8OVN | pdb_00008ovn

X-ray structure of the SF-iGluSnFR-S72A

PDB DOI: https://doi.org/10.2210/pdb8OVN/pdb

Classification: FLUORESCENT PROTEIN
Organism(s): Shigella flexneri
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2023-04-26 Released: 2023-05-17
Deposition Author(s): Tarnawski, M., Hellweg, L., Bergner, A., Hiblot, J., Leippe, P., Johnsson, K.
Funding Organization(s): Max Planck Society

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free:
0.253 (Depositor), 0.251 (DCC)
R-Value Work:
0.200 (Depositor), 0.199 (DCC)
R-Value Observed:
0.202 (Depositor)

Starting Models: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8OVN

This is version 1.1 of the entry. See complete history.

Literature

X-ray structure of the SF-iGluSnFR-S72A

Tarnawski, M., Hellweg, L., Bergner, A., Hiblot, J., Leippe, P., Johnsson, K.

To be published.

Macromolecule Content

Total Structure Weight: 58.21 kDa
Atom Count: 4,019
Modeled Residue Count: 504
Deposited Residue Count: 518
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative periplasmic binding transport protein,Green fluorescent protein	A	518	Shigella flexneri	Mutation(s): 22 Gene Names: ybeJ, SF0626, GFP
UniProt
Find proteins for P37902 (Escherichia coli (strain K12)) Explore P37902 Go to UniProtKB: P37902
Find proteins for P42212 (Aequorea victoria) Explore P42212 Go to UniProtKB: P42212
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Groups	P42212 P37902
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CIT Query on CIT Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	CITRIC ACID C₆ H₈ O₇ KRKNYBCHXYNGOX-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CRO Query on CRO	A	L-PEPTIDE LINKING	C₁₅ H₁₇ N₃ O₅		THR, TYR, GLY

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free: 0.253 (Depositor), 0.251 (DCC)
R-Value Work: 0.200 (Depositor), 0.199 (DCC)
R-Value Observed: 0.202 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 106.14	α = 90
b = 106.14	β = 90
c = 108.14	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-05-17

Deposition Author(s):

Funding Organization	Location	Grant Number
Max Planck Society	Germany	--

Revision History (Full details and data files)

Version 1.0: 2023-05-17
Type: Initial release
Version 1.1: 2024-10-23
Changes: Data collection, Structure summary
