8PK6

INTS13 complex with ZNF655


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.21 Å
  • R-Value Free: 0.333
  • R-Value Work: 0.299
  • R-Value Observed: 0.301

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Basis of gene-specific transcription regulation by the Integrator complex.

Sabath, K.Nabih, A.Arnold, C.Moussa, R.Domjan, D.Zaugg, J.B.Jonas, S.

(2024) Mol Cell 84: 2525

  • DOI: https://doi.org/10.1016/j.molcel.2024.05.027
  • Primary Citation of Related Structures:
    8PK5, 8PK6

  • PubMed Abstract:

    The Integrator complex attenuates gene expression via the premature termination of RNA polymerase II (RNAP2) at promoter-proximal pausing sites. It is required for stimulus response, cell differentiation, and neurodevelopment, but how gene-specific and adaptive regulation by Integrator is achieved remains unclear. Here, we identify two sites on human Integrator subunits 13/14 that serve as binding hubs for sequence-specific transcription factors (TFs) and other transcription effector complexes. When Integrator is attached to paused RNAP2, these hubs are positioned upstream of the transcription bubble, consistent with simultaneous TF-promoter tethering. The TFs co-localize with Integrator genome-wide, increase Integrator abundance on target genes, and co-regulate responsive transcriptional programs. For instance, sensory cilia formation induced by glucose starvation depends on Integrator-TF contacts. Our data suggest TF-mediated promoter recruitment of Integrator as a widespread mechanism for targeted transcription regulation.


  • Organizational Affiliation

    Department of Biology, Institute of Molecular Biology and Biophysics, ETH Zurich, 8093 Zurich, Switzerland. Electronic address: kevin.sabath@imp.ac.at.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Integrator complex subunit 13
A, C, E
242Homo sapiensMutation(s): 0
Gene Names: INTS13ASUNC12orf11GCT1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NVM9 (Homo sapiens)
Explore Q9NVM9
Go to UniProtKB:  Q9NVM9
PHAROS:  Q9NVM9
GTEx:  ENSG00000064102
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NVM9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Zinc finger protein 655
B, D, F
30Homo sapiensMutation(s): 0
Gene Names: ZNF655VIK
UniProt & NIH Common Fund Data Resources
Find proteins for Q8N720 (Homo sapiens)
Explore Q8N720
Go to UniProtKB:  Q8N720
PHAROS:  Q8N720
GTEx:  ENSG00000197343
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8N720
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.21 Å
  • R-Value Free: 0.333
  • R-Value Work: 0.299
  • R-Value Observed: 0.301
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 126.997α = 90
b = 188.103β = 90
c = 52.757γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Cootmodel building
XDSdata reduction
PHASERphasing
XSCALEdata scaling

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Swiss National Science FoundationSwitzerland141735
Swiss National Science FoundationSwitzerland182880
Swiss National Science FoundationSwitzerland205601
Other governmentSwitzerlandMB22.00064
European Molecular Biology Organization (EMBO)European Union4918
Other governmentGermanyPh.D. fellowship Kevin Sabath

Revision History  (Full details and data files)

  • Version 1.0: 2024-07-03
    Type: Initial release
  • Version 1.1: 2024-07-24
    Changes: Database references
  • Version 1.2: 2024-11-13
    Changes: Structure summary
