8Q0P

Crystal Structure of an N-terminal Domain of Variant Surface Glycoprotein 21 (VSG21) of Trypanosome brucei brucei Lister 427


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.01 Å
  • R-Value Free: 0.219
  • R-Value Work: 0.179
  • R-Value Observed: 0.181

Starting Model: in silico
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

A structural classification of the variant surface glycoproteins of the African trypanosomey.

Dakovic, S.Zeelen, J.P.Gkeka, A.Chandra, M.van Straaten, M.Foti, K.Zhong, J.Vlachou, E.P.Aresta-Branco, F.Verdi, J.P.Papavasiliou, F.N.Stebbins, C.E.

(2023) PLoS Negl Trop Dis 17: e0011621-e0011621

  • DOI: https://doi.org/10.1371/journal.pntd.0011621
  • Primary Citation of Related Structures:
    8OK4, 8OK5, 8OK6, 8OK7, 8OK8, 8ONH, 8Q0E, 8Q0P

  • PubMed Abstract:

    Long-term immune evasion by the African trypanosome is achieved through repetitive cycles of surface protein replacement with antigenically distinct versions of the dense Variant Surface Glycoprotein (VSG) coat. Thousands of VSG genes and pseudo-genes exist in the parasite genome that, together with genetic recombination mechanisms, allow for essentially unlimited immune escape from the adaptive immune system of the host. The diversity space of the "VSGnome" at the protein level was thought to be limited to a few related folds whose structures were determined more than 30 years ago. However, recent progress has shown that the VSGs possess significantly more architectural variation than had been appreciated. Here we combine experimental X-ray crystallography (presenting structures of N-terminal domains of coat proteins VSG11, VSG21, VSG545, VSG558, and VSG615) with deep-learning prediction using Alphafold to produce models of hundreds of VSG proteins. We classify the VSGnome into groups based on protein architecture and oligomerization state, contextualize recent bioinformatics clustering schemes, and extensively map VSG-diversity space. We demonstrate that in addition to the structural variability and post-translational modifications observed thus far, VSGs are also characterized by variations in oligomerization state and possess inherent flexibility and alternative conformations, lending additional variability to what is exposed to the immune system. Finally, these additional experimental structures and the hundreds of Alphafold predictions confirm that the molecular surfaces of the VSGs remain distinct from variant to variant, supporting the hypothesis that protein surface diversity is central to the process of antigenic variation used by this organism during infection.


  • Organizational Affiliation

    Division of Structural Biology of Infection and Immunity, German Cancer Research Center, Heidelberg, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Variant surface glycoprotein MITat 1.21
A, B, C, D, E
A, B, C, D, E, F
476Trypanosoma brucei bruceiMutation(s): 0
Gene Names: MITat 1.21
UniProt
Find proteins for B3GVH9 (Trypanosoma brucei brucei)
Explore B3GVH9
Go to UniProtKB:  B3GVH9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB3GVH9
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.01 Å
  • R-Value Free: 0.219
  • R-Value Work: 0.179
  • R-Value Observed: 0.181
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 174.329α = 90
b = 84.422β = 100.89
c = 120.095γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
pointlessdata scaling
XDSdata reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Helmholtz AssociationGermany--

Revision History  (Full details and data files)

  • Version 1.0: 2023-09-13
    Type: Initial release
