8STH | pdb_00008sth

human STING with diABZI agonist 15


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.97 Å
  • R-Value Free:
    0.247 (Depositor), 0.250 (DCC)
  • R-Value Work:
    0.204 (Depositor), 0.213 (DCC)
  • R-Value Observed:
    0.209 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 8STH

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Discovery and Optimization of a STING Agonist Platform for Application in Antibody Drug Conjugates.

Duvall, J.R.Thomas, J.D.Bukhalid, R.A.Catcott, K.C.Bentley, K.W.Collins, S.D.Eitas, T.Jones, B.D.Kelleher, E.W.Lancaster, K.Protopopova, M.Ray, S.S.Ter-Ovanesyan, E.Xu, L.Yang, L.Zurita, J.Damelin, M.Toader, D.Lowinger, T.B.

(2023) J Med Chem 66: 10715-10733

  • DOI: https://doi.org/10.1021/acs.jmedchem.3c00907
  • Primary Citation Related Structures:
    8STH, 8STI

  • PubMed Abstract:

    While STING agonists have proven to be effective preclinically as anti-tumor agents, these promising results have yet to be translated in the clinic. A STING agonist antibody-drug conjugate (ADC) could overcome current limitations by improving tumor accessibility, allowing for systemic administration as well as tumor-localized activation of STING for greater anti-tumor activity and better tolerability. In line with this effort, a STING agonist ADC platform was identified through systematic optimization of the payload, linker, and scaffold based on multiple factors including potency and specificity in both in vitro and in vivo evaluations. The platform employs a potent non-cyclic dinucleotide STING agonist, a cleavable ester-based linker, and a hydrophilic PEG8-bisglucamine scaffold. A tumor-targeted ADC built with the resulting STING agonist platform induced robust and durable anti-tumor activity and demonstrated high stability and favorable pharmacokinetics in nonclinical species.


  • Organizational Affiliation
    • Mersana Therapeutics, Inc., 840 Memorial Drive, Cambridge, Massachusetts 02139, United States.

Macromolecule Content

  • Total Structure Weight: 22.27 kDa
  • Atom Count: 1,688
  • Modeled Residue Count: 173
  • Deposited Residue Count: 187
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Stimulator of interferon genes protein187Homo sapiensMutation(s): 1
Gene Names: STING1ERISMITASTINGTMEM173
UniProt & NIH Common Fund Data Resources
Find proteins for Q86WV6 (Homo sapiens)
Explore Q86WV6
Go to UniProtKB:  Q86WV6
PHAROS:  Q86WV6
GTEx:  ENSG00000184584
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ86WV6
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
WWU
(Subject of Investigation/LOI)

Query on WWU



Download:Ideal Coordinates CCD File
B [auth A]1-[(2E)-4-{5-carbamoyl-2-[(4-ethyl-2-methyl-1,3-oxazole-5-carbonyl)amino]-7-(3-hydroxypropoxy)-1H-benzimidazol-1-yl}but-2-en-1-yl]-2-[(4-ethyl-2-methyl-1,3-oxazole-5-carbonyl)amino]-7-methoxy-1H-benzimidazole-5-carboxamide
C38 H42 N10 O9
KOGNEAQPTHRJQM-CMDGGOBGSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
WWU BindingDB:  8STH EC50: 1 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.97 Å
  • R-Value Free:  0.247 (Depositor), 0.250 (DCC)
  • R-Value Work:  0.204 (Depositor), 0.213 (DCC)
  • R-Value Observed: 0.209 (Depositor)
Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 112.55α = 90
b = 112.55β = 90
c = 36.195γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XSCALEdata scaling
REFMACrefinement
REFMACphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2023-07-26
    Type: Initial release
  • Version 1.1: 2023-08-02
    Changes: Database references
  • Version 1.2: 2023-08-16
    Changes: Data collection, Database references
