8RAS | pdb_00008ras

Plastid-encoded RNA polymerase transcription elongation complex


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.62 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8RAS

This is version 1.2 of the entry. See complete history

Literature

Structure of the plant plastid-encoded RNA polymerase.

Vergara-Cruces, A.Pramanick, I.Pearce, D.Vogirala, V.K.Byrne, M.J.Low, J.K.K.Webster, M.W.

(2024) Cell 187: 1145-1159.e21

  • DOI: https://doi.org/10.1016/j.cell.2024.01.036
  • Primary Citation Related Structures:
    8R5O, 8R6S, 8RAS, 8RDJ

  • PubMed Abstract:

    Chloroplast genes encoding photosynthesis-associated proteins are predominantly transcribed by the plastid-encoded RNA polymerase (PEP). PEP is a multi-subunit complex composed of plastid-encoded subunits similar to bacterial RNA polymerases (RNAPs) stably bound to a set of nuclear-encoded PEP-associated proteins (PAPs). PAPs are essential to PEP activity and chloroplast biogenesis, but their roles are poorly defined. Here, we present cryoelectron microscopy (cryo-EM) structures of native 21-subunit PEP and a PEP transcription elongation complex from white mustard (Sinapis alba). We identify that PAPs encase the core polymerase, forming extensive interactions that likely promote complex assembly and stability. During elongation, PAPs interact with DNA downstream of the transcription bubble and with the nascent mRNA. The models reveal details of the superoxide dismutase, lysine methyltransferase, thioredoxin, and amino acid ligase enzymes that are subunits of PEP. Collectively, these data provide a foundation for the mechanistic understanding of chloroplast transcription and its role in plant growth and adaptation.


  • Organizational Affiliation
    • Department of Biochemistry and Metabolism, John Innes Centre, Norwich Research Park, Norwich, NR4 7UH, UK.

Macromolecule Content

  • Total Structure Weight: 1,277.08 kDa
  • Atom Count: 57,315
  • Modeled Residue Count: 6,910
  • Deposited Residue Count: 10,846
  • Unique protein chains: 18
  • Unique nucleic acid chains: 3

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit alpha
A, B
327Sinapis albaMutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q9XQN8 (Sinapis alba)
Explore Q9XQN8
Go to UniProtKB:  Q9XQN8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9XQN8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit beta1,072Sinapis albaMutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for P46818 (Sinapis alba)
Explore P46818
Go to UniProtKB:  P46818
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP46818
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit beta'680Sinapis albaMutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for A0A6C0M5W0 (Sinapis alba)
Explore A0A6C0M5W0
Go to UniProtKB:  A0A6C0M5W0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A6C0M5W0
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit beta''1,373Sinapis albaMutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for A0A6C0M829 (Sinapis alba)
Explore A0A6C0M829
Go to UniProtKB:  A0A6C0M829
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A6C0M829
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP1911Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 6
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP2862Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 7
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP3675Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 8
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP4263Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 9
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP5529Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 10
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP6460Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 11
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP7483Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 12
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP8334Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 13
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP9297Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 14
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP10
O, P
185Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 15
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP11768Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 16
MoleculeChains  Sequence LengthOrganismDetailsImage
PAP12162Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 17
MoleculeChains  Sequence LengthOrganismDetailsImage
FLN2611Sinapis albaMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 18
MoleculeChains  Sequence LengthOrganismDetailsImage
PTAC18140Sinapis albaMutation(s): 0
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 19
MoleculeChains LengthOrganismImage
DNA (81-MER)U [auth X]81DNA molecule
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 20
MoleculeChains LengthOrganismImage
DNA (81-MER)V [auth Y]81DNA molecule
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 21
MoleculeChains LengthOrganismImage
RNA (40-MER)W [auth Z]40synthetic construct
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SAH
(Subject of Investigation/LOI)

Query on SAH



Download:Ideal Coordinates CCD File
AA [auth L]S-ADENOSYL-L-HOMOCYSTEINE
C14 H20 N6 O5 S
ZJUKTBDSGOFHSH-WFMPWKQPSA-N
ZN
(Subject of Investigation/LOI)

Query on ZN



Download:Ideal Coordinates CCD File
Y [auth E]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
FE
(Subject of Investigation/LOI)

Query on FE



Download:Ideal Coordinates CCD File
BA [auth N],
Z [auth I]
FE (III) ION
Fe
VTLYFUHAOXGGBS-UHFFFAOYSA-N
MG
(Subject of Investigation/LOI)

Query on MG



Download:Ideal Coordinates CCD File
X [auth D]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.62 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.20.1_4487

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomBB/P013511/1
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomBB/X01102X/1
Royal SocietyUnited KingdomRGS/R2/222157
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomNT33824

Revision History  (Full details and data files)

  • Version 1.0: 2024-03-06
    Type: Initial release
  • Version 1.1: 2024-03-13
    Changes: Database references
  • Version 1.2: 2025-12-10
    Changes: Data collection, Structure summary
