetric, where one heterodimer is flipped 180° relative to the other two heterodimers. The fusion of two subunits (α and β) of one asymmetric heterohexamer generates an asymmetric trimer with 4-OT activity. Hence, asymmetry can be introduced at the heterohexamer level and then retained in the fused trimers.

Macromolecule Content

  • Total Structure Weight: 43.8 kDa
  • Atom Count: 3,156
  • Modeled Residue Count: 403
  • Deposited Residue Count: 417
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Tautomerase beta subunit
A, E, F
74HerbaspirillumMutation(s): 0
Gene Names: PMI40_00695
UniProt
Find proteins for A0ACD6B9Q8 (Herbaspirillum sp. YR522)
Explore A0ACD6B9Q8
Go to UniProtKB:  A0ACD6B9Q8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ACD6B9Q8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Tautomerase alpha subunit
B, C, D
65HerbaspirillumMutation(s): 0
Gene Names: PMI40_00696
UniProt
Find proteins for A0ACD6B9Q9 (Herbaspirillum sp. YR522)
Explore A0ACD6B9Q9
Go to UniProtKB:  A0ACD6B9Q9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ACD6B9Q9
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.04 Å
  • R-Value Free:  0.230 (Depositor), 0.231 (DCC)
  • R-Value Work:  0.192 (Depositor), 0.194 (DCC)
  • R-Value Observed: 0.195 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 110.194α = 90
b = 61.028β = 123.82
c = 92.141γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data scaling
HKL-2000data reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM-104896

Revision History  (Full details and data files)

  • Version 1.0: 2023-12-06
    Type: Initial release
