8QBY

Respiratory complex I from Paracoccus denitrificans in MSP2N2 nanodiscs

PDB DOI: https://doi.org/10.2210/pdb8QBY/pdb
EM Map EMD-18324: EMDB EMDataResource

Classification: OXIDOREDUCTASE
Organism(s): Paracoccus denitrificans PD1222
Mutation(s): No
Membrane Protein: Yes PDBTM

Deposited: 2023-08-25 Released: 2024-09-11
Deposition Author(s): Ivanov, B.S., Bridges, H.R., Hirst, J.
Funding Organization(s): Medical Research Council (MRC, United Kingdom)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.30 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Respiratory complex I from Paracoccus denitrificans

Ivanov, B.S., Bridges, H.R., Hirst, J., Jarman, O.D.

To be published.

Macromolecule Content

Total Structure Weight: 614.71 kDa
Atom Count: 42,542
Modelled Residue Count: 5,133
Deposited Residue Count: 5,290
Unique protein chains: 18

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-quinone oxidoreductase subunit K	A [auth K]	101	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 7.1.1 Membrane Entity: Yes
UniProt
Find proteins for A1B482 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B482 Go to UniProtKB: A1B482
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B482
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-quinone oxidoreductase	B [auth G]	674	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 7.1.1
UniProt
Find proteins for A1B489 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B489 Go to UniProtKB: A1B489
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B489
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein-L-isoaspartate O-methyltransferase	C [auth t]	217	Paracoccus denitrificans PD1222	Mutation(s): 0
UniProt
Find proteins for A1B5L6 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B5L6 Go to UniProtKB: A1B5L6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B5L6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-quinone oxidoreductase subunit I	D [auth I]	163	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 7.1.1 Membrane Entity: Yes
UniProt
Find proteins for A1B486 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B486 Go to UniProtKB: A1B486
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B486
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH dehydrogenase subunit E	E	239	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 1.6.5.3
UniProt
Find proteins for A1B494 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B494 Go to UniProtKB: A1B494
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B494
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 6
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-quinone oxidoreductase subunit N	F [auth N]	499	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 7.1.1 Membrane Entity: Yes
UniProt
Find proteins for A1B479 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B479 Go to UniProtKB: A1B479
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B479
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 7
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-quinone oxidoreductase subunit H	G [auth H]	345	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 7.1.1 Membrane Entity: Yes
UniProt
Find proteins for A1B487 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B487 Go to UniProtKB: A1B487
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B487
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 8
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-quinone oxidoreductase subunit F	H [auth F]	431	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 7.1.1
UniProt
Find proteins for A1B491 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B491 Go to UniProtKB: A1B491
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B491
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 9
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-quinone oxidoreductase subunit D	I [auth D]	412	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 7.1.1 Membrane Entity: Yes
UniProt
Find proteins for A1B495 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B495 Go to UniProtKB: A1B495
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B495
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 10
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH:ubiquinone oxidoreductase 17.2 kD subunit	J [auth q]	124	Paracoccus denitrificans PD1222	Mutation(s): 0
UniProt
Find proteins for A1B1H8 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B1H8 Go to UniProtKB: A1B1H8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B1H8
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 11
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-quinone oxidoreductase subunit A	K [auth A]	121	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 7.1.1 Membrane Entity: Yes
UniProt
Find proteins for A1B498 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B498 Go to UniProtKB: A1B498
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B498
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 12
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-quinone oxidoreductase chain 10	L [auth J]	200	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 7.1.1 Membrane Entity: Yes
UniProt
Find proteins for A1B483 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B483 Go to UniProtKB: A1B483
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B483
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 13
Molecule	Chains	Sequence Length	Organism	Details	Image
Zinc finger CHCC-type domain-containing protein	M [auth R]	62	Paracoccus denitrificans PD1222	Mutation(s): 0
UniProt
Find proteins for A1B357 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B357 Go to UniProtKB: A1B357
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B357
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 14
Molecule	Chains	Sequence Length	Organism	Details	Image
ETC complex I subunit conserved region	N [auth Q]	103	Paracoccus denitrificans PD1222	Mutation(s): 0 Membrane Entity: Yes
UniProt
Find proteins for A1B1M0 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B1M0 Go to UniProtKB: A1B1M0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B1M0
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 15
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-quinone oxidoreductase subunit C	O [auth C]	208	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 7.1.1 Membrane Entity: Yes
UniProt
Find proteins for A1B496 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B496 Go to UniProtKB: A1B496
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B496
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 16
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH-quinone oxidoreductase subunit B	P [auth B]	175	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 7.1.1 Membrane Entity: Yes
UniProt
Find proteins for A1B497 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B497 Go to UniProtKB: A1B497
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B497
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 17
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH dehydrogenase subunit L	Q [auth L]	703	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 1.6.5.3 Membrane Entity: Yes
UniProt
Find proteins for A1B481 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B481 Go to UniProtKB: A1B481
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B481
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 18
Molecule	Chains	Sequence Length	Organism	Details	Image
NADH dehydrogenase subunit M	R [auth M]	513	Paracoccus denitrificans PD1222	Mutation(s): 0 EC: 1.6.5.3 Membrane Entity: Yes
UniProt
Find proteins for A1B480 (Paracoccus denitrificans (strain Pd 1222)) Explore A1B480 Go to UniProtKB: A1B480
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A1B480
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 12 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CDL Query on CDL Download Ideal Coordinates CCD File SDF format, chain JA [auth H] SDF format, chain LB [auth M] MOL2 format, chain JA [auth H] MOL2 format, chain LB [auth M] mmCIF format, chain JA [auth H] mmCIF format, chain LB [auth M]	JA [auth H], LB [auth M]	CARDIOLIPIN C₈₁ H₁₅₆ O₁₇ P₂ XVTUQDWPJJBEHJ-KZCWQMDCSA-L		Interactions Focus chain JA [auth H] Focus chain LB [auth M] Interactions & Density Focus chain JA [auth H] Focus chain LB [auth M]
U10 Query on U10 Download Ideal Coordinates CCD File SDF format, chain YA [auth B] MOL2 format, chain YA [auth B] mmCIF format, chain YA [auth B]	YA [auth B]	UBIQUINONE-10 C₅₉ H₉₀ O₄ ACTIUHUUMQJHFO-UPTCCGCDSA-N		Interactions Focus chain YA [auth B] Interactions & Density Focus chain YA [auth B]
P5S Query on P5S Download Ideal Coordinates CCD File SDF format, chain CB [auth L] SDF format, chain Z [auth I] MOL2 format, chain CB [auth L] MOL2 format, chain Z [auth I] mmCIF format, chain CB [auth L] mmCIF format, chain Z [auth I]	CB [auth L], Z [auth I]	O-[(R)-{[(2R)-2,3-bis(octadecanoyloxy)propyl]oxy}(hydroxy)phosphoryl]-L-serine C₄₂ H₈₂ N O₁₀ P TZCPCKNHXULUIY-RGULYWFUSA-N		Interactions Focus chain CB [auth L] Focus chain Z [auth I] Interactions & Density Focus chain CB [auth L] Focus chain Z [auth I]
PC1 Query on PC1 Download Ideal Coordinates CCD File SDF format, chain QA [auth D] SDF format, chain UA [auth J] MOL2 format, chain QA [auth D] MOL2 format, chain UA [auth J] mmCIF format, chain QA [auth D] mmCIF format, chain UA [auth J]	QA [auth D], UA [auth J]	1,2-DIACYL-SN-GLYCERO-3-PHOSPHOCHOLINE C₄₄ H₈₈ N O₈ P NRJAVPSFFCBXDT-HUESYALOSA-N		Interactions Focus chain QA [auth D] Focus chain UA [auth J] Interactions & Density Focus chain QA [auth D] Focus chain UA [auth J]
3PE Query on 3PE Download Ideal Coordinates CCD File SDF format, chain CA [auth N] SDF format, chain DB [auth L] SDF format, chain EA [auth N] SDF format, chain FA [auth N] SDF format, chain HB [auth M] SDF format, chain IA [auth H] SDF format, chain JB [auth M] SDF format, chain KB [auth M] SDF format, chain MA [auth H] SDF format, chain SA [auth q] MOL2 format, chain CA [auth N] MOL2 format, chain DB [auth L] MOL2 format, chain EA [auth N] MOL2 format, chain FA [auth N] MOL2 format, chain HB [auth M] MOL2 format, chain IA [auth H] MOL2 format, chain JB [auth M] MOL2 format, chain KB [auth M] MOL2 format, chain MA [auth H] MOL2 format, chain SA [auth q] mmCIF format, chain CA [auth N] mmCIF format, chain DB [auth L] mmCIF format, chain EA [auth N] mmCIF format, chain FA [auth N] mmCIF format, chain HB [auth M] mmCIF format, chain IA [auth H] mmCIF format, chain JB [auth M] mmCIF format, chain KB [auth M] mmCIF format, chain MA [auth H] mmCIF format, chain SA [auth q]	CA [auth N] DB [auth L] EA [auth N] FA [auth N] HB [auth M] CA [auth N], DB [auth L], EA [auth N], FA [auth N], HB [auth M], IA [auth H], JB [auth M], KB [auth M], MA [auth H], SA [auth q]	1,2-Distearoyl-sn-glycerophosphoethanolamine C₄₁ H₈₂ N O₈ P LVNGJLRDBYCPGB-LDLOPFEMSA-N		Interactions Focus chain CA [auth N] Focus chain DB [auth L] Focus chain EA [auth N] Focus chain FA [auth N] Focus chain HB [auth M] Focus chain IA [auth H] Focus chain JB [auth M] Focus chain KB [auth M] Focus chain MA [auth H] Focus chain SA [auth q] Interactions & Density Focus chain CA [auth N] Focus chain DB [auth L] Focus chain EA [auth N] Focus chain FA [auth N] Focus chain HB [auth M] Focus chain IA [auth H] Focus chain JB [auth M] Focus chain KB [auth M] Focus chain MA [auth H] Focus chain SA [auth q]
3PH Query on 3PH Download Ideal Coordinates CCD File SDF format, chain AB [auth L] SDF format, chain BB [auth L] SDF format, chain DA [auth N] SDF format, chain EB [auth L] SDF format, chain FB [auth L] SDF format, chain GA [auth N] SDF format, chain GB [auth M] SDF format, chain IB [auth M] SDF format, chain KA [auth H] SDF format, chain LA [auth H] SDF format, chain MB [auth M] SDF format, chain NA [auth H] SDF format, chain NB [auth M] SDF format, chain TA [auth A] SDF format, chain VA [auth J] SDF format, chain WA [auth J] SDF format, chain Y [auth I] MOL2 format, chain AB [auth L] MOL2 format, chain BB [auth L] MOL2 format, chain DA [auth N] MOL2 format, chain EB [auth L] MOL2 format, chain FB [auth L] MOL2 format, chain GA [auth N] MOL2 format, chain GB [auth M] MOL2 format, chain IB [auth M] MOL2 format, chain KA [auth H] MOL2 format, chain LA [auth H] MOL2 format, chain MB [auth M] MOL2 format, chain NA [auth H] MOL2 format, chain NB [auth M] MOL2 format, chain TA [auth A] MOL2 format, chain VA [auth J] MOL2 format, chain WA [auth J] MOL2 format, chain Y [auth I] mmCIF format, chain AB [auth L] mmCIF format, chain BB [auth L] mmCIF format, chain DA [auth N] mmCIF format, chain EB [auth L] mmCIF format, chain FB [auth L] mmCIF format, chain GA [auth N] mmCIF format, chain GB [auth M] mmCIF format, chain IB [auth M] mmCIF format, chain KA [auth H] mmCIF format, chain LA [auth H] mmCIF format, chain MB [auth M] mmCIF format, chain NA [auth H] mmCIF format, chain NB [auth M] mmCIF format, chain TA [auth A] mmCIF format, chain VA [auth J] mmCIF format, chain WA [auth J] mmCIF format, chain Y [auth I]	AB [auth L] BB [auth L] DA [auth N] EB [auth L] FB [auth L] AB [auth L], BB [auth L], DA [auth N], EB [auth L], FB [auth L], GA [auth N], GB [auth M], IB [auth M], KA [auth H], LA [auth H], MB [auth M], NA [auth H], NB [auth M], TA [auth A], VA [auth J], WA [auth J], Y [auth I]	1,2-DIACYL-GLYCEROL-3-SN-PHOSPHATE C₃₉ H₇₇ O₈ P YFWHNAWEOZTIPI-DIPNUNPCSA-N		Interactions Focus chain AB [auth L] Focus chain BB [auth L] Focus chain DA [auth N] Focus chain EB [auth L] Focus chain FB [auth L] Focus chain GA [auth N] Focus chain GB [auth M] Focus chain IB [auth M] Focus chain KA [auth H] Focus chain LA [auth H] Focus chain MB [auth M] Focus chain NA [auth H] Focus chain NB [auth M] Focus chain TA [auth A] Focus chain VA [auth J] Focus chain WA [auth J] Focus chain Y [auth I] Interactions & Density Focus chain AB [auth L] Focus chain BB [auth L] Focus chain DA [auth N] Focus chain EB [auth L] Focus chain FB [auth L] Focus chain GA [auth N] Focus chain GB [auth M] Focus chain IB [auth M] Focus chain KA [auth H] Focus chain LA [auth H] Focus chain MB [auth M] Focus chain NA [auth H] Focus chain NB [auth M] Focus chain TA [auth A] Focus chain VA [auth J] Focus chain WA [auth J] Focus chain Y [auth I]
FMN Query on FMN Download Ideal Coordinates CCD File SDF format, chain OA [auth F] MOL2 format, chain OA [auth F] mmCIF format, chain OA [auth F]	OA [auth F]	FLAVIN MONONUCLEOTIDE C₁₇ H₂₁ N₄ O₉ P FVTCRASFADXXNN-SCRDCRAPSA-N		Interactions Focus chain OA [auth F] Interactions & Density Focus chain OA [auth F]
SF4 Query on SF4 Download Ideal Coordinates CCD File SDF format, chain PA [auth F] SDF format, chain S [auth G] SDF format, chain T [auth G] SDF format, chain W [auth I] SDF format, chain X [auth I] SDF format, chain ZA [auth B] MOL2 format, chain PA [auth F] MOL2 format, chain S [auth G] MOL2 format, chain T [auth G] MOL2 format, chain W [auth I] MOL2 format, chain X [auth I] MOL2 format, chain ZA [auth B] mmCIF format, chain PA [auth F] mmCIF format, chain S [auth G] mmCIF format, chain T [auth G] mmCIF format, chain W [auth I] mmCIF format, chain X [auth I] mmCIF format, chain ZA [auth B]	PA [auth F] S [auth G] T [auth G] W [auth I] X [auth I] PA [auth F], S [auth G], T [auth G], W [auth I], X [auth I], ZA [auth B]	IRON/SULFUR CLUSTER Fe₄ S₄ LJBDFODJNLIPKO-UHFFFAOYSA-N		Interactions Focus chain PA [auth F] Focus chain S [auth G] Focus chain T [auth G] Focus chain W [auth I] Focus chain X [auth I] Focus chain ZA [auth B] Interactions & Density Focus chain PA [auth F] Focus chain S [auth G] Focus chain T [auth G] Focus chain W [auth I] Focus chain X [auth I] Focus chain ZA [auth B]
FES Query on FES Download Ideal Coordinates CCD File SDF format, chain BA [auth E] SDF format, chain U [auth G] MOL2 format, chain BA [auth E] MOL2 format, chain U [auth G] mmCIF format, chain BA [auth E] mmCIF format, chain U [auth G]	BA [auth E], U [auth G]	FE2/S2 (INORGANIC) CLUSTER Fe₂ S₂ NIXDOXVAJZFRNF-UHFFFAOYSA-N		Interactions Focus chain BA [auth E] Focus chain U [auth G] Interactions & Density Focus chain BA [auth E] Focus chain U [auth G]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain XA [auth R] MOL2 format, chain XA [auth R] mmCIF format, chain XA [auth R]	XA [auth R]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain XA [auth R] Interactions & Density Focus chain XA [auth R]
CA Query on CA Download Ideal Coordinates CCD File SDF format, chain AA [auth I] SDF format, chain HA [auth N] SDF format, chain OB [auth M] SDF format, chain RA [auth D] MOL2 format, chain AA [auth I] MOL2 format, chain HA [auth N] MOL2 format, chain OB [auth M] MOL2 format, chain RA [auth D] mmCIF format, chain AA [auth I] mmCIF format, chain HA [auth N] mmCIF format, chain OB [auth M] mmCIF format, chain RA [auth D]	AA [auth I], HA [auth N], OB [auth M], RA [auth D]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain AA [auth I] Focus chain HA [auth N] Focus chain OB [auth M] Focus chain RA [auth D] Interactions & Density Focus chain AA [auth I] Focus chain HA [auth N] Focus chain OB [auth M] Focus chain RA [auth D]
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain V [auth G] MOL2 format, chain V [auth G] mmCIF format, chain V [auth G]	V [auth G]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain V [auth G] Interactions & Density Focus chain V [auth G]

Modified Residues 2 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
2MR Query on 2MR	I [auth D]	L-PEPTIDE LINKING	C₈ H₁₈ N₄ O₂		ARG
FME Query on FME	K [auth A]	L-PEPTIDE LINKING	C₆ H₁₁ N O₃ S		MET

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.30 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	RELION	3.1.0
MODEL REFINEMENT	PHENIX	1.2

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2024-09-11

Deposition Author(s):

Ivanov, B.S.

Bridges, H.R.

Hirst, J.

Funding Organization	Location	Grant Number
Medical Research Council (MRC, United Kingdom)	United Kingdom	MC_UU_00015/2
Medical Research Council (MRC, United Kingdom)	United Kingdom	MC_UU_00028/1

Revision History (Full details and data files)

Version 1.0: 2024-09-11
Type: Initial release
Version 1.1: 2024-11-06
Changes: Data collection, Structure summary

RCSB PDB Core Operations are funded by the U.S. National Science Foundation (DBI-2321666), the US Department of Energy (DE-SC0019749), and the National Cancer Institute, National Institute of Allergy and Infectious Diseases, and National Institute of General Medical Sciences of the National Institutes of Health under grant R01GM157729.

Prepare Data

Validate Data

Deposit Data

Help and Resources

8QBY

Respiratory complex I from Paracoccus denitrificans in MSP2N2 nanodiscs

Respiratory complex I from Paracoccus denitrificans

Entity ID: 1

UniProt

Entity Groups

Sequence Annotations

Entity ID: 2

UniProt

Entity Groups

Sequence Annotations

Entity ID: 3

UniProt

Entity Groups

Sequence Annotations

Entity ID: 4

UniProt

Entity Groups

Sequence Annotations

Entity ID: 5

UniProt

Entity Groups

Sequence Annotations

Entity ID: 6

UniProt

Entity Groups

Sequence Annotations

Entity ID: 7

UniProt

Entity Groups

Sequence Annotations

Entity ID: 8

UniProt

Entity Groups

Sequence Annotations

Entity ID: 9

UniProt

Entity Groups

Sequence Annotations

Entity ID: 10

UniProt

Entity Groups

Sequence Annotations

Entity ID: 11

UniProt

Entity Groups

Sequence Annotations

Entity ID: 12

UniProt

Entity Groups

Sequence Annotations

Entity ID: 13

UniProt

Entity Groups

Sequence Annotations

Entity ID: 14

UniProt

Entity Groups

Sequence Annotations

Entity ID: 15

UniProt

Entity Groups

Sequence Annotations

Entity ID: 16

UniProt

Entity Groups

Sequence Annotations

Entity ID: 17

UniProt

Entity Groups

Sequence Annotations

Entity ID: 18

UniProt

Entity Groups

Sequence Annotations

Experimental Data
