8T5J | pdb_00008t5j

Crystal structure of outer membrane lipoprotein carrier protein (LolA) from Francisella philomiragia

PDB DOI: https://doi.org/10.2210/pdb8T5J/pdb

Classification: LIPID TRANSPORT
Organism(s): Francisella philomiragia
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2023-06-13 Released: 2023-06-28
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.55 Å
R-Value Free:
0.208 (Depositor), 0.216 (DCC)
R-Value Work:
0.170 (Depositor), 0.180 (DCC)
R-Value Observed:
0.172 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8T5J

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of outer membrane lipoprotein carrier protein (LolA) from Francisella philomiragia

Woodward, E.L., Lovell, S., Cooper, A., Buchko, G.

To be published.

Macromolecule Content

Total Structure Weight: 22.91 kDa
Atom Count: 1,483
Modeled Residue Count: 154
Deposited Residue Count: 197
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Outer membrane lipocarrier LolA family protein	A	197	Francisella philomiragia	Mutation(s): 0 Gene Names: Fphi_1079
UniProt
Find proteins for B0TX44 (Francisella philomiragia subsp. philomiragia (strain ATCC 25017 / CCUG 19701 / FSC 153 / O#319-036)) Explore B0TX44 Go to UniProtKB: B0TX44
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	B0TX44
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
1PE Query on 1PE Download:Ideal Coordinates CCD File SDF format, chain I [auth A] MOL2 format, chain I [auth A] mmCIF format, chain I [auth A]	I [auth A]	PENTAETHYLENE GLYCOL C₁₀ H₂₂ O₆ JLFNLZLINWHATN-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Interactions & Density Focus chain I [auth A]
HEZ Query on HEZ Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A]	F [auth A], G [auth A], H [auth A]	HEXANE-1,6-DIOL C₆ H₁₄ O₂ XXMIOPMDWAUFGU-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.55 Å
R-Value Free: 0.208 (Depositor), 0.216 (DCC)
R-Value Work: 0.170 (Depositor), 0.180 (DCC)
R-Value Observed: 0.172 (Depositor)

Diffraction Data:

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 61.85	α = 90
b = 61.85	β = 90
c = 86.611	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
SAINT	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-06-28

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201700059C

Revision History (Full details and data files)

Version 1.0: 2023-06-28
Type: Initial release
Version 1.1: 2024-05-22
Changes: Data collection
