8Q2N | pdb_00008q2n

Cas1-Cas2 CRISPR integrase bound to prespacer and target DNA, Streptococcus thermophilus DGCC 7710 CRISPR3 system

• PDB DOI: https://doi.org/10.2210/pdb8Q2N/pdb
• NAKB: 8Q2N
• EM Map EMD-18113: EMDB EMDataResource

• Classification: DNA BINDING PROTEIN
• Organism(s): Streptococcus thermophilus DGCC 7710, synthetic construct
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2023-08-02 Released: 2024-08-14
• Deposition Author(s): Sasnauskas, G., Gaizauskaite, U., Tamulaitiene, G.
• Funding Organization(s): Research Council of Lithuania

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 2.98 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Starting Model: in silico

Literature

Structural basis for spacer acquisition in a type II-A CRISPR-Cas system

Sasnauskas, G., Gaizauskaite, U., Tamulaitiene, G.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Hetero 6-mer - A4B2

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 213.91 kDa
• Atom Count: 13,714
• Modeled Residue Count: 1,520
• Deposited Residue Count: 1,584
• Unique protein chains: 2
• Unique nucleic acid chains: 4

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
CRISPR-associated endoribonuclease Cas2	A, D	114	Streptococcus thermophilus DGCC 7710	Mutation(s): 0  Gene Names: cas2 EC: 3.1
UniProt
Find proteins for G3ECR3 (Streptococcus thermophilus) Explore G3ECR3  Go to UniProtKB:  G3ECR3

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
CRISPR-associated endonuclease Cas1	B, C, E, F	302	Streptococcus thermophilus DGCC 7710	Mutation(s): 0  Gene Names: cas1 EC: 3.1
UniProt
Find proteins for G3ECR2 (Streptococcus thermophilus) Explore G3ECR2  Go to UniProtKB:  G3ECR2

Entity ID: 3
Molecule	Chains	Length	Organism	Image
Prespacer DNA, chain G	G	26	synthetic construct

Entity ID: 4
Molecule	Chains	Length	Organism	Image
Prespacer DNA, chain H	H	26	synthetic construct

Entity ID: 5
Molecule	Chains	Length	Organism	Image
Integration target, chain I	I	48	synthetic construct

Entity ID: 6
Molecule	Chains	Length	Organism	Image
Integration target, chain J	J	48	synthetic construct

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MG	K [auth A], L [auth D]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 2.98 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC	4.2.1+230427
MODEL REFINEMENT	PHENIX	1.21rc1_4903

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2024-08-14
Deposition Author(s): Sasnauskas, G., Gaizauskaite, U., Tamulaitiene, G.

---

Funding Organization	Location	Grant Number
Research Council of Lithuania	Lithuania	S-MIP-19-32

Revision History

• Version 1.0: 2024-08-14
  Type: Initial release
