8T86

Racemic mixture of amylin segment 25-AILSS-29 forms heterochiral rippled beta-sheet


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.10 Å
  • R-Value Free: 0.179
  • R-Value Work: 0.152

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Racemic Peptides from Amyloid beta and Amylin Form Rippled beta-Sheets Rather Than Pleated beta-Sheets.

Hazari, A.Sawaya, M.R.Sajimon, M.Vlahakis, N.Rodriguez, J.Eisenberg, D.Raskatov, J.A.

(2023) J Am Chem Soc 145: 25917-25926

  • DOI: https://doi.org/10.1021/jacs.3c11712
  • Primary Citation of Related Structures:
    8T82, 8T84, 8T86, 8T89

  • PubMed Abstract:

    The rippled β-sheet was theorized by Pauling and Corey in 1953 as a structural motif in which mirror image peptide strands assemble into hydrogen-bonded periodic arrays with strictly alternating chirality. Structural characterization of the rippled β-sheet was limited to biophysical methods until 2022 when atomic resolution structures of the motif were first obtained. The crystal structural foundation is restricted to four model tripeptides composed exclusively of aromatic residues. Here, we report five new rippled sheet crystal structures derived from amyloid β and amylin, the aggregating toxic peptides of Alzheimer's disease and type II diabetes, respectively. Despite the variation in peptide sequence composition, all five structures form antiparallel rippled β-sheets that extend, like a fibril, along the entire length of the crystalline needle. The long-range packing of the crystals, however, varies. In three of the crystals, the sheets pack face-to-face and exclude water, giving rise to cross-β architectures grossly resembling the steric zipper motif of amyloid fibrils but differing in fundamental details. In the other two crystals, the solvent is encapsulated between the sheets, yielding fibril architectures capable of host-guest chemistry. Our study demonstrates that the formation of rippled β-sheets from aggregating racemic peptide mixtures in three-dimensional (3D) assemblies is a general phenomenon and provides a structural basis for targeting intrinsically disordered proteins.


  • Organizational Affiliation

    Dept. of Chemistry and Biochemistry, UCSC, 1156 High Street, Santa Cruz, California 95064, United States.


Macromolecules

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Racemic mixture of amylin segment 25-AILSS-295Homo sapiensMutation(s): 0
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.10 Å
  • R-Value Free: 0.179
  • R-Value Work: 0.152
  • Space Group: P -1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 9.5α = 90.452
b = 9.88β = 98.132
c = 16.29γ = 94.376
Software Package:
Software NamePurpose
REFMACrefinement
XSCALEdata scaling
XDSdata reduction
SHELXDphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute on Aging (NIH/NIA)United StatesAG074954

Revision History  (Full details and data files)

  • Version 1.0: 2023-11-29
    Type: Initial release
  • Version 1.1: 2023-12-13
    Changes: Database references
