8PRE

The structure of nvBagel2 in the presence of Zn(II)

PDB DOI: https://doi.org/10.2210/pdb8PRE/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): synthetic construct
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): No

Deposited: 2023-07-12 Released: 2024-07-24
Deposition Author(s): Vandebroek, L., Voet, A.R.D., Lee, X.Y.
Funding Organization(s): Research Foundation - Flanders (FWO)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.10 Å
R-Value Free: 0.288
R-Value Work: 0.229
R-Value Observed: 0.232

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

The structure of v13Bagel2

Vandebroek, L., Voet, A.R.D., Lee, X.Y.

To be published.

Macromolecule Content

Total Structure Weight: 9.18 kDa
Atom Count: 608
Modelled Residue Count: 79
Deposited Residue Count: 84
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cell surface protein	A	84	synthetic construct	Mutation(s): 0 Gene Names: DICTH_0179
UniProt
Find proteins for B5YBJ6 (Dictyoglomus thermophilum (strain ATCC 35947 / DSM 3960 / H-6-12)) Explore B5YBJ6 Go to UniProtKB: B5YBJ6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	B5YBJ6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN (Subject of Investigation/LOI) Query on ZN Download Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A]	B [auth A], C [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.10 Å
R-Value Free: 0.288
R-Value Work: 0.229
R-Value Observed: 0.232
Space Group: I 4 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.05	α = 90
b = 55.05	β = 90
c = 107.92	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
xia2	data scaling
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2024-07-24

Deposition Author(s):

Funding Organization	Location	Grant Number
Research Foundation - Flanders (FWO)	Belgium	1235722N

Revision History (Full details and data files)

Version 1.0: 2024-07-24
Type: Initial release
