8QZT | pdb_00008qzt

Single particle cryo-EM co-structure of E. coli AcrB with bound BDM91531 inhibitor at 3.52 A resolution

PDB DOI: https://doi.org/10.2210/pdb8QZT/pdb
EM Map EMD-18782: EMDB EMDataResource

Classification: TRANSPORT PROTEIN
Organism(s): Escherichia coli K-12
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No
Membrane Protein: Yes PDBTM

Deposited: 2023-10-29 Released: 2024-11-06
Deposition Author(s): Boernsen, C., Mueller, R.T., Pos, K.M., Frangakis, A.S.
Funding Organization(s): German Federal Ministry for Education and Research, Agence Nationale de la Recherche (ANR)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.52 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8QZT

This is version 1.0 of the entry. See complete history.

Literature

Single particle cryo-EM co-structure of E. coli AcrB with bound BDM91531 inhibitor at 3.52 A resolution

Boernsen, C., Mueller, R.T.

To be published.

Macromolecule Content

Total Structure Weight: 341.7 kDa
Atom Count: 23,460
Modeled Residue Count: 3,079
Deposited Residue Count: 3,147
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Multidrug efflux pump subunit AcrB	A, B, C	1,049	Escherichia coli K-12	Mutation(s): 0 Gene Names: acrB Membrane Entity: Yes
UniProt
Find proteins for P31224 (Escherichia coli (strain K12)) Explore P31224 Go to UniProtKB: P31224
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P31224
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
XE9 (Subject of Investigation/LOI) Query on XE9 Download:Ideal Coordinates CCD File SDF format, chain E [auth C] SDF format, chain D [auth A] MOL2 format, chain E [auth C] MOL2 format, chain D [auth A] mmCIF format, chain E [auth C] mmCIF format, chain D [auth A]	D [auth A], E [auth C]	[3-(3-chloranyl-2-piperazin-1-yl-quinolin-6-yl)phenyl]methanamine C₂₀ H₂₁ Cl N₄ PMBAQAZUQBDHLD-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth C] Interactions & Density Focus chain D [auth A] Focus chain E [auth C]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.52 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC	4

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-11-06

Deposition Author(s):

Frangakis, A.S.

Funding Organization	Location	Grant Number
German Federal Ministry for Education and Research	Germany	BMBF- 16GW0236K
Agence Nationale de la Recherche (ANR)	France	ANR-19-AMRB-0007

Revision History (Full details and data files)

Version 1.0: 2024-11-06
Type: Initial release
