8R5C | pdb_00008r5c

Crystal structure of human TRIM7 PRYSPRY domain bound to (2-(1-oxoisoindolin-2-yl)-3-phenylpropanoyl)-L-glutamine


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:
    0.179 (Depositor), 0.194 (DCC)
  • R-Value Work:
    0.139 (Depositor)
  • R-Value Observed:
    0.141 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8R5C

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

A C-Degron Structure-Based Approach for the Development of Ligands Targeting the E3 Ligase TRIM7.

Munoz Sosa, C.J.Lenz, C.Hamann, A.Farges, F.Dopfer, J.Kramer, A.Cherkashyna, V.Tarnovskiy, A.Moroz, Y.S.Proschak, E.Nemec, V.Muller, S.Saxena, K.Knapp, S.

(2024) ACS Chem Biol 19: 1638-1647

  • DOI: https://doi.org/10.1021/acschembio.4c00301
  • Primary Citation Related Structures:
    8R5C, 8R5D

  • PubMed Abstract:

    TRIM7 is a ubiquitin E3 ligase with key regulatory functions, mediating viral infection, tumor biology, innate immunity, and cellular processes, such as autophagy and ferroptosis. It contains a PRYSPRY domain that specifically recognizes degron sequences containing C-terminal glutamine. Ligands that bind to the TRIM7 PRYSPRY domain may have applications in the treatment of viral infections, as modulators of inflammation, and in the design of a new class of PROTACs (PROteolysis TArgeting Chimeras) that mediate the selective degradation of therapeutically relevant proteins (POIs). Here, we developed an assay toolbox for the comprehensive evaluation of TRIM7 ligands. Using TRIM7 degron sequences together with a structure-based design, we developed the first series of peptidomimetic ligands with low micromolar affinity. The terminal carboxylate moiety was required for ligand activity but prevented cell penetration. A prodrug strategy using an ethyl ester resulted in enhanced permeability, which was evaluated using confocal imaging.


  • Organizational Affiliation
    • Institute for Pharmaceutical Chemistry, Johann Wolfgang Goethe-University, Max-von-Laue-Straße 9, 60438 Frankfurt am Main, Germany.

Macromolecule Content

  • Total Structure Weight: 20.64 kDa
  • Atom Count: 1,595
  • Modeled Residue Count: 172
  • Deposited Residue Count: 175
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
E3 ubiquitin-protein ligase TRIM7175Homo sapiensMutation(s): 0
Gene Names: TRIM7
EC: 2.3.2.27
UniProt & NIH Common Fund Data Resources
Find proteins for Q9C029 (Homo sapiens)
Explore Q9C029
Go to UniProtKB:  Q9C029
PHAROS:  Q9C029
GTEx:  ENSG00000146054
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9C029
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Y3C
(Subject of Investigation/LOI)

Query on Y3C



Download:Ideal Coordinates CCD File
B [auth A](2~{S})-5-azanyl-5-oxidanylidene-2-[[(2~{S})-2-(3-oxidanylidene-1~{H}-isoindol-2-yl)-3-phenyl-propanoyl]amino]pentanoic acid
C22 H23 N3 O5
HSTLLKBRGCBKBS-ROUUACIJSA-N
SRT

Query on SRT



Download:Ideal Coordinates CCD File
F [auth A],
G [auth A]
S,R MESO-TARTARIC ACID
C4 H6 O6
FEWJPZIEWOKRBE-XIXRPRMCSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
C [auth A],
D [auth A],
E [auth A]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:  0.179 (Depositor), 0.194 (DCC)
  • R-Value Work:  0.139 (Depositor)
  • R-Value Observed: 0.141 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 83.716α = 90
b = 44.594β = 108.79
c = 59.657γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
Aimlessdata scaling
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Innovative Medicines InitiativeSwitzerland875510

Revision History  (Full details and data files)

  • Version 1.0: 2024-01-17
    Type: Initial release
  • Version 1.1: 2024-07-31
    Changes: Database references
